Omron Photoelectric Sensor 10 TO 30VDC, E3FA-DP12,E3FA-BP22

Omron Photoelectric Sensor 10 TO 30VDC, E3FA-DP12,E3FA-BP22 Specification

Operating Temperature
-25C to +55C Celsius (oC)

Application
Industrial automation, packaging, textile, assembly lines

Features
Compact design, LED indicator, reverse polarity protection

Measurement Range
Detection distance: 100mm (adjustable)

IP Rating
IP67

Interface
2-wire or 3-wire connection

Signal Type
DC electronic output

Mounting Type
Panel or surface mounting

Sensor Type
Diffuse Reflective Photoelectric Sensor

Sensitivity
Adjustable sensitivity

Cable Length
2 meters Meter (m)

Wireless
No

Product Type
Photoelectric Sensor

Material
Plastic

Input
10-30V DC

Output
PNP, NO/NC selectable

Function
Detection of objects using diffuse reflective technology

Usage
Object detection, automation, presence sensing

Resolution
Up to 1 mm

Voltage
10-30V DC Volt (v)

Weight
Approx. 60g Grams (g)

Ambient Humidity
35% to 85% RH

Polarity Protection
Available

Housing Material
ABS

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Indicator
Operation indicator (red LED)

Light Source
Red LED (660nm)

Model Number
E3FA-DP12

Connection Method
Pre-wired cable

Shock Resistance
500 m/s², 3 times each in X, Y, Z directions

Storage Temperature
-40°C to +70°C

Short-circuit Protection
Yes

Omron Photoelectric Sensor 10 TO 30VDC, E3FA-DP12,E3FA-BP22 Trade Information

Minimum Order Quantity
10 Number

Delivery Time
5-10 Days

About Omron Photoelectric Sensor 10 TO 30VDC, E3FA-DP12,E3FA-BP22

Experience the elite capabilities of the OMRON PHOTOELECTRIC SENSOR E3FA-DP12, a cost-effective and hot-selling solution for precision automation tasks. This potent, new model showcases a polished ABS housing, red LED (660nm) light source, and robust resistance to vibration and shock. Built for demanding industrial settings, its compact design and high-accuracy detection make it a standout choice. With adjustable sensitivity and reliable NO/NC output, it seamlessly integrates into packaging, textile, and assembly lines, delivering dependable object detection with minimal power consumption and advanced safety protections.

Optimized Surface Application & Flexible Usage Directions

The OMRON PHOTOELECTRIC SENSOR E3FA-DP12 is engineered for versatile surface and panel or surface mounting in industrial environments. For optimal results, align the sensor toward the target object within its 100mm adjustable range. This high-performance sensor is ideal for continuous, automated, and presence sensing use in packaging, assembly, and textile processes, providing consistent precision and reliability on various material surfaces.

Sample Availability, Supply Capacity & Secure Delivery

OMRON E3FA-DP12 samples are readily available for initial evaluation and testing. Backed by high supply ability, orders are managed with professional packaging and secure shipping services, ensuring prompt and safe delivery. This hot-selling sensor comes at a competitive sale price and is supported by internationally recognized certifications, offering buyers peace of mind and market confidence for industrial applications.

FAQs of OMRON PHOTOELECTRIC SENSOR 10 30VDC, E3FA-DP12:

Q: How do I install the OMRON PHOTOELECTRIC SENSOR E3FA-DP12 in my automation system?

A: The E3FA-DP12 can be Surface or panel-mounted using its compact design. Simply connect via its 2-meter pre-wired cable (2- or 3-wire setup), align with the target object, and adjust sensitivity as needed for optimal detection.

Q: What surfaces and applications are suitable for E3FA-DP12 usage?

A: Engineered for object detection, presence sensing, and automation, this sensor performs exceptionally on packaging lines, textile manufacturing, and assembly stations. It adapts well to various material surfaces due to its diffuse reflective technology.

Q: When should I use this photoelectric sensor over other types of sensors?

A: Choose the E3FA-DP12 when you require high-accuracy, reliable switching within a 100mm adjustable range, especially for applications needing compact, robust, and energy-efficient sensors with advanced protections.

Q: Where is the best place to purchase the OMRON E3FA-DP12 sensor?

A: You can source this sensor through authorized suppliers, traders, wholesalers, or directly from manufacturers in China, ensuring product authenticity and access to support.

Q: What are the main benefits of using the OMRON E3FA-DP12 sensor?

A: This sensor offers cost-effectiveness, elite performance, high sensitivity, and potent reliability for industrial automation, all in a polished, compact body with built-in safety features such as polarity and short-circuit protection.
