OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18KS05-M1-B2

OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18KS05-M1-B2 Specification

Power Consumption
15 mA

IP Rating
IP67

Signal Type
Digital

Interface
M12 4-pin connector

Wireless
No

Application
Proximity sensing, position detection

Cable Length
M12 connector, no cable included

Sensitivity
Factory set sensitivity

Operating Temperature
-25C to +70C

Features
Robust, vibration and shock-resistant

Mounting Type
Flush (shielded) mounting

Response Time
1 ms

Measurement Range
Sensing distance 5 mm

Sensor Type
Inductive

Product Type
Proximity Sensor

Material
Metal Housing

Input
10 to 30V DC

Output
PNP, Normally Open

Function
Detection of metal objects

Usage
Industrial Automation

Accuracy
High precision (TO 0.5 mm)

Resolution
Fine resolution for object detection

Voltage
10 to 30V DC

Weight
Approx. 50 g

Indicator
LED operation indicator

Model Number
E2B-M18KS05-M1-B2

Shock Resistance
500 m/s2, 3 times each in X, Y, Z directions

Connection Type
Plug-in (connector)

Housing Material
Nickel-plated brass

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Shell Diameter
M18

Switching Frequency
1,000 Hz max.

Protection Circuits
Overload and short-circuit protection

Storage Temperature
-40C to +85C

Output Current
200 mA

About OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18KS05-M1-B2

The OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18KS05-M1-B2, is an acclaimed, cost-effective solution for industrial automation. Renowned for its illustrious durability and paragon of reliability, this trending sensor offers valorous performance in demanding environments. With a robust nickel-plated brass housing, high precision up to 0.5 mm, and advanced overload and short-circuit protection, it stands apart in quality. Its LED indicator and PNP output ensure seamless operation. Designed for accuracy and resilience, this sensor is a prudent choice for modern automated processes.

Versatile Applications and Competitive Edge

The standout OMRON PROXIMITY SENSOR E2B-M18KS05-M1-B2 is adept at metal detection and position sensing in industrial setups. Its swift plug-in connector allows a hassle-free installation method. This sensor's primary advantages include uncompromised accuracy, vibration and shock resistance, and strong IP67-rated durability. Perfect for factory floors, assembly lines, or automated machinery, it serves as an optimal, reliable solution for proximity-based applications where robust operation is paramount.

Certifications, Export Markets, and Delivery Details

Certified to endure rigorous industrial use, the E2B-M18KS05-M1-B2 is highly sought in main export markets such as China and beyond. Its streamlined shipment process ensures your expenditure is justified-goods are promptly shipped, offering minimal lead times. This paragon sensor is carefully packed to ensure safe goods transport, making it ideal for wholesalers, traders, and industrial end-users who value punctual delivery and trusted international standards.

FAQ's of OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18KS05-M1-B2:

Q: How does the OMRON E2B-M18KS05-M1-B2 proximity sensor detect objects?

A: The sensor uses inductive technology to detect the presence of metal objects within its 5 mm sensing range. When a metal object enters this range, the sensor's field is disturbed, triggering the digital PNP output.

Q: What are the key benefits of using this sensor in industrial automation?

A: Its robust, nickel-plated brass housing, high precision of up to 0.5 mm, and resistance to vibration and shock make it ideal for demanding environments. The sensor offers reliability, accuracy, and low power consumption for seamless integration.

Q: Where can this proximity sensor be applied most effectively?

A: It excels in industrial automation, especially for position detection and proximity sensing on assembly lines, packaging plants, and automated machinery-anywhere reliable metal detection is required.

Q: What method is used for connecting and mounting the sensor?

A: It features a user-friendly M12 plug-in connector for swift installation and supports flush (shielded) mounting, ensuring adaptable deployment across various setups.

Q: How is the delivery process managed for international markets?

A: Products are shipped promptly to key export destinations, with efficient goods transport and careful packaging to ensure your expenditure yields reliable products swiftly and securely.
