OMRON, PHOTOELECTRIC SENSOR 10 TO 30VDC, E3FA-RP21

OMRON, PHOTOELECTRIC SENSOR 10 TO 30VDC, E3FA-RP21 Specification

Sensor Type
Retro-reflective

Operating Temperature
-25C to +55C

Application
Industrial Automation, Conveyor Systems, Packaging, Material Handling

IP Rating
IP67

Sensitivity
Adjustable

Interface
Cable

Mounting Type
Through-hole, Bracket Mount

Response Time
1 ms

Wireless
No

Cable Length
2 meters

Power Consumption
Max. 30 mA

Measurement Range
Up to 4 meters (with reflector)

Signal Type
PNP

Features
Compact design, Red LED, Easy alignment, Short-circuit protection

Product Type
Photoelectric Sensor

Material
Plastic Housing

Input
10 to 30 VDC

Output
PNP, NO/NC Selectable

Function
Retro-reflective

Usage
Object Detection

Accuracy
High

Voltage
10 to 30 VDC

Weight
Approx. 80g

Standards Compliance
CE, RoHS

Indicator
LED Output Indicator

Light Source
Red LED (660 nm)

Frequency
500 Hz switching frequency

Ambient Humidity
35% to 85% RH (non-condensing)

Enclosure Material
PBT (Polybutylene Terephthalate)

Protection Circuit
Reverse polarity and surge protection

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Reflector Type
E39-R1 or equivalent

Housing Color
Black

Storage Temperature
-30C to +70C

Connection Method
Pre-wired cable

Shock Resistance
500 m/s (approx. 50G), 3 times each in X, Y, Z directions

About OMRON, PHOTOELECTRIC SENSOR 10 TO 30VDC, E3FA-RP21

Jump on the opportunity to purchase the superlative OMRON PHOTOELECTRIC SENSOR E3FA-RP21, designed for prime performance in enlightened automation environments. Reserve this retro-reflective sensor, equipped with a high-accuracy Red LED (660 nm) light source, and benefit from a resilient PBT enclosure. This sensor delivers a quick response time (1 ms), adjustable sensitivity, and easy alignment for optimal usage. With CE and RoHS compliance, reverse polarity and surge protection, and IP67 rating, it is built for enduring stability across challenging industrial settings. Available from China suppliers, traders, and wholesalers.

Versatile Applications and Usage

OMRON E3FA-RP21 PHOTOELECTRIC SENSOR is ideal for media such as industrial automation, packaging lines, conveyor systems, and material handling. This sensor excels at object detection in high-accuracy environments, providing reliable performance across a array of industrial applications. Its usage spans factory automation and logistics, ensuring safety, operational efficiency, and quality control in both commercial and industrial settings.

Packaging Details, Export Markets & Sample Policy

Each shipment of the E3FA-RP21 sensor is meticulously packaged to ensure prime protection during transit. Main export markets include Asia, Europe, and North America. Interested buyers may estimate their outlay according to the prevailing asking price, with sample policies available for preliminary evaluation. Contact suppliers to discuss the sample process, pricing options, and international shipping details tailored to your procurement needs.

FAQ's of OMRON, PHOTOELECTRIC SENSOR 10 TO 30VDC, E3FA-RP21:

Q: How does the OMRON E3FA-RP21 enhance object detection in industrial automation?

A: Its high accuracy, fast response time, adjustable sensitivity, and reliable retro-reflective function make this sensor a prime choice for streamlined and safe industrial automation workflows.

Q: What environments is the E3FA-RP21 sensor best suited for?

A: It is optimized for commercial and industrial settings, including packaging lines, conveyor systems, and material handling operations requiring reliable detection and stability.

Q: Where can I purchase or reserve the E3FA-RP21 sensor?

A: You can acquire or reserve this model through authorized suppliers, traders, and wholesalers in China, who offer flexible purchasing options and support international exports.

Q: What is the process for requesting a sample of the E3FA-RP21?

A: Prospective buyers should contact the supplier to inquire about sample policy, estimated outlay, and the necessary steps to receive a trial unit before a larger purchase.

Q: What are the key benefits of using this sensor in material handling applications?

A: The E3FA-RP21 offers dependable detection, easy alignment, and robust protection features, ensuring safe and efficient material handling with reduced downtime.

Q: When is it necessary to use a reflector with the E3FA-RP21 sensor?

A: A reflector such as the E39-R1, or its equivalent, is required for proper retro-reflective operation and to achieve optimal measurement range in object detection tasks.
