OMRON LIMIT SWITCH,D4B-2116N

OMRON LIMIT SWITCH,D4B-2116N Specification

Rated Voltage
250 VAC

Max. Current
10A

Response Time
Instantaneous (snap action)

Circuit Type
SPDT

Finish Type
Powder Coated

Automation Grade
Industrial

Temperature Range
-10C to +80C

Protection Level
IP67

Mechanical Life
10,000,000 operations min.

Number of Module
Single

Product Type
Limit Switch

Material
Die-cast Aluminium Body, Resin Head

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. (initial value)

Max. Voltage
250 VAC

Operating Temperature
-10C to +80C (without freezing)

Stoke
22 mm (overall movement)

Size
50.8 mm x 50.8 mm x 50 mm (approx.)

Color
Grey/Black

Weight
Approx. 350 g

Mounting Type
Panel/Surface Mount

Current Rating
10A at 250 VAC

No Of Poles
2

Release Force
5 N min.

Shock Resistance
1,000 m/s2 (approx. 100 G)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Electrical Life
500,000 operations min.

Terminal Type
Screw Terminal

Operating Force
15 N max.

Contact Configuration
1NO+1NC

Ambient Humidity
35% to 95% RH

Actuator Type
Roller Plunger

Housing Material
Die-cast aluminium

About OMRON LIMIT SWITCH,D4B-2116N

Discover the new release OMRON LIMIT SWITCH, D4B-2116N-crafted to champion reliability and performance for industrial automation. With a celebrated die-cast aluminum body and resin head, this switch boasts an exceptional electrical life of 500,000 operations min. and a champion-level mechanical life of 10,000,000 operations. Perfect for rigorous applications, its robust construction ensures IP67 protection and superior vibration and shock resistance. Procure this limited-time offer now-ideal for suppliers, traders, and wholesalers seeking a dependable switch solution direct from China.

Versatile Application Areas and Outstanding Machine Features

The OMRON LIMIT SWITCH, D4B-2116N is not only perfect for industrial automation but excels in usage across conveyor systems, machinery safety panels, and factory assembly lines. Its celebrated features include a roller plunger actuator, instantaneous snap action response, and a rugged die-cast aluminum structure. Designed with precision, this switch operates reliably within a wide temperature range, and its IP67-level protection ensures longevity even in harsh environments-making it a champion choice for a spectrum of machine applications.

Payment, Packaging, and Sample Policy Details for Your Purchase

To procure the OMRON LIMIT SWITCH, D4B-2116N, simply issue a Purchase Order and take advantage of our competitive offer. All shipments are meticulously packaged in secure, tamper-proof boxes to ensure pristine condition upon arrival. Standard payment terms are available, tailored to streamline the purchasing process. For businesses interested in evaluating before large-scale procurement, samples can be shipped upon request according to our transparent sample policy. Contact us for comprehensive details and seamless order fulfillment.

FAQ's of OMRON LIMIT SWITCH,D4B-2116N:

Q: How can I order the OMRON LIMIT SWITCH, D4B-2116N for my business?

A: You can place your order by submitting a formal Purchase Order through your supplier, trader, or wholesaler channels. Once processed, your order will be prepared and shipped in secure packaging.

Q: What are the primary usage areas for this limit switch?

A: The D4B-2116N is celebrated for its versatility and is widely used in factory automation equipment, conveyor systems, and as a safety interlock in various industrial machinery.

Q: What payment terms are available when procuring this switch?

A: We offer standard payment terms which can be customized based on your company's requirements. Specifics can be discussed and agreed upon at the time of purchase.

Q: Where is the OMRON LIMIT SWITCH, D4B-2116N manufactured?

A: This model is supplied directly from China, ensuring efficient procurement chains for traders, suppliers, and wholesalers worldwide.

Q: What are the benefits of using this particular limit switch in industrial settings?

A: With a robust die-cast aluminum housing, IP67 protection, and a high mechanical life, this switch provides long-term, reliable operation even in challenging industrial environments.

Q: What is the process for obtaining a product sample?

A: To request a sample, simply contact us with your business details. Samples are shipped based on our sample policy, allowing you to evaluate the switch before committing to bulk procurement.
