OMRON PHOTOELECTRIC SENSOR, E3FA-TP21

OMRON PHOTOELECTRIC SENSOR, E3FA-TP21 Specification

Wireless
No

Signal Type
Digital

Application
Object sensing, Material handling, Process control

Operating Temperature
-25C to +55C

Sensor Type
PHOTOELECTRIC SWITCH

Sensitivity
Adjustable

Cable Length
2 meters

Response Time
1 ms

Interface
3-wire cable connection

Measurement Range
0.1 to 2 m (diffuse reflective)

IP Rating
IP67

Mounting Type
M18 Threaded Barrel

Features
Compact size, Easy installation, LED Status Indicator, Reverse polarity protection

Power Consumption
25 mA

Product Type
PHOTOELECTRIC SENSOR

Material
ABS Plastic

Input
10 to 30V DC

Output
PNP (Normally Open)

Function
Object Detection

Usage
Industrial Automation, Conveyor Systems, Packaging Machinery

Accuracy
High accuracy object detection

Resolution
Standard resolution

Voltage
10 to 30V DC

Weight
Approx. 70g

Frequency
500 Hz

Housing Diameter
18 mm

Repeatability
0.2 mm

Indicator
Operation LED (Yellow), Stability LED (Green)

Package Contents
1 sensor unit, Mounting nuts

Protection Circuit
Surge protection, Short-circuit protection

Adjustment
Sensitivity adjustment trimmer

Shock Resistance
500 m/s2 (approx. 50G) for 3 times in each direction

Maximum Load Current
100 mA at 30V DC

Connection Method
Pre-wired cable (2m)

Ambient Humidity
35% to 95% RH

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Light Source
Red LED (visible)

Sensing Method
Diffuse Reflective

Compliance
CE, RoHS

About OMRON PHOTOELECTRIC SENSOR, E3FA-TP21

For a limited time, grab the new release of the lustrous OMRON PHOTOELECTRIC SENSOR, E3FA-TP21. This noteworthy and sought-after sensor boasts state-of-the-art diffuse reflective sensing, powered by a visible red LED and engineered for high accuracy object detection. Housed in a compact 18 mm barrel, it features advanced repeatability ( 0.2 mm), robust shock and vibration resistance, and IP67 protection. With a sensitivity adjustment trimmer, clear LED indicators, and pre-wired convenience, its ideal for industrial automation, conveyor systems, and packaging machinery. Compliance with CE and RoHS guarantees reliability and safety.

Versatile Features for Robust Automation

The E3FA-TP21 offers precise object detection via a standard resolution diffuse reflective method. Its sensitivity adjustment trimmer and LED status indicators ensure operational flexibility. Notable for its compact design and ABS plastic build, the sensor resists vibration and shock, making it highly reliable for industrial automation, packaging machinery, and conveyor systems. It stands out for easy installation and consistent performance, streamlining material handling and process control applications.

Efficient Supply and Certified Delivery

Shipped from Chinas major FOB ports, the OMRON E3FA-TP21 sensor is available for express shipping and prompt handling. With robust supply abilities, certified by CE and RoHS, every unit is delivered in protective packaging. The list price offers value for traders and wholesalers, ensuring timely delivery and strict adherence to international certification standards for industrial use.

FAQs of OMRON PHOTOELECTRIC SENSOR, E3FA-TP21:

Q: How does the OMRON E3FA-TP21 sensor benefit industrial automation applications?

A: The E3FA-TP21 delivers high accuracy object detection and exceptional reliability through its repeatable sensing and robust protection, streamlining automation processes and reducing errors in industries such as packaging and conveyor systems.

Q: What connection method is used for installing the E3FA-TP21 sensor?

A: This sensor is equipped with a 2-meter pre-wired 3-wire cable for straightforward, secure installation in various automation setups.

Q: When should the sensitivity adjustment trimmer be used?

A: The sensitivity adjustment trimmer should be used during setup and calibration to optimize detection for different objects or distances, ensuring precise operation in variable environments.

Q: Where can the E3FA-TP21 sensor be applied?

A: Its widely used in material handling, conveyor systems, process control, and packaging machinery where reliable object sensing is essential for efficient operations.

Q: What certifications support the quality of the E3FA-TP21 sensor?

A: This sensor complies with CE and RoHS certifications, guaranteeing that it meets strict safety and environmental standards for industrial applications.

Q: How does the sensor indicate operational status?

A: The E3FA-TP21 features yellow operation and green stability LED indicators, allowing users to quickly verify real-time status and functionality at a glance.
