OMRON LIMIT SWITCH, D4N-6A32

OMRON LIMIT SWITCH, D4N-6A32 Specification

Mechanical Life
30,000,000 operations min.

Protection Level
IP67

Temperature Range
-10C to +80C

Number of Module
Single

Max. Current
10A (AC-15, 250VAC; DC-13, 250VDC)

Finish Type
Matte

Rated Voltage
500 VAC, 250 VDC

Response Time
Instantaneous (snap action)

Automation Grade
Automatic

Circuit Type
SPDT (Double Break)

Product Type
Limit Switch

Material
Plastic housing, Metal actuator

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. (initial) at 0.1 A, 24 VDC

Max. Voltage
500 VAC (Ui)

Operating Temperature
-10C to +80C (with no icing)

Stoke
18 mm (Plunger full stroke)

Size
30 mm 29 mm 65 mm (approx.)

Color
Black body, red actuator

Weight
Approx. 110 g

Mounting Type
Panel Mount

Current Rating
10A

No Of Poles
2

Operating Force
18 N max.

Wire Connection
Screw terminal

Standards Compliance
IEC/EN60947-5-1, UL508, CSA C22.2

Actuator Type
Spring plunger

Electrical Life
500,000 operations min.

Vibration Resistance
Malfunction: 10 to 55 Hz, 1.5 mm double amplitude

Body Style
Rectangular, Compact

Shock Resistance
Malfunction: 300 m/s2 (approx. 30G)

Contact Material
Silver alloy

Contact Configuration
2NC/2NO (snap action)

About OMRON LIMIT SWITCH, D4N-6A32

Unlock the potential of superior automation with the new release OMRON LIMIT SWITCH, D4N-6A32 - a must-have for those seeking formidable performance in industrial control. Featuring a grandiose 18 N max. operating force, a ravishing 2NC/2NO snap action configuration, and fortified with IEC/EN60947-5-1, UL508, and CSA C22.2 standards, this switch ensures reliability. Designed for endurance with 30,000,000 mechanical and 500,000 electrical operations minimum, the compact rectangular body is crafted from resilient plastic and metal to endure the most demanding environments. Elevate safety and performance with IP67 protection and a striking red actuator.

Precision and Versatility in Industrial Applications

The OMRON LIMIT SWITCH, D4N-6A32 is ideal for automation, conveyor belts, and assembly lines. Featuring a robust plastic housing and durable metal actuator, it withstands grandiose operational stresses while delivering precise, instantaneous responses. Special features include its compact rectangular design, IP67-rated protection against dust and water, and snap action double-break circuitry, ensuring formidable and safe operation across demanding environments.

Global Supply, Trusted Certifications, and Secure Delivery

As a supplier, trader, and wholesaler from China, we maintain a high supply ability of the OMRON LIMIT SWITCH, D4N-6A32 to meet growing export market demand. Certified under prestigious standards like IEC/EN60947-5-1, UL508, and CSA C22.2, each unit is meticulously packed for international freight, ensuring safe delivery. Competitive rates, reliable packaging, and swift dispatch services keep your operations running efficiently.

FAQ's of OMRON LIMIT SWITCH, D4N-6A32:

Q: How do you install the OMRON LIMIT SWITCH, D4N-6A32?

A: Installation is straightforward with a panel mount design and screw terminals for secure wire connections. Follow the provided instructions and adhere to local safety regulations.

Q: What special features enhance the switch's durability and performance?

A: The D4N-6A32 offers a high IP67 protection level, robust plastic housing, metal actuator, and exceptional shock and vibration resistance, supporting prolonged, reliable operation.

Q: When is maintenance required for this switch?

A: Thanks to its formidable electrical and mechanical life, maintenance is infrequent, but routine inspections after heavy-duty cycles help optimize longevity.

Q: Where can the OMRON D4N-6A32 switch be used effectively?

A: It is perfect for automated machinery, assembly lines, and conveyor systems where high durability, precise operation, and safety are paramount.

Q: What are the benefits of the double-break snap action mechanism?

A: The double-break snap action circuit enables instantaneous, reliable switching, ensuring safety and consistent performance in critical automation tasks.
