OMRON POWER SUPPLY 100-240VAC, S82J-10024A

OMRON POWER SUPPLY 100-240VAC, S82J-10024A Specification

Rated Power
100W

Features
High Reliability, Compact Design, Universal Input, DIN Rail Mountable

Power Supply
AC-DC Switching

Operating Temperature
-10 to 60C

Rated Current
4.5A

Application
Industrial Equipment, PLC, Control Panels

Output Type
Single Output

Connector Type
Screw Terminal Block

Power Factor
Typical 0.7

Output Current
4.5A

Current Range
0-4.5A

Working Temperature
-10 to 60C (Derating above 45C)

Cooling Method
Natural Air Cooling

Phase
Single Phase

Noise Level
120mVp-p (Ripple & Noise)

Product Type
Switching Power Supply

Output Power
100W

Output Frequency
50/60Hz

Input Voltage
100-240VAC (85-264VAC, 120-370VDC)

Voltage Protection
Overvoltage, Overcurrent, Short Circuit Protection

Efficiency
82% (typical at full load, 230VAC input)

Material
Metal Case

Line Regulation
Within 0.4% (100-240VAC) (Rated Load)

Storage Temperature
-25 to 65C

Weight
Approx. 850g

Hold-up Time
More than 20 ms (at 100VAC input, full load)

Humidity
25 to 85% RH (non-condensing)

Mounting Type
Panel Mount

Insulation Resistance
100M min. (500VDC)

Output Voltage
24VDC

Dimensions
82mm (W) 160mm (D) 40mm (H)

Input Frequency
50/60Hz

Isolation Voltage
3kVAC (Input to Output), 2kVAC (Input to Ground)

Adjustable Output
22V to 28VDC

MTBF
Over 100,000 hours (at 25C, full load)

About OMRON POWER SUPPLY 100-240VAC, S82J-10024A

Take advantage of the elite OMRON POWER SUPPLY S82J-10024A-crafted for extraordinary performance in demanding environments. This exquisite AC-DC switching unit delivers a soaring output of 24VDC (adjustable 22-28VDC), rated at 100W with a robust 4.5A current. Engineered for critical industrial tasks, its high isolation voltage, comprehensive protection (overvoltage, overcurrent, short circuit), and an impressive MTBF exceeding 100,000 hours guarantee reliability. Its compact, natural-cooling metal case ensures seamless panel or DIN rail mounting, representing an elite power solution for PLCs and control panels.

Elite Features and Versatile Applications

The OMRON S82J-10024A power supply showcases a compact design, universal AC input, high efficiency, and protection from common electrical faults. Its adjustable output and noise minimization make it ideal for precise applications across industrial equipment, automation panels, and PLC systems. Quick mounting on control panels or DIN rails streamlines installation, while superior insulation, broad humidity tolerances, and natural air-cooling ensure extraordinary stability and performance in challenging environments.

Sample Policy and Shipping Details

Samples of the OMRON POWER SUPPLY S82J-10024A are available to aid your evaluation and decision-making process before bulk orders. Upon request and agreement on the asking price, samples are dispatched promptly, ensuring swift arrival. The product is shipped from China FOB port, making expenditure estimation straightforward. Our sample policy is designed for your convenience, ensuring you understand the product's worth before substantial investment.

FAQ's of OMRON POWER SUPPLY 100-240VAC, S82J-10024A:

Q: How does the OMRON S82J-10024A ensure reliable operation in industrial environments?

A: The OMRON S82J-10024A features high insulation resistance, robust isolation voltage, and comprehensive protection against overvoltage, overcurrent, and short circuit, ensuring stable and reliable performance under demanding industrial conditions.

Q: What are the recommended application areas for this power supply model?

A: This power supply is designed for industrial automation, PLC systems, control panels, and various equipment requiring dependable 24VDC output. Its compact build and DIN rail compatibility make integration effortless.

Q: When is it best to use the adjustable voltage feature?

A: The adjustable voltage (22V to 28VDC) is advantageous when specific application loads demand precise voltage settings, protecting connected devices and optimizing operational performance.

Q: Where is the ideal mounting location for the S82J-10024A?

A: It is best mounted on control panels or DIN rails within climate-controlled industrial enclosures, ensuring optimal cooling and exposure conditions for peak performance.

Q: What process is involved in obtaining a product sample?

A: Request a sample through our supplier or trader. After agreeing on the asking price and sample expenditure terms, we promptly arrange shipment from the FOB port in China for swift arrival.
