OMRON PROXIMITY SENSOR 10 TO30VDC,E2E-S05S12-WC-C1

OMRON PROXIMITY SENSOR 10 TO30VDC,E2E-S05S12-WC-C1 Specification

Sensitivity
Set at factory non-adjustable

Cable Length
2 m

Sensor Type
Inductive Proximity

Mounting Type
Embedded (flush), M8 thread

Response Time
1 ms

IP Rating
IP67

Application
Metal Object Detection

Measurement Range
Sensing distance: 1.5 mm (flush mounting)

Signal Type
Digital

Wireless
No

Interface
3-wire DC

Features
Short-circuit protection, Reverse polarity protection

Operating Temperature
-25C to +70C (no icing or condensation)

Power Consumption
10 mA

Product Type
Proximity Sensor

Material
Stainless Steel (housing), PVC (cable)

Input
10 to 30 VDC

Output
NPN NO (Normally Open)

Function
Object Detection (Non-contact)

Usage
Industrial Automation, Position Sensing

Accuracy
High

Resolution
Standard

Voltage
10 to 30 VDC

Weight
Approx. 20 g (excluding cable)

Shock Resistance
500 m/s² (IEC 60068-2-27)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude (IEC 60068-2-6)

Model Number
E2E-S05S12-WC-C1

Indicator
Operation indicator (LED)

Storage Temperature
-40°C to +85°C

Housing Diameter
M8

Cable Type
Oil-resistant PVC cable

Switching Frequency
1 kHz

Connection Type
Pre-wired cable

About OMRON PROXIMITY SENSOR 10 TO30VDC,E2E-S05S12-WC-C1

Discover the lustrous efficiency of the OMRON PROXIMITY SENSOR 10 TO30VDC, model E2E-S05S12-WC-C1. Now on sale, find an unmatched blend of industrial prowess and reliability at an unbeatable price. With a robust stainless steel M8 housing, this sensor boasts unrivaled shock resistance, high accuracy for metal object detection, and a lavish IP67 protection for demanding environments. The oil-resistant PVC cable ensures durability while the operation indicator LED guarantees clear status monitoring. Elevate position sensing in your automation projects with elite performance and supreme dependability.

Versatile Applications & Optimal Usage

OMRON PROXIMITY SENSOR E2E-S05S12-WC-C1 is suitable for industrial automation lines, assembly systems, and robotic positioning tasks. Ideal for harsh environments, it excels in factories, packaging machinery, and material handling. Its robust design and high accuracy make it perfect for detecting metal objects or controlling processes where non-contact position sensing is required. The sensor's embedded mounting and flush detection ability ensure seamless integration in diverse settings.

Sample, Delivery & Supply Capability

Samples of the E2E-S05S12-WC-C1 are available for product valuation and hands-on assessment. Quotations are promptly provided upon request, ensuring transparent pricing. Handover of products occurs quickly, with standard delivery times and secure logistics. With a strong supply ability, OMRON and its network of suppliers, traders, and wholesalers in China can fulfill bulk requirements efficiently, supporting consistent operations in your enterprise.

FAQ's of OMRON PROXIMITY SENSOR 10 TO30VDC,E2E-S05S12-WC-C1:

Q: How does the OMRON E2E-S05S12-WC-C1 proximity sensor enhance industrial automation processes?

A: This sensor offers high accuracy and rapid response time, enabling reliable metal object detection and position sensing, thereby streamlining control and safety in automated environments.

Q: What places and applications is the E2E-S05S12-WC-C1 most suitable for?

A: It is ideal for factories, packaging lines, robotic systems, and material handling equipment, particularly where non-contact metal detection and environmental durability are critical.

Q: When can I expect delivery after placing an order for this sensor?

A: Standard delivery usually occurs within the agreed timeframe after order confirmation; quick handover is facilitated, especially for bulk quantities.

Q: Where can I request product samples or quotations for the E2E-S05S12-WC-C1 sensor?

A: You can contact your trusted supplier, trader, or wholesaler in China to request samples and obtain a detailed quotation tailored to your requirements.

Q: What benefits are offered by the IP67-rated housing and oil-resistant cable?

A: The IP67 protection and oil-resistant PVC cable guarantee longevity and reliability, even in harsh or hazardous industrial settings, reducing maintenance and replacement frequency.

Q: How is the sensor installed and connected in industrial applications?

A: It is easily mounted using its M8 thread for flush embedding, and connects via a pre-wired 3-wire DC cable, streamlining installation in automated systems.
