OMRON, PLC, CP1H-XA40DT1-D

OMRON, PLC, CP1H-XA40DT1-D Specification

Humidity
10% to 90% (non-condensing)

Frequency
50/60 Hz

Phase
Single Phase

Operating Temperature
0 to 55C

Rated Voltage
24V DC

Mounting Type
DIN Rail Mounting

Efficiency
High

Protection Level
IP20

Output Voltage
24V DC (transistor), relay outputs as per connected load

Input Current
Approx. 200 mA (at 24V DC)

Main Material
ABS Plastic, Electronic Components

Processing Type
Programmable Logic Controller

Condition
New

Function
Programmable logic, relay and transistor output control

Application
Industrial automation, machine control, process control

Dimension (L*W*H)
130 mm x 100 mm x 90 mm

Power Mode
DC Power supply

Voltage
24V DC

Power Consumption
28 W max

Accessories
User Manual, Mounting screws

Input Signal Voltage
24 VDC, 5 mA

Analog Outputs
2 channels

Output Type
Relay + Transistor (NPN)

Insulation Resistance
20 M min. (at 500 VDC)

Maximum Number of Expansion Units
Up to 7 units

Digital Inputs
24 (24VDC, sink/source selectable)

Analog Inputs
4 channels

Shock Resistance
150 m/s2, 3 times each in X, Y, Z directions

Weight
Approx. 750 g

Vibration Resistance
5 to 8.4 Hz, 3.5 mm; 8.4 to 150 Hz, 9.8 m/s2

Communication Ports
RS-232C, USB, and optional Ethernet

Digital Outputs
16 (8 Relay + 8 NPN Transistor)

Model Name
CP1H-XA40DT1-D

Program Capacity
20 Ksteps

Response Time
1.5 ms or less

Data Memory
24 Kwords

Storage Temperature
-20 to +70C

About OMRON, PLC, CP1H-XA40DT1-D

Discover the grand capabilities of the OMRON PLC CP1H-XA40DT1-D, now available on sale for demanding automation projects. This pivotal PLC offers 24 digital inputs, 16 digital outputs (8 Relay, 8 NPN Transistor), plus customizable analog I/O channels for versatile control. Redeem value from robust expansion options, advanced communication interfaces, and high program capacity to meet valorous industrial challenges. Constructed with high-quality ABS plastic and resilient electronic components, this programmable logic controller ensures high efficiency, reliable operation, and durable performance under diverse industrial conditions.

Versatile Usage, Durable Build, Ideal for Industrial Control

The OMRON PLC CP1H-XA40DT1-D is purpose-built for industrial automation, machine, and process control. With a sturdy ABS plastic chassis and reliable electronic components, it excels in harsh plant environments. Perfect for manufacturers seeking customizable and expandable solutions, its DIN rail mounting and IP20 protection deliver practical installation and robust service life. This PLC easily adapts to both new production lines and existing system upgrades, offering a pivotal role in enhancing operational efficiency and system reliability.

Swift Delivery and Reliable Supply Chain

Packing & Dispatch processes are streamlined for the OMRON PLC CP1H-XA40DT1-D. Secure packaging ensures safety during transportation, and coordinated logistics minimize delivery times. Payment terms are flexible to suit customers' procurement needs, facilitating smooth transactions. With high supply ability for bulk or single unit orders, customers worldwide can benefit from prompt and dependable shipping, supporting ramp-up projects or scheduled maintenance without unnecessary delays.

FAQ's of OMRON, PLC, CP1H-XA40DT1-D:

Q: How can the CP1H-XA40DT1-D be customized for different automation tasks?

A: The CP1H-XA40DT1-D supports up to 7 expansion units and offers both relay and transistor outputs, as well as analog I/O options, making it adaptable to a wide range of industrial automation and process control requirements.

Q: What materials ensure the durability of this OMRON PLC?

A: This PLC uses ABS plastic and premium electronic components, which grant high resistance to shock, vibration, and harsh plant environments, providing long-lasting and reliable service.

Q: When can customers expect delivery after placing an order?

A: Orders are packed and dispatched promptly, with delivery times depending on the destination and selected transportation method. Most shipments can be expected within standard international or domestic shipping durations.

Q: Where can the CP1H-XA40DT1-D be installed in an industrial setting?

A: The PLC is designed for DIN rail mounting and fits securely in control cabinets, suitable for a range of industrial and process plant environments.

Q: What is the process for redeeming benefits from this PLC's capabilities?

A: Users can leverage high program capacity, multiple I/O options, and seamless integration with other equipment by configuring the PLC according to project needs, maximizing efficiency and productivity.

Q: How does the PLC enhance efficiency and plant operation?

A: With swift response times, customizable inputs/outputs, reliable communication ports, and high memory capacity, the CP1H-XA40DT1-D optimizes automation, ensuring valorous uptime and streamlined process control.
