OMRON PROXIMITY SENSOR 10 TO 30VDC, E2E-C04S12-WC-C1 2M

OMRON PROXIMITY SENSOR 10 TO 30VDC, E2E-C04S12-WC-C1 2M Specification

Interface
Cable

Wireless
No

Features
Compact size, High durability, Short body, Shielded type

IP Rating
IP67

Cable Length
2 meters

Power Consumption
Max. 15 mA

Operating Temperature
-25C to +70C

Measurement Range
Sensing Distance 1 mm

Mounting Type
Flush Mount

Sensitivity
Fixed

Application
Automation Equipment, Conveyors, Robotics

Response Time
2 ms

Signal Type
DC 3-wire

Sensor Type
Inductive Proximity

Product Type
Proximity Sensor

Material
Stainless Steel

Input
10 to 30 VDC

Output
PNP Normally Open (NO)

Function
Detection of metallic objects

Usage
Industrial Automation, Position Sensing

Accuracy
High Precision

Resolution
Discrete (On/Off)

Voltage
10 to 30 VDC

Weight
Approx. 20g

Housing Diameter
4 mm

Max Switching Frequency
2 kHz

Control Output
Open collector, PNP

Ambient Humidity
35%-95% RH

Model
E2E-C04S12-WC-C1

Insulation Resistance
50 M min. (at 500 VDC)

Detection Target
Ferrous metal

Thread Size
M4

Repeat Accuracy
Within 0.03 mm

Storage Temperature
-40C to +85C

Cable Type
Pre-wired

Housing Finish
Nickel-plated brass

Protection Circuits
Surge protection, Load short-circuit protection

Body Length
Short body type

About OMRON PROXIMITY SENSOR 10 TO 30VDC, E2E-C04S12-WC-C1 2M

Introducing the new OMRON PROXIMITY SENSOR 10 TO 30VDC, E2E-C04S12-WC-C1 2M-a peerless solution for high-precision industrial automation. Select this enlightened sensor for detecting metallic objects with ineffable accuracy, offering repeatability within 0.03 mm and a sensing distance of 1 mm. Its robust, nickel-plated brass body, compact M4 thread, and IP67 protection circuit ensure enduring reliability and high durability. Take advantage of advanced protection circuits, short body design, and quick response time. Perfect for conveyors, robotics, and automation equipment, the OMRON sensor enables seamless, efficient workflows in even the most demanding environments.

Innovative Application and Distinctive Machine Features

The OMRON E2E-C04S12-WC-C1 2M inductive proximity sensor excels in automation applications such as conveyors, robotics, and positioning systems. Engineered with a compact, shielded design and short body, this sensor offers peerless operation in tight or confined spaces. Special features include surge and load short-circuit protection, high accuracy repeatability, and nickel-plated brass housing, making it a robust and durable choice for challenging industrial environments demanding precise metallic detection.

Delivery Time, Asking Price, and Sample Policy

OMRON's E2E-C04S12-WC-C1 2M sensor is delivered swiftly, meeting industry-standard timelines. We offer a flexible sample policy-samples are available upon request to assess product suitability before finalizing your purchase. Inquire now for our competitive asking price and discover the market value of a sensor trusted by automation professionals worldwide. Delivered with care and efficiency, this product ensures both satisfaction and high performance in a variety of industrial applications.

FAQ's of OMRON PROXIMITY SENSOR 10 TO 30VDC, E2E-C04S12-WC-C1 2M:

Q: How can the OMRON PROXIMITY SENSOR E2E-C04S12-WC-C1 2M be used in automation equipment?

A: The sensor is designed for accurate detection of ferrous metals, making it ideal for conveyors, robotic arms, and position sensing in modern automation systems, ensuring efficient and reliable performance.

Q: What are the special features that make this proximity sensor stand out?

A: This sensor offers a compact short body, high repeat accuracy within 0.03 mm, surge and load short-circuit protection, and a rugged nickel-plated brass housing for enhanced durability in harsh industrial environments.

Q: Where can I apply the OMRON E2E-C04S12-WC-C1 2M sensor?

A: It is suitable for use on automation equipment, conveyors, robotic systems, and applications requiring precise metallic object detection, even in demanding and space-constrained environments.

Q: What is the process for requesting a sample?

A: You can request a sample from your supplier, trader, or wholesaler. Sample availability is provided to help you evaluate its suitability for your specific application before purchasing in larger quantities.

Q: When will the product be delivered after order confirmation?

A: Delivery typically follows standard industry timelines. For exact delivery schedules, contact your supplier or distributor to confirm the shipping and arrival details of your sensor.
