OMRON PHOTOELECTRIC SENSOR 12 TO 24VDC, E3ZG-D67

OMRON PHOTOELECTRIC SENSOR 12 TO 24VDC, E3ZG-D67 Specification

Cable Length
2 m (Standard)

Response Time
1 ms max.

Sensor Type
Diffuse Reflective

Interface
Pre-wired cable

Application
Detection of objects and materials on conveyer systems, packaging, automation lines

Features
Compact size, reverse polarity protection, short-circuit protection, bright LED indicators

Power Consumption
30 mA

Signal Type
Digital (On/Off, transistor output)

Mounting Type
Panel or DIN-rail mounting

Sensitivity
Adjustable (via potentiometer)

Wireless
No

Operating Temperature
-25 to +55 C

IP Rating
IP67

Measurement Range
Up to 500 mm (depending on model configuration)

Product Type
Photoelectric Sensor

Material
PBT (Polybutylene Terephthalate)

Input
12 to 24V DC

Output
NPN/PNP Output (switch-selectable model available)

Function
Presence Detection

Usage
Industrial Automation

Accuracy
High (Factory-calibrated, precise detection)

Resolution
1 mm (typical for object size detection)

Voltage
12 to 24V DC

Weight
Approx. 50 g

Operating Humidity
35% to 85% RH (non-condensing)

Housing Size
31 x 11 x 20 mm

Control Output
300 mA max (at 30V DC)

Connection Method
2 m pre-wired cable

Light Source
Red LED (660 nm wavelength)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude for 2 hours in X, Y, and Z directions

Shock Resistance
500 m/s2 for 3 times in X, Y, and Z directions

Series
E3ZG-D67

Compliance
CE, RoHS

Protection Circuitry
Reverse polarity and surge protection

Storage Temperature
-40 to +70 C

About OMRON PHOTOELECTRIC SENSOR 12 TO 24VDC, E3ZG-D67

Order Today the illustrious OMRON PHOTOELECTRIC SENSOR 12 TO 24VDC, E3ZG-D67an exceptional solution featured for industrial automation professionals. Renowned for its premier accuracy and rare detection capabilities, this triumphant sensor boasts a factory-calibrated red LED light source (660 nm), detection range up to 500 mm, and selectable NPN/PNP outputs. Its compact 31 x 11 x 20 mm housing ensures easy installation, while CE and RoHS compliance highlight its superior build. Benefit from robust vibration and shock resistance, adjustable sensitivity, reverse polarity, and surge protection for consistent, reliable operations. Secure yours from a trusted China supplier, trader, or wholesaler.

Superior Performance for Industrial Automation

The OMRON PHOTOELECTRIC SENSOR 12 TO 24VDC, E3ZG-D67 exemplifies exceptional versatility in presence detection across industrial environments. Ideal for use on conveyor systems, packaging lines, and automated processes, it incorporates advanced features like a compact housing, reverse polarity protection, and bright LED indicators. This diffuse reflective sensor offers highly precise (1 mm resolution) detection with adjustable sensitivity, ensuring robust performance for a range of materials and applications.

Dependable Supply, Prompt Shipment, Flexible Payment

Our supply chain guarantees shipped goods at a competitive rate for the E3ZG-D67. Sample units are available for evaluation before executing a bulk purchase order. We ensure rapid dispatch and reliable availability to meet urgent industrial requirements. Favorable payment terms further streamline your procurement process, providing a seamless purchasing experience for traders and wholesalers seeking the best in photoelectric sensing technology.

FAQs of OMRON PHOTOELECTRIC SENSOR 12 TO 24VDC, E3ZG-D67:

Q: How does the OMRON E3ZG-D67 sensor operate in industrial environments?

A: The E3ZG-D67 utilizes a diffuse reflective red LED light source to detect the presence of objects on conveyor systems and automated lines, making it ideal for industrial automation use.

Q: What are the key benefits of the E3ZG-D67s compact design and protection features?

A: Its compact 31 x 11 x 20 mm housing allows for effortless installation even in tight spaces, while features like reverse polarity and surge protection provide safe, reliable operation.

Q: Where can this sensor be mounted, and what is the connection method?

A: The E3ZG-D67 can be mounted on panels or DIN-rails, using the included standard 2 m pre-wired cable for straightforward, durable integration into automation systems.

Q: What payment terms are available for purchasing the E3ZG-D67 sensor?

A: We offer flexible payment options, allowing buyers to settle according to agreed-upon terms following a purchase order, facilitating smooth transactions.

Q: What is the measurement range and detection precision of the E3ZG-D67 sensor?

A: This sensor detects objects within a range of up to 500 mm, with a typical detection resolution of 1 mm for high-accuracy presence detection in various applications.
