OMRON, LIMIT SWITCH , D4C-1202

OMRON, LIMIT SWITCH , D4C-1202 Specification

Temperature Range
-10C to +80C

Protection Level
IP67

Max. Current
5A at 125/250VAC

Number of Module
Single

Automation Grade
Industrial

Finish Type
Corrosion-proof coating

Circuit Type
Snap Action

Rated Voltage
125/250VAC, 8A

Mechanical Life
10,000,000 operations min.

Response Time
Within 20 ms

Product Type
Limit Switch

Material
Housing: Zinc Die-cast, Actuator: Resin/Stainless Steel

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. (initial)

Max. Voltage
24 Volt (V)

Operating Temperature
-10C to +80C

Stoke
2 mm (Pretravel)

Size
28 x 16 x 50 mm (approx.)

Color
BLACK

Weight
Approx. 80g

Mounting Type
Panel/Body mount

Current Rating
8A

No Of Poles
1 Pole (SPDT)

Actuator Type
Plunger

Ambient Humidity
35% to 95% RH

Standards
CE, UL, CCC, EN60947-5-1

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Pre-travel
2 mm max.

Shock Resistance
1000 m/s²

Switching Frequency
120 cycles/min (mechanical)

Cable Entry
M12 Threaded Conduit

Overtravel
5 mm min.

Mounting Hole Size
4.2 mm

Degree of Protection (IEC Standard)
IP67

Enclosure Material
Zinc Die-cast

Release Force
0.25 N min.

Differential Travel
0.2 mm max.

Contact Form
SPDT (1NO+1NC)

OMRON, LIMIT SWITCH , D4C-1202 Trade Information

Minimum Order Quantity
10 Number

Supply Ability
Number

Delivery Time
Days

Sample Available
Yes

About OMRON, LIMIT SWITCH , D4C-1202

Discover the unrivaled performance of the OMRON LIMIT SWITCH D4C-1202, an affordable yet magnificent solution designed for today's trending automation needs. Crafted with a zinc die-cast housing and a corrosion-proof finish, this device ensures outstanding durability and reliability. With a plunger actuator, SPDT contact form, and an impressive mechanical lifespan exceeding 10 million operations, it's among the finest in its class. Grab yours now and enhance your automation systems with a switch that boasts IP67 protection, rapid response time, and conformity to global standards such as CE, UL, and CCC.

Versatile Application and Competitive Advantages

The OMRON D4C-1202 Limit Switch excels in industrial automation applications, whether panel or body mounting is required. Its corrosion-resistant coating, robust IP67 protection, and compatibility with multiple international standards make it an unrivaled choice for demanding environments. This device's zinc die-cast housing ensures longevity on varied surfaces, while its rapid snap action enhances safety and operational efficiency. Designed for seamless integration, it's one of the finest switches for cost-effective and reliable control.

Domestic Market Presence and Supply Logistic Excellence

Serving the main domestic market across Japan and beyond, the OMRON LIMIT SWITCH D4C-1202 guarantees consistent supply ability and transparent sample policy. With efficient freight and transportation solutions, customers benefit from reduced expenditure and dependable, timely product delivery. The supplier and wholesaler partnerships enhance market reach, ensuring enterprises receive both quality assurance and logistical support. Simplified processes and clear communication contribute to a trustworthy buying and shipping experience in industrial supply.

FAQ's of OMRON, LIMIT SWITCH , D4C-1202:

Q: How can the OMRON LIMIT SWITCH D4C-1202 be installed within automation systems?

A: The OMRON D4C-1202 is designed for easy panel or body mounting. Its compact form and M12 threaded cable entry simplify integration, while the mounting holes ensure secure and precise installation in a variety of industrial settings.

Q: What primary advantages does the D4C-1202 offer over other limit switches?

A: This switch stands out for its corrosion-proof zinc die-cast housing, IP67 ingress protection, high mechanical life, and compliance with CE, UL, and CCC standards. These attributes guarantee superior durability, reliability, and safety in challenging environments.

Q: When is the D4C-1202 limit switch typically used?

A: It is commonly used in industrial automation applications where reliability and sustained performance are critical, such as in machinery, conveyor systems, and process equipment requiring precise position detection.

Q: Where can I apply the OMRON LIMIT SWITCH D4C-1202?

A: Its robust design makes it suitable for installation on various equipment surfaces exposed to vibration, moisture, and dust-particularly in industrial facilities, factories, and automated production lines.

Q: What is the process for obtaining samples and arranging transportation?

A: Suppliers follow a clear sample policy and provide logistic support throughout the shipping process. Efficient freight options ensure economical expenditure, and products are delivered securely via reliable transportation services.

Q: What are the benefits of using a snap action circuit in the D4C-1202?

A: The snap action circuit enables fast and consistent switching performance, reducing wear and preventing contact bounce. This ensures accurate signal transmission and extends the life of the device in heavy-duty operation.
