OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1 2M

OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1 2M Specification

Features
Short cylindrical shape, Robust build, LED operation indicator

Application
General industrial applications

Signal Type
Discrete

Sensor Type
Inductive

Sensitivity
Factory set

Cable Length
2 meters

Power Consumption
10 mA (no load)

Operating Temperature
-25C to +70C

Measurement Range
Sensing distance 8mm

Mounting Type
Flush mounting

Wireless
No

IP Rating
IP67

Response Time
2 ms

Interface
Cable

Product Type
Proximity Sensor

Material
Stainless Steel Housing

Input
DC

Output
PNP, Normally Open (NO)

Function
Detection of metallic objects without physical contact

Usage
Industrial automation, machine tools, robotics

Accuracy
High

Resolution
Standard

Voltage
10-30V DC

Weight
Approx. 100g

Ambient Humidity
35% to 95% RH (non-condensing)

Threaded Length
Approx. 55 mm

Shock Resistance
500 m/s2 (approx. 50 G) 3 times each in X, Y, Z axes

Protection Circuit
Reverse polarity, Surge protection, Output short-circuit protection

Diameter
M12

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Connector Type
Pre-wired

Active Surface Material
PBT (Polybutylene Terephthalate)

Housing Material
Nickel-plated brass

Switching Frequency
1000 Hz (Max)

About OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1 2M

Redeem the prime choice for industrial detection with the famed OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1 2M. Engineered for exceptional reliability, this sensor features a robust nickel-plated brass housing, pre-wired connection, and superior shock and vibration resistance. With its 8mm sensing distance and high accuracy detection, it's ideal for automation, robotics, and machine tools. Add to cart or buy now to experience discrete, precise metallic object detection, complete with IP67 protection, LED operation indicator, and an energy-efficient design. Trusted by suppliers and wholesalers worldwide.

Versatile Application & Prime Industrial Usage

The OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1 2M is tailored for the surface detection of metallic objects in demanding environments. Its inductive sensing technology facilitates contactless operation, making it exceptional for industrial automation, robotics, and machine tools. With flush mounting and a rugged stainless steel design, it seamlessly integrates into control panels and machinery. Widely applied in general industrial settings, this sensor ensures reliable operation, precise sensing, and longevity for all types of manufacturing or assembly line needs.

Sample Policy, Certifications, and Order Process

Sample requests for the OMRON PROXIMITY SENSOR can be accommodated to support your evaluation and decision-making during order completion. Products are dispatched with prompt goods transport, ensuring quick arrival at your determined destination. Each sensor is certified for industrial compliance, reflecting high standards and optimal reliability. This enables a seamless acquisition, from sample evaluation to bulk procurement, reinforcing trust in both quality and punctual delivery for suppliers, traders, and wholesalers.

FAQ's of OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1 2M:

Q: How does the OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1 2M function in industrial environments?

A: The sensor detects metallic objects without physical contact using inductive technology, ensuring accurate and reliable performance in automation, machine tool, and robotics applications.

Q: What are the primary applications of this proximity sensor?

A: It is widely used for object detection in industrial automation, assembly lines, machine tools, and robotics, supporting efficient, non-contact sensing tasks.

Q: Where can the OMRON E2B-M12KN08-WP-B1 2M be installed for optimal results?

A: The sensor is designed for flush mounting on metal surfaces, making it ideal for control panels, machinery, and tight industrial spaces.

Q: What is the process for obtaining samples and certifications for this sensor?

A: You can request samples before finalizing your order. Each sensor comes with necessary certifications and standards, ensuring quality and performance upon goods arrival.

Q: What are the benefits of using a PNP, normally open (NO) output in this sensor?

A: A PNP NO output provides easy integration with PLCs and controls, ensuring safe operation and clear signal logic for various industrial automation systems.
