OMRON LIMIT SWITCH D4C-3320

OMRON LIMIT SWITCH D4C-3320 Specification

Response Time
15 ms max.

Circuit Type
Single pole double throw (SPDT)

Protection Level
IP67

Finish Type
Matte

Automation Grade
Industrial

Mechanical Life
10,000,000 operations min.

Rated Voltage
250 VAC

Number of Module
Single

Temperature Range
-10C to +80C (No freezing)

Max. Current
5A

Product Type
Limit Switch

Material
Plastic and zinc die-cast body

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. (initial value)

Max. Voltage
250 VAC

Operating Temperature
-10C to +80C

Stoke
Short stroke

Size
Approx. 49 mm x 18 mm x 16.2 mm (LxWxH, body only)

Color
Grey/Black

Weight
Approx. 30 g

Mounting Type
Panel Mount

Current Rating
5A at 250 VAC

No Of Poles
2

Electrical Life
300,000 operations min.

Contact Form
1NO+1NC

Actuator Type
Roller Plunger

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Connection Type
Pre-wired cable

Shock Resistance
1,000 m/s2 (approx. 100G)

Application
Industrial automation systems, machine safety interlock

Switching Configuration
Snap Action

About OMRON LIMIT SWITCH D4C-3320

The OMRON LIMIT SWITCH D4C-3320 is an elite, in-demand device tailored for top-ranking performance in industrial environments. Crafted with a robust plastic and zinc die-cast body, this gorgeous, first-rate switch features a special rate for unbeatable value. Its roller plunger actuator ensures precise snap-action reliability, while the IP67 protection secures longevity even in harsh settings. With a fast 15ms response and a stunning 10,000,000-cycle mechanical life, this switch is a market favorite for automation systems worldwide.

Expert Application Versatility for Industry Leaders

The OMRON LIMIT SWITCH D4C-3320 thrives in a variety of industrial automation settings and machine safety interlock systems. Built for panel mounting, its robust design and short stroke are perfect for precision control on equipment and interlocked machinery surfaces. Its a top choice for engineers needing rapid response and elite reliability in safety-critical and high-throughput automated lines, providing safe operation across a range of environments.

Reliable Supply and Worldwide Export Excellence

OMRON LIMIT SWITCH D4C-3320 is consistently supplied at an attractive, lowest price for bulk orders. With trusted international certifications and fast delivery, it meets the highest supplier and trader standards. Our main export markets include Europe, Asia, and the Middle East, guaranteeing fulfillment and professional logistics charges. Clients rely on us for secure, certified products backed by a responsive wholesale network, ensuring every order meets elite export criteria.

FAQs of OMRON LIMIT SWITCH D4C-3320:

Q: How does the OMRON LIMIT SWITCH D4C-3320 ensure operational reliability?

A: The D4C-3320 provides reliability through its snap action mechanism, robust IP67-rated housing, and the capacity to withstand high shock and vibration, ensuring consistent switching in demanding environments.

Q: What are the main applications and benefits of using this limit switch?

A: This elite limit switch is widely used in industrial automation systems and machine safety interlocks, offering benefits like high-speed response, long electrical and mechanical life, and protection against harsh conditions, crucial for modern manufacturing setups.

Q: When should I consider installing the D4C-3320 in my system?

A: Install the D4C-3320 when you require a dependable switch for safety interlocking, position sensing, or automation tasksespecially in environments where durability, accuracy, and quick response are vital.

Q: Where can this limit switch be mounted and on what surfaces?

A: The D4C-3320 is designed for secure panel mounting on metal, composite, or rigid plastic surfaces, ensuring stable installation in machine enclosures and automation panels.

Q: What is the process for ordering and delivery of the OMRON D4C-3320?

A: Ordering is straightforward with options for wholesale, trading, or direct purchase. Delivery is swift, tailored to customer location, with the lowest price, transparent logistics charges, and certification for export compliance.

Q: How does the short stroke design benefit my automation setup?

A: The short stroke roller plunger design allows for quick actuation and minimal reset distance, making it ideal for applications demanding rapid cycling and precise position detection.
