OMRON PLUG IN RELAY, G2R-1-SN DC24(S), DADS-K1, DADS-K2, DADS-K5

OMRON PLUG IN RELAY, G2R-1-SN DC24(S), DADS-K1, DADS-K2, DADS-K5 Specification

Coil Power
Approx. 0.53W

Contact Material
Silver Alloy

Power Consumption
0.53W (approx.) Watt (W)

Coil Voltage
24V DC Volt (V)

Contact Resistance
100 m max. (at 1A 6VDC) Milliohm (m)

Ambient Temperature
-40C to +70C Celsius (oC)

Protect Feature
Enclosed, Finger-safe

Working Temperature
-40C to +70C Celsius (oC)

Contact Form
SPDT (1c - Single Pole Double Throw)

Product Type
Plug-in Relay

Insulation Resistance
1000 M min. (at 500 VDC)

Theory
Electromagnetic Relay

Usage
General Purpose, Industrial Automation

Contact Load
10A at 250VAC / 10A at 30VDC (Resistive Load)

Terminal Type
Plug-In

Rated Voltage
24V DC Volt (V)

Supply Terminal
Screw Terminal

Color
Transparent Cover with Black Base

Dimension (L*W*H)
29 mm 12.7 mm 25.5 mm Millimeter (mm)

Weight
Approximately 35g Grams (g)

Shock Resistance
1,000 m/s2 (approx. 100G)

Vibration Resistance
10 to 55 Hz, 1.5mm double amplitude

Sealing
Flux-tight, Enclosed

Mounting Type
DIN Rail or Panel Mount (with socket)

Model Numbers
G2R-1-SN DC24(S), DADS-K1, DADS-K2, DADS-K5

Socket Compatibility
PYF Series Sockets

Release Time
5 ms max.

Wire Size
Max 2.5mm2 (with terminal socket)

Certification Standards
CE, RoHS compliant

LED Indicator
Yes (for DC version)

OMRON PLUG IN RELAY, G2R-1-SN DC24(S), DADS-K1, DADS-K2, DADS-K5 Trade Information

Minimum Order Quantity
30 Number

Supply Ability
1000 Per Month

Delivery Time
7 Days

About OMRON PLUG IN RELAY, G2R-1-SN DC24(S), DADS-K1, DADS-K2, DADS-K5

Experience the pinnacle of relay technology with the top-rated OMRON PLUG IN RELAY, featuring elite designs such as the Redoubtable G2R-1-SN DC24(S), DADS-K1, DADS-K2, and DADS-K5. These preeminent relays, renowned for their rare combination of superb durability and exceptional performance, offer versatile DIN rail or panel mounting options. Their flux-tight, enclosed structure ensures safe, reliable operation, while the transparent cover with black base delivers unmistakable status visibility. Boasting industry-leading certifications (CE, RoHS), impressive vibration and shock resistance, and superior electrical specifications, this relay range epitomizes elite quality for general use and industrial automation applications.

Advantages, Features, and Applications of OMRON Plug In Relay

The OMRON PLUG IN RELAY series delivers superb operational reliability and safety. Each unit is engineered with a visible LED indicator, advanced shock and vibration resistance, and rapid operate and release times. Its compatibility with PYF Series Sockets and robust silver alloy contacts make it a rare, elite choice. Ideally suited for industrial automation and general-purpose use, these relays support 24V DC operation, offer finger-safe, enclosed protection, and accommodate diverse mounting methods, ensuring extensive applicability in demanding environments.

Main Export Markets, Sample Policy, and Sample Availability

The OMRON PLUG IN RELAY lineup enjoys arrival in top export markets including Europe, Asia, and the Americas thanks to reliable supply channels. Sample availability is provided under a straightforward, minimal expenditure policy to facilitate client evaluations before bulk procurement. Our provision of samples enables confident decision-making, making it convenient for customers worldwide to authenticate quality and functionality before committing to full-scale acquisition of these advanced relay solutions.

FAQs of OMRON PLUG IN RELAY, G2R-1-SN DC24(S), DADS-K1, DADS-K2, DADS-K5:

Q: How is the OMRON PLUG IN RELAY series mounted?

A: The OMRON PLUG IN RELAY series can be mounted either on a DIN rail or on a panel, using an appropriate socket from the compatible PYF Series Sockets.

Q: What key features make these relays suitable for industrial automation?

A: These relays offer a superb combination of high vibration and shock resistance, finger-safe enclosed design, transparent status indication, fast operate/release times, and CE/RoHS compliance, making them ideal for robust industrial settings.

Q: When should I select the OMRON G2R-1-SN DC24(S) or DADS models for my application?

A: Choose these relays for general-purpose or industrial automation tasks where reliability, safety, and compatibility with 24V DC systems are vital.

Q: Where can samples of these relays be obtained prior to purchase?

A: Samples are available upon request as part of our sample policy, allowing customers to evaluate product performance before larger scale expenditure and supply commitments.
