OMRON PLC IN/OUT UNIT, CP1W-40EDR, CP1W-MAD11,CP1W-MAD42

OMRON PLC IN/OUT UNIT, CP1W-40EDR, CP1W-MAD11,CP1W-MAD42 Specification

Input Current
Digital: 5mA@24VDC, Analog: 4-20mA (Analog Input channels)

Protection Level
IP20

Frequency
50/60Hz

Operating Temperature
0C to 55C

Mounting Type
DIN Rail Mounting

Phase
Single Phase

Humidity
10% to 90% RH (No condensation)

Rated Voltage
24V DC

Efficiency
High Reliability and Signal Integrity

Output Voltage
24V DC Relay Output

Condition
New

Function
Digital Input/Output, Analog Input/Output Expansion

Application
Industrial Automation, Machine Control, Data Acquisition

Dimension (L*W*H)
CP1W-40EDR: 90 x 40 x 85mm, CP1W-MAD11: 80 x 45 x 90mm, CP1W-MAD42: 95 x 45 x 90mm

Power Mode
DC Powered

Voltage
24V DC

Power Consumption
CP1W-40EDR: 5.0W, CP1W-MAD11: 1.1W, CP1W-MAD42: 1.5W

Accessories
User Manual, Mounting Screws

Compatible PLC Series
OMRON CP1E/CP1L/CP1H Series

Number of Expansion Units Allowed
Up to 7 units

Output Type
CP1W-40EDR: 16 Relay outputs, CP1W-MAD11: 1 output (Analog), CP1W-MAD42: 2 outputs (Analog)

Response Time
Digital I/O: Less than 1ms

Signal Isolation
Photocoupler Isolation (Digital I/O), No isolation (Analog I/O)

Input Type
CP1W-40EDR: 24 inputs (Digital), CP1W-MAD11: 2 inputs (Analog), CP1W-MAD42: 4 inputs (Analog)

Maximum Switching Capacity (Relay)
2A @ 250V AC/30V DC

Weight
CP1W-40EDR: 250g, CP1W-MAD11: 140g, CP1W-MAD42: 180g

Storage Temperature
-20C to 75C

Minimum Switching Current (Relay)
1mA @ 5V DC

Analog Input Range
0-10V DC, 4-20mA

Input Impedance (Analog)
500k (Voltage), 250 (Current)

Analog Output Range
0-10V DC, 4-20mA

Channel Resolution (Analog)
12 bits

Isolation Resistance
20M minimum

About OMRON PLC IN/OUT UNIT, CP1W-40EDR, CP1W-MAD11,CP1W-MAD42

Highlighted for its superb reliability and noteworthy performance, the OMRON PLC IN/OUT UNIT series CP1W-40EDR, CP1W-MAD11, and CP1W-MAD42 present a sensational solution for industrial automation and machine control. These top-tier modules feature a mix of digital and analog channels across various units-making them ideal for diverse signal processing and data acquisition tasks. With advanced signal isolation, rapid response (<1ms), and robust relay outputs, this deal is designed for seamless integration with OMRON CP1E/CP1L/CP1H series. Every unit is engineered for high efficiency, durability, and exceptional signal integrity. Suitable for demanding applications.

Application Method and Material Excellence

The OMRON PLC IN/OUT UNIT series is designed for simple DIN rail mounting, allowing seamless installation across various plant applications. Its robust ABS plastic casing and high-quality electronic components ensure longevity and stability, especially under harsh industrial conditions. Not only does it excel in digital and analog signal processing, but its IP20 protection level and wide temperature range make it suitable for machine control and precise data acquisition in automation systems-delivering consistent, high-performance operation in every deployment.

Supply Ability, Sample Policy, and FOB Information

We estimate steady supply ability for the OMRON PLC IN/OUT UNIT, catering efficiently to wholesale and large-scale industrial needs. Prospective clients can request samples as per our convenient sample policy before confirming orders. Shipments are handled via a prominent China-based FOB port, ensuring reliable and efficient transportation of goods. Timely delivery and secure packaging guarantee your order reaches you swiftly, making the entire supply chain process streamlined and dependable from estimation to final shipment.

FAQ's of OMRON PLC IN/OUT UNIT, CP1W-40EDR, CP1W-MAD11,CP1W-MAD42:

Q: How does the signal isolation function enhance device safety and reliability?

A: OMRON's CP1W-40EDR unit uses photocoupler isolation for digital inputs and outputs, significantly reducing the risk of electrical interference and signal degradation. This ensures both dependable operation and long-term safety of connected equipment.

Q: What are the main applications of the CP1W-40EDR, CP1W-MAD11, and CP1W-MAD42 in industrial settings?

A: These modules are popularly used for digital input/output expansion, analog signal processing, industrial automation, machine control, and precise data acquisition in manufacturing plants and machinery.

Q: Where can these PLC IN/OUT units be installed and what mounting method is supported?

A: They're designed for DIN rail mounting, which is a standardized and convenient installation method suitable for control panels, machinery, and industrial enclosures.

Q: What makes this product a top deal compared to other expansion units?

A: Noteworthy features include high-speed response (less than 1ms), compatibility with multiple OMRON PLC series, flexible input/output combinations, and outstanding signal integrity, making it a superb investment for industrial automation.

Q: When can I expect shipment after placing an order and is there a sample available?

A: Shipment times depend on current supply and order quantity, but sample units can be provided upon request to help evaluate the product before finalizing a larger purchase.

Q: How does the product maintain signal integrity and efficiency in tough environments?

A: High-quality ABS plastic, meticulous electronic design, and IP20 protection ensure the units maintain stable operation, while signal processing precision is preserved even under varying humidity and temperature conditions.
