OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-WP-C1

OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-WP-C1 Specification

Wireless
No

Power Consumption
10 mA (no load)

Mounting Type
Flush mounting, M18 threaded

Sensor Type
Inductive Proximity Sensor

Signal Type
Discrete

Features
LED status indicator, robust design, vibration and shock resistant

Measurement Range
Sensing distance: 8 mm (flush)

Operating Temperature
-25C to +70C

Application
Detecting metal objects, position sensing, industrial machinery

IP Rating
IP67

Interface
2-wire DC

Response Time
2 ms

Cable Length
2 m, PVC cable

Sensitivity
Factory set

Product Type
Proximity Sensor

Material
Nickel-plated brass housing

Input
10 to 30 VDC

Output
PNP Normally Open (NO)

Function
Non-contact object detection

Usage
Industrial automation, object detection

Accuracy
High repeatability, 0.08 mm

Resolution
0.01 mm

Voltage
10 to 30 VDC

Weight
Approx. 90 g

Short Circuit Protection
Yes

Output Current
Max. 200 mA

Housing Diameter
18 mm (M18)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Storage Temperature
-40C to +85C

Model Number
E2B-M18LS08-WP-C1

Connection Type
Pre-wired cable

Reverse Polarity Protection
Yes

Ambient Humidity
35% to 95% RH

Frequency Response
Up to 1 kHz

About OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-WP-C1

Order today the preeminent OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-WP-C1 and experience superb industrial object detection. Engineered with a noble nickel-plated brass housing and robust IP67 protection, this sensor boasts high accuracy (0.08 mm repeatability, 0.01 mm resolution) and reliable performance under challenging conditions. Its PNP-NO output and flush mounting make installation seamless. Take advantage of our competitive pricing and special rates for bulk purchases-ideal for wholesalers, suppliers, and traders looking to enhance their automation solutions. Secure your order today!

Applications, Material Excellence, and Commercial Uses

OMRON PROXIMITY SENSOR 10 TO 30VDC, model E2B-M18LS08-WP-C1, is extensively used for precise metal object detection, position sensing, and automation in industrial machinery. Fabricated from tough, nickel-plated brass, it ensures durability and corrosion resistance, making it suitable for demanding environments. Commercially, it finds noble applications in assembly lines, conveyors, and quality assurance setups, supporting various sectors that require reliable and continuous automation processes.

Supply Ability, Certifications, and Fast Dispatch

We guarantee swift dispatching of the OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-WP-C1. Our robust supply chain allows us to estimate quick dispatch times and reliable order fulfillment. This sensor adheres to pertinent certifications, ensuring you receive trusted and quality products. Ships from our main FOB port in China, we prioritize efficiency and reliability in every transaction, catering to both individual and bulk requirements promptly.

FAQ's of OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-WP-C1:

Q: How does the OMRON PROXIMITY SENSOR E2B-M18LS08-WP-C1 function in industrial environments?

A: The OMRON PROXIMITY SENSOR E2B-M18LS08-WP-C1 operates using non-contact inductive technology to accurately detect metal objects, making it ideal for object detection and position sensing in automated industrial systems.

Q: What materials and protective features does this sensor offer?

A: It features a robust nickel-plated brass housing, provides IP67 dust and water resistance, and includes reverse polarity and short circuit protection, ensuring reliability even in harsh industrial settings.

Q: When should I opt for this model for my automation needs?

A: Choose this sensor when you require high repeatability (0.08 mm) and factory-set sensitivity for applications involving metal detection and precise position sensing, particularly where harsh conditions may be present.

Q: Where is the sensor manufactured and how is it supplied?

A: This sensor is supplied from China, available for quick dispatch through our efficient supply chain, and can be shipped globally from our main FOB port.

Q: What benefits does the LED status indicator provide during usage?

A: The integrated LED status indicator allows for easy monitoring of sensor operation and quick troubleshooting, enhancing maintenance efficiency and system uptime.

Q: How can I order this sensor and benefit from competitive pricing or special bulk rates?

A: You can place your order today through our sales platform to access competitive pricing and inquire about special rates for bulk purchases, ideal for suppliers, traders, and wholesalers.
