Omron Limit Switch, Wlca12-g, Wlca12-2ld

Omron Limit Switch, Wlca12-g, Wlca12-2ld Specification

Number of Module
Single

Temperature Range
-10C to +80C Celsius (oC)

Rated Voltage
250V AC / 125V DC Volt (V)

Protection Level
IP67

Finish Type
Painted

Automation Grade
Industrial

Circuit Type
SPDT (Snap Action, Double Throw)

Product Type
Limit Switch

Material
Zinc Diecast (Housing), Stainless Steel (Actuator)

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. (initial) Milliohm (m)

Max. Voltage
250V AC/DC Volt (V)

Operating Temperature
-10C to +80C Celsius (oC)

Stoke
30 mm (approximate total lever movement)

Size
Approx. 65 x 40 x 37 mm (excluding actuator)

Color
Silver/Black

Weight
Approx. 330 g Grams (g)

Mounting Type
Panel Mount, Screw Mount

Current Rating
10A at 250VAC

No Of Poles
2

Actuator Type
Adjustable Roller Lever

Electrical Life
500,000 operations min. (at rated load)

Body Construction
Double insulation

Terminal Type
Screw terminal

Contact Form
1a+1b (NO+NC)

Shock Resistance
1,000 m/s2 (100G) max.

Switch Type
Snap Action

Application
General industrial machinery, safety interlocks, automation systems

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Standards Compliance
CE, CCC, UL, RoHS

Omron Limit Switch, Wlca12-g, Wlca12-2ld Trade Information

Minimum Order Quantity
30 Number

Delivery Time
5-10 Days

About Omron Limit Switch, Wlca12-g, Wlca12-2ld

The OMRON LIMIT SWITCH, WLCA12-G, WLCA12-2LD comes highly recommended for industrial automation, offering gilt-edged performance with a meritorious track record in reliability. This adjustable roller lever, snap-action switch boasts a lofty mechanical life of 10,000,000 operations and an electrical life exceeding 500,000 cycles at rated load. Clearance pricing is availabletake advantage now! Compliant with CE, CCC, UL, and RoHS standards, it ensures robust protection (IP67) and resists both shock and vibration. Its durable zinc diecast housing and stainless steel actuator guarantee longevity, while double insulation adds safety. Secure this premium-grade switch for your plant today.

Direction of Use and Application Areas

Install the WLCA12-G, WLCA12-2LD limit switch with panel or screw mounting on general industrial machinery, safety interlocks, or automation systems. Its adjustable roller lever allows for precise position detection, ensuring optimal functioning in plant environments. This switch excels in both light-duty and rigorous plant applications, guiding automated processes and equipment workflows safely. Suitable for production lines and equipment interlocks, enhancing quality control and plant safety with gilt-edged reliability.

Packaging Details and Delivery Value

Packaged with utmost care to ensure secure shipping, the OMRON LIMIT SWITCH comes in robust cartons tailored to protect its gilt-edged finish and key components during transit. Available at the lowest price to increase your market value, it can be delivered across the main domestic market in China. Benefit from swift delivery timeframes and dependable trading from trusted suppliers, wholesalers, and tradersguaranteeing your purchase arrives undamaged for immediate installation.

FAQs of OMRON LIMIT SWITCH, WLCA12-G, WLCA12-2LD:

Q: How do I install the OMRON LIMIT SWITCH, WLCA12-G, WLCA12-2LD in my automation system?

A: Installation is straightforward by using the panel or screw mount options provided. Connect wiring to the screw terminals, ensure the adjustable roller lever is aligned with the target, and tighten all fastenings as per guidelines. Double insulation ensures added safety during installation.

Q: What applications are best suited for this limit switch?

A: This switch is ideal for general industrial machinery, plant safety interlocks, and automation systems, especially where reliability and high operational cycles are important. Its robust build and high protection level make it fit for demanding environments.

Q: Where can I purchase the WLCA12-G, WLCA12-2LD at the lowest price?

A: You can acquire this highly recommended limit switch from authorized wholesalers, suppliers, and traders in China, taking advantage of clearance offers to boost your market value.

Q: What is the process for ensuring secure shipping and proper packaging?

A: The limit switch is shipped in sturdy cartons with secure packaging to protect against transit damage. Suppliers in the main domestic market adhere to robust shipping standards, ensuring your product arrives safely.

Q: What are the benefits of using a Gilt-edged, IP67-rated limit switch?

A: An IP67-rated, gilt-edged switch guarantees high resistance to dust and moisture, reduces downtime from environmental damage, and delivers long-term reliability. These features are meritorious in industrial operations, providing dependable safety and automation control.

Q: When should the limit switchs electrical and mechanical life be considered for replacement?

A: With an electrical life of at least 500,000 operations and a mechanical life exceeding 10,000,000 cycles, routine monitoring or replacement is advised only after extensive usage or if position-accuracy begins to fade in demanding environments.
