OMRON PHOTOELECTRIC SENSOR,E3FA-DN13

OMRON PHOTOELECTRIC SENSOR,E3FA-DN13 Specification

Operating Temperature
-25C to +55C (no icing or condensation)

IP Rating
IP67

Response Time
1 ms

Mounting Type
Panel mounting, M18 threaded

Sensitivity
Adjustable via potentiometer

Interface
Cable 3-wire (brown/blue/black)

Features
Compact size, easy installation, highly visible red LED indicator

Cable Length
2 meters fixed cable

Application
Industrial automation, conveyor systems

Wireless
No, wired connection

Measurement Range
Detection distance: 100 mm (white paper, standard)

Sensor Type
Diffuse-reflective Photoelectric Sensor

Signal Type
Discrete, ON/OFF signal

Power Consumption
25 mA (no load)

Product Type
Photoelectric Sensor

Material
Plastic housing

Input
10 to 30 VDC

Output
NPN, Normally Open (NO)

Function
Diffuse-reflective, NPN output

Usage
Object detection, automation systems

Accuracy
High repeatability (0.1 mm typ.)

Resolution
Precise switching, suitable for small objects

Voltage
Operating Voltage: 10-30 VDC

Weight
Approx. 70g (with 2m cable)

Protection Circuit
Reverse polarity protection, output short-circuit protection

Case Dimensions
M18 x 50 mm

Adjustment
Sensitivity adjustment control

Delay Functions
No built-in delay

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude, 2 hrs each in X, Y, and Z directions

LED Operation Indicator
Operation indicator (orange), stability indicator (green)

Shock Resistance
500 m/s² (approx. 50G), 3 times each in X, Y, and Z directions

Light Source
Red LED (660 nm)

Short-circuit Protection
Yes

Ambient Light Immunity
Ambient illumination: Incandescent lamp: 3,000 lx max., Sunlight: 10,000 lx max.

Connector Type
Pre-wired (cable type), no connector

Control Output Current
Max. 100 mA at 30 VDC

About OMRON PHOTOELECTRIC SENSOR,E3FA-DN13

Explore the supreme precision of the OMRON PHOTOELECTRIC SENSOR, E3FA-DN13-crafted for rarefied industrial environments and object detection with ineffable reliability. Featuring a top-grade red LED (660 nm) light source, advanced ambient light immunity, and supreme shock and vibration resistance, it delivers high repeatability (0.1 mm typ.) and precise switching, even on small objects. With short-circuit protection, IP67 rating, adjustable sensitivity, and easy-to-mount compact design, this sensor empowers automation at the lowest price. The pre-wired 2-meter cable ensures secure connections, making it ideal for varied industrial applications.

Supreme Features for Industrial Excellence

The OMRON PHOTOELECTRIC SENSOR E3FA-DN13 boasts a compact, robust design and rarefied detection accuracy, making it a top choice for object detection and automation systems. With adjustable sensitivity, it suits complex conveyor environments and automated machinery. Used by top-tier industries, its high sensor repeatability and panel-mount versatility enable efficient integration. Highly visible indicators, IP67 protection, and rapid response time make this machine invaluable across manufacturing, packaging, and sorting applications.

Prompt Delivery and Reliable Packaging at the Lowest Price

Your OMRON PHOTOELECTRIC SENSOR E3FA-DN13 is delivered promptly to meet urgent automation needs, serving both the domestic market and global clients. Packaging is thoughtfully designed to ensure supreme protection and product integrity in transit. Traders, suppliers, and wholesalers from China are committed to delivering sensors at the lowest price, helping streamline your purchasing process. The sensor is exported mainly to industrial hubs worldwide, ensuring reliable availability for all your automation requirements.

FAQ's of OMRON PHOTOELECTRIC SENSOR,E3FA-DN13:

Q: How does the E3FA-DN13 photoelectric sensor ensure accurate object detection?

A: The E3FA-DN13 uses a precise red LED light source combined with adjustable sensitivity to detect objects with high repeatability (0.1 mm typical), ensuring accuracy even with small or varied targets.

Q: What application areas are ideal for the OMRON E3FA-DN13 sensor?

A: This sensor is suitable for industrial automation, conveyor systems, manufacturing lines, and other environments requiring reliable ON/OFF object detection with rapid response and compact mounting.

Q: Where can the E3FA-DN13 be installed for optimal performance?

A: The sensor features panel mounting with an M18 threaded design, allowing secure installation in machinery, conveyors, or automated assembly lines needing robust object detection.

Q: What protection and safety features does the sensor offer during operation?

A: Equipped with IP67 water resistance, reverse polarity, output short-circuit protection, and high shock/vibration resistance, the sensor delivers safe and reliable performance in tough industrial conditions.

Q: What is the process for adjusting the sensitivity of the E3FA-DN13?

A: Sensitivity can be fine-tuned using the built-in potentiometer control, allowing users to optimize detection for specific object sizes and surface colors.

Q: When is the best time to use a diffuse-reflective photoelectric sensor in automation workflow?

A: Diffuse-reflective sensors like the E3FA-DN13 are ideal when precise detection of varying sizes or colored objects is needed, especially on conveyor lines or rapid sorting processes.
