OMRON PHOTOELECTRIC SWITCH, E3FA-DP13

OMRON PHOTOELECTRIC SWITCH, E3FA-DP13 Specification

Response Time
1 ms

Power Consumption
25 mA (current consumption)

Application
Sensing object presence, production lines

Cable Length
2 meters (standard)

Measurement Range
100 mm (sensing distance)

Sensitivity
Adjustable by potentiometer

Interface
Pre-wired cable

Mounting Type
Panel or surface mounting

Wireless
No

Features
Compact size, easy installation, LED indicator

Operating Temperature
-25C to +55C

Sensor Type
Photoelectric

IP Rating
IP67

Signal Type
Digital output

Product Type
Photoelectric Switch

Material
Plastic body with acrylic lens

Input
12 to 24 V DC

Output
PNP, NO/NC selectable

Function
Diffuse Reflective Type

Usage
Industrial automation, object detection

Accuracy
High accuracy detection

Resolution
Detectable object: Opaque, 2 mm min. diameter

Voltage
12-24 VDC 10%

Weight
Approx. 50g (including cable)

Housing Diameter
18 mm

Light Source
Red LED (Visible)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Connection Method
Pre-wired (Standard), Connector type available

Control Output Voltage
30 VDC max.

Storage Temperature
-40°C to +70°C

Ambient Humidity
35% to 85% RH (non-condensing)

Protection Circuits
Reverse polarity and load short circuit protection

Shock Resistance
500 m/s², 3 times each in X, Y, and Z directions

Maximum Load Current
100 mA max.

Indicator
Operation indicator (red LED)

About OMRON PHOTOELECTRIC SWITCH, E3FA-DP13

Redeem the astonishing reliability of OMRON PHOTOELECTRIC SWITCH, E3FA-DP13, designed for invincible industrial automation and sublime object detection. Capitalise on its high accuracy, PNP output, and adjustable sensitivity to optimise your production lines. Secure a discount with our trusted supplier network and experience a compact, robust photoelectric sensor boasting IP67 protection, vibration and shock resistance, and a durable acrylic lens. Detect opaque objects from 2 mm diameter at a sublime response time 1 ms, all in a plastic body housing for effortless installation and sublime performance.

Competitive Advantages & Application Highlights

The OMRON PHOTOELECTRIC SWITCH, E3FA-DP13 stands out with its compact form, high precision, and superior environmental resistance. It is ideal for demanding industrial environments such as automated production lines and object sensing stations. Specifically used to detect the presence of small and opaque objects, its sublime reliability and invincible accuracy deliver optimum performance, while its LED indicator streamlines usage and monitoring, providing a competitive edge in various application places.

Supply Ability & Market Delivery Details

Our supply ability ensures the E3FA-DP13 can be estimated, processed, and shipped reliably across the main domestic market. Carefully packaged for safety, each sensor is handed over following strict quality checks. With shipment options tailored to client requirements, we minimise lead times for wholesalers and traders. This guarantees prompt deliveries to buyers in China and beyond, maintaining consistent stock availability and trusted partnership.

FAQs of OMRON PHOTOELECTRIC SWITCH, E3FA-DP13:

Q: How does the OMRON E3FA-DP13 photoelectric switch enhance industrial automation?

A: The E3FA-DP13 improves industrial automation by providing high-accuracy, fast-response object detection (1 ms), adjustable sensitivity, and reliable performance in robust environments, streamlining process efficiency on production lines.

Q: What is the main benefit of using this photoelectric switch in production applications?

A: It delivers invincible accuracy when sensing objects as small as 2 mm, supports quick installation, and remains resistant to vibration, shock, and harsh temperatures, ensuring continuous, sublime operation.

Q: Where can the E3FA-DP13 be effectively utilised?

A: This sensor is ideal for use in automated factories, packaging stations, presence detection on conveyor belts, assembly lines, and anywhere precise, rapid object sensing is required.

Q: What is the process for adjusting sensitivity and detecting opaque objects?

A: Sensitivity can be fine-tuned easily with the built-in potentiometer, enabling detection of opaque objects down to 2 mm diameter, ensuring precise configuration for diverse applications.

Q: When should users capitalise on the operation indicator feature?

A: Users should monitor the red LED operation indicator for real-time feedback on the sensors functioning, allowing prompt reaction to system changes or potential issues.

Q: How is the OMRON E3FA-DP13 packaged and handed over to customers?

A: Each product is carefully packaged to withstand shipment conditions and is handed over after rigorous quality assurance checks, ensuring it arrives ready for immediate installation.
