OMRON LIMIT SWITCH , WLCA12

OMRON LIMIT SWITCH , WLCA12 Specification

Mechanical Life
10,000,000 operations min.

Finish Type
Matte

Temperature Range
-10C to +80C

Response Time
20 ms max.

Protection Level
IP67

Max. Current
10A (inductive), 20A (resistive) at 250VAC

Circuit Type
1NC/1NO, Double-break

Rated Voltage
250 VAC, 250 VDC

Number of Module
Single

Automation Grade
Industrial

Product Type
Limit Switch

Material
Die-cast zinc and resin

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. (initial value)

Max. Voltage
500V AC/DC

Operating Temperature
-10C to +80C

Stoke
Full stroke: 30 mm

Size
Body: Approx. 76 mm x 28 mm x 32 mm

Color
Gray (Body), Black (Head)

Weight
Approx. 280g

Mounting Type
Panel Mount / Screw Mount

Current Rating
10A

No Of Poles
2

Wire Entry
Gland type

Actuator Type
Sealed roller lever

Sealing
Oil-tight, Dust-tight

Terminal Type
Screw terminals

Electrical Life
500,000 operations min.

Shock Resistance
1,000 m/s2 (approx. 100G)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Operating Force
14.7N max.

Contact Form
SPDT (Double Throw)

About OMRON LIMIT SWITCH , WLCA12

Take advantage of one of the most formidable limit switches on the marketthe OMRON WLCA12. Its excellent oil-tight and dust-tight design ensures unbeatable durability, powered by a sealed roller lever actuator and robust die-cast zinc construction. With a scarce stock, act swiftly and shop now to secure your unit. Boasting a formidable electrical life of 500,000 operations and IP67 protection, this switch meets even the most demanding industrial requirements. An excellent choice for panel or screw mounting, it supports a high current rating and ensures operational reliability in any setting.

Versatile Usage and Special Features

The OMRON LIMIT SWITCH WLCA12 is engineered for demanding industrial automation, suitable for production lines, machinery, and assembly plants. Its sealed roller lever actuator delivers precision and consistency, while the oil- and dust-tight sealing enhances lifespan. The switchs sturdy die-cast zinc body withstands harsh plant environments, supporting both panel and screw mounting for flexible installation. With a wide temperature range and excellent shock/vibration resistance, this switch excels in robust, repetitive applications requiring reliability and safety.

Export Markets, Packaging, and Certifications

Supplied by leading exporters, traders and wholesalers from Japan, the OMRON WLCA12 is distributed globally, especially to industrial hubs and automation markets. Our logistics ensure each switch reaches you in secure, damage-resistant packaging, optimizing outlay and transit efficiency. Shipped from well-established FOB ports, every unit meets strict international certifications, guaranteeing quality and compliance with required standards. Designed to meet the needs of global buyers, the WLCA12 arrives ready for seamless integration into your automation systems.

FAQs of OMRON LIMIT SWITCH , WLCA12:

Q: How does the OMRON WLCA12 ensure reliability in industrial settings?

A: The WLCA12 boasts oil-tight and dust-tight sealing, robust materials, and a mechanical life of at least 10,000,000 operations, providing consistent, long-term operation even under harsh industrial conditions.

Q: What applications is the OMRON LIMIT SWITCH WLCA12 best suited for?

A: It is ideal for automation plants, machinery, assembly lines, and equipment where precise limit control and durability are required, thanks to its superior shock, vibration resistance, and wide temperature operating range.

Q: Where is the OMRON WLCA12 manufactured and exported from?

A: This model is manufactured in Japan and shipped globally through established FOB ports, distributed by trusted suppliers, traders, and wholesalers with international reach.

Q: What are the key features that set the WLCA12 apart from other limit switches?

A: The WLCA12 features a sealed roller lever, double-break contacts, IP67 protection, versatile mounting options, and high-current rating, along with oil- and dust-tight sealing for superior durability.

Q: How is the WLCA12 packaged and delivered to buyers?

A: Each unit is packaged securely using robust materials to prevent damage during transportation. Efficient logistics ensure prompt, safe delivery to buyers, optimizing both packaging integrity and outlay efficiency.
