OMRON POWER SUPPLY 200-240VAC,S8FS-C10048

OMRON POWER SUPPLY 200-240VAC,S8FS-C10048 Specification

Output Type
Single Output

Features
High reliability, Compact design, Terminal block type, Fail Safe, Overload/Overvoltage/Short Circuit Protection

Output Current
4.5A

Operating Temperature
-20C to +60C

Power Supply
AC to DC Converter

Power Factor
>0.95

Cooling Method
Natural air cooling

Working Temperature
-20C to +60C

Phase
Single Phase

Current Range
0 - 4.5A

Connector Type
Terminal Block

Application
Industrial Automation, Control Panels, Machinery

Rated Power
100W

Rated Current
4.5A

Noise Level
50mVp-p

Product Type
Switching Power Supply

Output Power
100W

Output Frequency
50/60Hz

Input Voltage
200-240VAC

Voltage Protection
Overvoltage and Overcurrent Protection

Efficiency
up to 88%

Material
Metal Case

Line Regulation
0.5%

Storage Temperature
-25C to +65C

Weight
Approx. 590g

Dimensions
50mm (W) x 117mm (H) x 117mm (D)

Model Number
S8FS-C10048

Input Frequency
50/60Hz

Start-up hold time
20ms min.

Withstand Voltage
3.0kVAC between input and output

Insulation Resistance
100M min. (at 500VDC)

Adjustment Range (V Adj.)
10% of rated output voltage

Ripple & Noise
1% (peak-peak)

Mounting Type
DIN Rail/Panel Mount

Output Voltage
48V DC

Safety Approvals
UL, cUL, CE, TUV

About OMRON POWER SUPPLY 200-240VAC,S8FS-C10048

Capitalise on splendiferous reliability and classic performance with the OMRON POWER SUPPLY 200-240VAC S8FS-C10048. This sensational industrial-grade power supply delivers a robust 48V DC output at 4.5A, packaged in a compact metal case that's made for DIN Rail or Panel Mount applications. Highly recommended for control panels and machinery, it holds safety approvals like UL, cUL, CE, and TUV. With fail-safe features and high efficiency (up to 88%), Get It Now to ensure uninterrupted, efficient, and safe power conversion for demanding environments.

Unmatched Competitive Edge and Versatile Application

The OMRON POWER SUPPLY S8FS-C10048 boasts primary competitive advantages such as high reliability, excellent efficiency, and a compact, classic design. Surface of application includes industrial automation, control panels, and machinery. Easily installed via DIN Rail or Panel Mount methods, users can ensure secure and splendiferous power management while capitalizing on superior operational safety features for continuous industrial performance.

Packaging, Domestic Shipment, and Certifications

Items are meticulously packaged for optimal goods transport and safe shipment. Serving a wide domestic mar, the S8FS-C10048 is distributed across major industrial regions. Certified by UL, cUL, CE, and TUV, customers benefit from ensured compliance and unwavering safety. The packaging process guarantees product integrity, making it the preferred choice for dependable delivery and installation in varied domestic environments.

FAQ's of OMRON POWER SUPPLY 200-240VAC,S8FS-C10048:

Q: How can I mount the OMRON POWER SUPPLY S8FS-C10048?

A: The OMRON S8FS-C10048 provides both DIN Rail and Panel Mounting options, making installation easy and versatile for different industrial setups.

Q: What applications is this power supply suitable for?

A: This model is designed for industrial automation, control panels, and machinery, supporting reliable power conversion in demanding environments.

Q: What certifications does the S8FS-C10048 have?

A: It is certified by UL, cUL, CE, and TUV, ensuring compliance with international safety and quality standards.

Q: When should I use the overvoltage and overcurrent protection features?

A: These protection features automatically activate in case of abnormal voltage or current levels, safeguarding your equipment and maintaining operational safety.
