OMRON PHOTOELECTRIC SWITCH,E3ZM-V86

OMRON PHOTOELECTRIC SWITCH,E3ZM-V86 Specification

Response Time
1 ms max.

Circuit Type
NPN Open Collector

Number of Module
Single

Temperature Range
-25C to +55C

Protection Level
IP67

Rated Voltage
12 to 24 VDC (10 to 30 VDC allowable)

Automation Grade
Automatic

Max. Current
100 mA max. at 24 VDC

Finish Type
Glossy/Matte

Product Type
Photoelectric Switch

Material
Stainless Steel (SUS316L), PBT (Polybutylene Terephthalate)

Insulation Resistance
20 M min. (at 500 VDC)

Max. Voltage
26.4 VDC

Operating Temperature
-25C to +55C (with no icing or condensation)

Size
10.9 x 20 x 31 mm (W x H x D)

Color
Metallic/Black

Weight
Approx. 15 g

Mounting Type
Panel/Through-hole Mounting

Current Rating
Output: 100 mA max.

No Of Poles
3-wire

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Sensing Method
Diffuse-reflective (mark detection)

Light Source
Red LED (pulse modulation)

Ambient Humidity
35 to 85% RH

Shock Resistance
500 m/s2, 3 times each in X, Y, and Z directions

EMC
Conforms to EN60947-5-2

Sensing Distance
12 to 24 mm

Output Type
NPN

Indicators
Operation indicator (orange), stability indicator (green)

Model
E3ZM-V86

Connection Method
Pre-wired 2 m cable

About OMRON PHOTOELECTRIC SWITCH,E3ZM-V86

Get your hands on the redoubtable OMRON PHOTOELECTRIC SWITCH, E3ZM-V86. Featuring a first-string diffuse-reflective sensing method for accurate mark detection using a pulse-modulated Red LED, this switch navigates challenging environments with pristine precision. Its robust stainless steel (SUS316L) and PBT body ensures high endurance against vibration, shock, and humidity. With a max current of 100 mA, IP67 protection, and a 1 ms response time, this scarce automation gem now comes with a special price cut perfect for suppliers and wholesalers seeking dependable performance.

Versatile Applications & Standout Features

The OMRON E3ZM-V86 serves reliably in packaging, labeling, and automation, swiftly detecting marks even in dynamic processes. Its pristine stainless steel housing offers superior resistance to harsh conditions, ensuring long-term durability. Distinguished by a 1 ms response time and dual LED indicators, this compact and glossy/matte switch outperforms competitors in challenging environments. Its universal panel/through-hole mounting and automation grade quality cement its place as a prime choice for both new systems and retrofit projects.

Payment Options & Export Details

List price offers exceptional value for the OMRON E3ZM-V86, with products shipped efficiently to leading export markets, including Asia, Europe, and the Middle East. Flexible payment terms are available to suit buyer preferences. We offer sample policies tailored to wholesale inquiries, making testing and evaluation seamless. Secure your order today and benefit from deals designed for suppliers, traders, and volume buyers aiming to enhance their automation solutions with this dependable, competitive switch.

FAQs of OMRON PHOTOELECTRIC SWITCH,E3ZM-V86:

Q: How does the OMRON E3ZM-V86 ensure reliable mark detection in automation processes?

A: The E3ZM-V86 utilizes a diffuse-reflective sensing method with a red LED (pulse modulation), providing precise and consistent mark detection, even on moving objects. Its fast 1 ms response time further enhances efficiency in high-speed applications.

Q: What makes the OMRON E3ZM-V86 ideal for harsh environments?

A: Its construction features pristine stainless steel (SUS316L) and PBT material, complemented by IP67 protection, high vibration, and shock resistance, ensuring durability and stable operation in challenging industrial settings.

Q: Where is the OMRON E3ZM-V86 commonly used?

A: This photoelectric switch is widely used in packaging lines, labeling machinery, and diverse industrial automation tasks requiring stable and accurate mark detection.

Q: What is the process for ordering samples of the E3ZM-V86?

A: Sample policies are available to prospective buyers and volume purchasers. Interested parties can contact the supplier or wholesaler directly to request samples before placing larger orders.

Q: How much current does the E3ZM-V86 handle, and what is its rated voltage?

A: The switch supports a maximum current of 100 mA at 24 VDC and operates reliably within a rated voltage range of 12 to 24 VDC (allowing for 10 to 30 VDC).
