OMRON POWER SUPPLY 48VDC, S8FS-C07548

OMRON POWER SUPPLY 48VDC, S8FS-C07548 Specification

Phase
Single Phase

Rated Power
75W

Application
Industrial Automation, Control Panels, Factory Equipment

Power Supply
AC-DC

Current Range
0-1.6A

Cooling Method
Natural Air Cooling

Operating Temperature
-20C to +60C

Connector Type
Screw Terminal

Rated Current
1.6A

Working Temperature
-20C to +60C

Output Type
Single Output

Power Factor
>0.95 at 230VAC

Noise Level
<10mVp-p (Ripple & Noise)

Features
Reliable, High Durability, Compact Design, Easy Installation

Output Current
1.6A

Product Type
Switching Power Supply

Output Power
75W

Output Frequency
50/60Hz

Input Voltage
100-240VAC

Voltage Protection
Overvoltage, Overcurrent, Short Circuit Protection

Efficiency
89% (typical)

Material
Metal (Steel) Enclosure

Line Regulation
0.5%

Storage Temperature
-25C to +65C

Weight
Approx. 500g

Output Voltage Adjustment Range
43.2 - 52.8VDC

Hold-up Time
>20ms (at full load, 230VAC)

Series
S8FS-C

Dimensions (W x H x D)
50mm x 89mm x 95mm

Model Number
S8FS-C07548

Mounting Type
DIN Rail or Panel Mount

Input Current
1.6A (at 100VAC), 0.8A (at 240VAC)

Vibration Resistance
10 to 55 Hz, 0.375mm single amplitude

Input Frequency
50/60Hz

Humidity Range
10% to 90% RH (non-condensing)

Leakage Current
<1mA (at 240VAC)

Startup Time
500ms max.

Withstand Voltage
3kVAC Input to Output for 1 min

Insulation Resistance
100M min (500VDC)

OMRON POWER SUPPLY 48VDC, S8FS-C07548 About

Access a world-class solution with the OMRON POWER SUPPLY 48VDC, S8FS-C07548-an exclusive masterpiece engineered for industrial automation and control panels. This highly sought-after unit brings you significant savings through high efficiency and compact design, while offering reliable and durable performance. With overvoltage, overcurrent, and short-circuit protection, this power supply ensures optimal safety for your systems. Enjoy seamless installation with DIN Rail or Panel Mount options and benefit from robust metal construction, making it the preferred choice for traders, wholesalers, and industrial suppliers nationwide.

Engineered for Precision and Versatility

The OMRON POWER SUPPLY 48VDC, S8FS-C07548 is tailored for demanding industrial usage-perfect for automation, control panels, and factory equipment. Its compact design, high durability, and natural air cooling ensure long life and low maintenance. Features like adjustable output voltage, vibration resistance, and reliable screw terminal connections guarantee peak performance in rigorous environments, making it an invaluable asset for commercial and industrial applications alike.

Certifications, Swift Delivery & Nationwide Availability

Order processing for the OMRON 48VDC S8FS-C07548 power supply is rapid and ensures prompt shipment, with drop-off options streamlined to meet delivery deadlines. Certified for superior insulation and voltage protection, the unit is a trusted choice across the main domestic market. Our shipment routes cover major industrial hubs, ensuring you receive dependable quality and on-time delivery for your essential automation and control system needs.

FAQ's of OMRON POWER SUPPLY 48VDC, S8FS-C07548:

Q: How can I mount the OMRON S8FS-C07548 power supply in my setup?

A: The OMRON S8FS-C07548 supports both DIN Rail and Panel Mount installations, allowing flexibility to suit your industrial control panel requirements.

Q: What protection features does the OMRON POWER SUPPLY 48VDC, S8FS-C07548 offer?

A: This power supply incorporates overvoltage, overcurrent, and short circuit protection to enhance the safety and reliability of your electrical systems.

Q: Where can the OMRON S8FS-C07548 be commercially utilized?

A: It is sought-after in industrial automation, factory equipment, and control panels, serving diverse applications in automation and manufacturing environments.

Q: What is the shipment and order processing timeline for this power supply?

A: Order processing is efficient, with fast shipment and drop-off options available to ensure prompt delivery across the main domestic market.

Q: What benefits do traders and wholesalers gain from using the S8FS-C07548 power supply?

A: Traders and wholesalers experience savings with its high efficiency, robust durability, and the exclusive advantage of supplying a highly reliable, in-demand product.
