OMRON PLC OUTPUT UNIT,CJ1W-0D233

OMRON PLC OUTPUT UNIT,CJ1W-0D233 Specification

Features
16-channel output, removable terminal block, compact size

Power Supply
Supplied from PLC backplane

Output Current
0.5A/point, 2A/common

Application
Automation Control, Industrial Machinery

Working Temperature
0C to +55C

Connector Type
Screw terminal

Operating Temperature
0C to 55C

Rated Current
0.5A/point

Cooling Method
Natural convection

Noise Level
Low

Phase
Single

Output Type
Transistor (NPN) Output

Current Range
0 to 0.5A/point

Product Type
PLC Output Unit

Output Power
24V DC, 0.5A/point, 2A/common

Output Frequency
DC Switching only

Input Voltage
Not applicable (Output module)

Voltage Protection
Built-in surge absorber

Efficiency
High reliability

Material
Polycarbonate/ABS

Storage Temperature
-25C to +70C

Weight
Approx. 120g

Output Residual Voltage
1.2V max. (at rated load)

Mounting Method
DIN Rail or direct mounting

Model Number
CJ1W-OD233

Response Time
ON: 0.5 ms max., OFF: 0.5 ms max.

Dimensions
31 mm (W) x 89 mm (H) x 65 mm (D)

Insulation Resistance
20 M min. (at 100 VDC)

Output Leakage Current
0.1 mA max.

Common Type
8 points/common

Number of Outputs
16 points

Dielectric Strength
500 VAC for 1 min (Between external terminal and internal circuit)

Series
CJ1W

About OMRON PLC OUTPUT UNIT,CJ1W-0D233

Upgrade your automation solutions with the OMRON PLC OUTPUT UNIT, CJ1W-OD233, available at an unbeatable price! As a top-ranking, kingly choice in industrial control, this 16-channel output module ensures high reliability and efficient performance. With built-in surge protection, rapid 0.5 ms response, and removable terminal blocks, it's perfectly suited for cost-effective integration. Enjoy outstanding insulation, robust polycarbonate/ABS build, and seamless installation via DIN rail or direct mounting. Benefit now from our exclusive sale and take advantage of this remarkable discount!

Commercial & Plant Applications for Enhanced Productivity

Ideal for automation control in factories, the OMRON CJ1W-OD233 excels in commercial plants and industrial machinery. With its NPN transistor outputs and rapid response time, it efficiently manages DC power switching. Its robust construction and low noise operation make it suitable for harsh, high-demand environments, supporting automation in applications like conveyor systems, robotic assembly lines, and machine tools-delivering kingly performance across varied industrial applications and media.

Main Domestic & Export Markets with Competitive Pricing

The OMRON PLC OUTPUT UNIT, CJ1W-OD233, is highly sought-after in India's main domestic automation market for its sale price and certified reliability. Buyers benefit from internationally recognized certifications, ensuring the highest standards. Global users, especially in China and other growing markets, prefer this model for its unbeatable asking price and seamless exchange options. Positioned as a leader in global industrial automation exports, it's trusted for its value and performance.

FAQ's of OMRON PLC OUTPUT UNIT,CJ1W-0D233:

Q: How does the OMRON PLC OUTPUT UNIT, CJ1W-OD233, benefit industrial automation processes?

A: This output unit offers high-speed switching and reliable performance, making it ideal for automating complex machinery, reducing downtime, and improving operational efficiency in industrial environments.

Q: What are the main usage scenarios for the CJ1W-OD233 in plant applications?

A: The CJ1W-OD233 is commonly used in plant automation, including conveyor control, robotics, packaging machines, and assembly lines where precise and rapid DC switching is essential.

Q: Where can this OMRON output unit be mounted during installation?

A: It can be easily mounted on a DIN rail or directly onto a chassis, providing flexible installation options for integration into diverse industrial setups.

Q: What makes the CJ1W-OD233 a kingly choice for automation engineers?

A: Its compact size, reliable transistor output, low leakage current, and built-in surge absorber combine to provide superior safety and performance demanded by professional automation users.

Q: When is it recommended to use this output unit over other models?

A: Choose the CJ1W-OD233 for high-speed, 16-channel DC output requirements where rapid response, robust insulation, and low power loss are crucial.

Q: How does the built-in surge absorber enhance the durability of the unit?

A: The built-in surge absorber protects the unit and connected devices from voltage spikes, extending equipment lifespan and ensuring uninterrupted plant operations.
