OMRON PHOTOELECTRIC SENSOR E3FA-DP23, E3FA-TP12

OMRON PHOTOELECTRIC SENSOR E3FA-DP23, E3FA-TP12 Specification

Sensor Type
Diffuse-Reflective (E3FA-DP23), Through-Beam (E3FA-TP12)

Sensitivity
Adjustable (Potentiometer)

Operating Temperature
25C to +55C Celsius (oC)

Signal Type
Digital

Interface
3-wire Cable, M12 Connector

Features
LED Indicator, Short-circuit and Reverse Polarity Protection, Compact

Cable Length
2 m Meter (m)

Mounting Type
M18 Threaded, Panel or Bracket Mounting

IP Rating
IP67

Wireless
No

Measurement Range
300 mm

Application
Industrial Automation, Packaging, Conveyor systems

Product Type
Photoelectric Sensor

Material
Plastic Housing

Input
DC 12-24V

Output
PNP Output

Function
Object Detection

Usage
Automation, Position Sensing

Resolution
Standard

Voltage
12-24V DC Volt (v)

Weight
About 50 g Grams (g)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude, 2 hrs each in X, Y, Z

Cable Type
PVC, 3-wire 2 m

Operating Humidity
35AAA85% RH (No condensation)

Ambient Illumination
Sunlight: 10,000 lx Max, Incandescent: 3,000 lx Max

Control Output Current
Max 100 mA

Polarity Protection
Yes

Light Source
Red LED (Visible)

Detection Method
Diffuse (E3FA-DP23), Through-Beam (E3FA-TP12)

Housing Dimensions
18 mm Diameter, 59 mm Length

Short Circuit Protection
Yes

Max Sensing Distance (Through-Beam)
2 m

Shock Resistance
500 m/sAA2 (approx. 50G), 3 times each in X, Y, Z

Case Color
Black

OMRON PHOTOELECTRIC SENSOR E3FA-DP23, E3FA-TP12 Trade Information

Minimum Order Quantity
10 Number

Supply Ability
1000 Per Month

Delivery Time
7 Days

OMRON PHOTOELECTRIC SENSOR E3FA-DP23, E3FA-TP12 About

Discover the rare and magnificent OMRON PHOTOELECTRIC SENSOR E3FA-DP23 and E3FA-TP12engineered for superlative object detection in demanding industrial settings. With polished precision, these sensors feature advanced Red LED technology for unrivaled accuracy. The E3FA-DP23 offers diffuse sensing up to 300 mm, while the E3FA-TP12 through-beam excels to 2 m. Experience instant checkout with easy M18 mounting and robust IP67-rated housing. Dont miss outget it now for premium automation, assured with powerful protection features and reliable performance every time.

Extraordinary Features & Versatile Applications

The OMRON PHOTOELECTRIC SENSOR E3FA series dazzles with its adjustable sensitivity and LED indicator, ensuring superior detection accuracy. Its compact, IP67-rated build withstands harsh environments, making it perfect for conveyor systems, automated packaging, and high-precision position sensing. This sensor excels across industrial automation floors, adapting effortlessly to mounting surfaces such as panels or brackets. Ideal for logistics, material handling, and object positioning tasks, its polished versatility addresses a broad spectrum of industrial requirements.

Packaging, Logistics & Ordering Information

OMRONs sensors are delivered in robust, secure packaging designed to maintain product integrity during worldwide logistics. Each order is processed efficiently, and purchase orders are managed with care for prompt dispatch from Chinas top FOB ports. Secure shipping options are available to ensure quick and safe delivery. Sample units are provided upon request to enable hands-on validation before large-scale procurement. Every shipment is supported by comprehensive tracking for peace of mind throughout the supply chain journey.

FAQs of OMRON PHOTOELECTRIC SENSOR E3FA-DP23, E3FA-TP12:

Q: How do I install the OMRON PHOTOELECTRIC SENSOR E3FA-DP23 or E3FA-TP12?

A: Installation is simple, with options for M18 threaded, panel, or bracket mounting. Follow the provided wiring and connection guidelines for rapid integration into your automation system.

Q: What is the main benefit of using the E3FA series in automation applications?

A: The E3FA series offers high precision and adjustable sensitivity, ensuring robust object detection and position sensing even in challenging environments. Its durability and protection features provide reliable, maintenance-free operation.

Q: What surfaces or applications are compatible with these sensors?

A: The E3FA sensors adapt to various industrial surfaces such as machine panels and brackets, and excel in packaging lines, conveyor automation, material handling, and manufacturing environments.

Q: Where are the products shipped from, and is secure shipping guaranteed?

A: Products are shipped directly from Chinas major FOB ports using secure, robust packaging and reliable logistics partners, ensuring safe arrival at your destination.

Q: Is a sample available before placing a bulk purchase order?

A: Yes, samples of the E3FA series are available upon request to allow quality inspection and performance evaluation before large orders are finalized.

Q: What process should I follow to initiate a purchase order?

A: Contact the supplier or authorized trader to request a quotation, confirm specifications, and formalize the purchase order. Secure checkout and logistics arrangements will follow promptly.
