OMRON GUARD LOCK SAFETY DOOR SWITCH, D4SL-NSK10-LKH,D4SL-N4QDA-D

OMRON GUARD LOCK SAFETY DOOR SWITCH, D4SL-NSK10-LKH,D4SL-N4QDA-D Specification

Rated Voltage
240 VAC / 24 VDC Volt (V)

Finish Type
Matte

Number of Module
Single

Max. Current
6A Ampere (amp)

Circuit Type
Double-Break, Slow Action

Temperature Range
-10C to +55C Celsius (oC)

Automation Grade
Automatic

Protection Level
IP67

Product Type
Guard Lock Safety Door Switch

Material
Polyamide (enclosure), Stainless Steel (actuator)

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. Milliohm (m)

Max. Voltage
250 VAC Volt (V)

Operating Temperature
-10C to +55C Celsius (oC)

Stoke
30 mm (plunger total travel)

Size
40 x 40 x 130 mm (approx.)

Color
Black & Red

Weight
Approx. 400 g Grams (g)

Mounting Type
Screw Mount

Current Rating
6A at 240 VAC

No Of Poles
2 to 4 Poles (depending on model)

Mounting Orientation
Any direction

Shock Resistance
1,000 m/s2 (approx. 100G)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Thread Size
M20 conduit entry

Operating Force
Approx. 30 N (to lock/unlock actuator)

Electrical Life
100,000 operations min.

Actuator Entry Points
4 directions

Standards Compliance
IEC/EN60947-5-1, EN1088, GS-ET-19

Release Key Type
Manual override key

Impulse Withstand Voltage (Uimp)
2.5 kV

Contact Configuration
2 NC / 1 NO (standard combination)

Ambient Humidity
35% to 85% RH (no condensation)

Rated Insulation Voltage (Ui)
250 V

Cable Entry
1 x M20 or PG13.5

Solenoid Consumption
Approx. 4.5 W at 24 VDC

Lock Type
Solenoid lock with key release

OMRON GUARD LOCK SAFETY DOOR SWITCH, D4SL-NSK10-LKH,D4SL-N4QDA-D Trade Information

Minimum Order Quantity
30 Number

Supply Ability
1000 Per Month

Delivery Time
7 Days

About OMRON GUARD LOCK SAFETY DOOR SWITCH, D4SL-NSK10-LKH,D4SL-N4QDA-D

Capitalise on superior safety with the OMRON GUARD LOCK SAFETY DOOR SWITCH, D4SL-NSK10-LKH, D4SL-N4QDA-Da true redoubtable masterpiece engineered for robust industrial protection. Deal yourself optimal value with this solenoid lock featuring IEC/EN60947-5-1 standards compliance and formidable performance. Its double-break, slow action contact system, and manual override key guarantee reliability in every automation scenario. Add to Cart now and master workplace security with equipment designed for high electrical and mechanical longevity, delivering steadfast lock integrity under demanding conditions.

Versatile Application & Enhanced Features

The OMRON GUARD LOCK SAFETY DOOR SWITCH is built for automatic use in diverse industrial automation environments. Its mounting orientation supports any direction, while four actuator entry points allow flexible installation. Trust this machines matte-finished polyamide enclosure and stainless steel actuator to perform reliably in harsh operating conditions. The standard 2 NC / 1 NO configuration and solenoid lock with key release ensure ease of operation and maintenance for every user.

Efficient Dispatch & Supply Capabilities

Benefit from Express Shipping when ordering through our China FOB Port, with prompt dispatching to keep your project timelines on track. Our supply ability caters to bulk requirements, making it easy for suppliers, traders, and wholesalers to manage their outlay. Sample policy is available for strategic evaluationcapitalise on cost-effective, reliable solutions delivered rapidly to your facility.

FAQs of OMRON GUARD LOCK SAFETY DOOR SWITCH, D4SL-NSK10-LKH,D4SL-N4QDA-D:

Q: How does the manual override key on the OMRON GUARD LOCK enhance safety operations?

A: The manual override key enables immediate manual release of the lock mechanism, ensuring rapid response during maintenance or emergencies, thereby enhancing operator safety.

Q: What are the main features that distinguish this safety door switch from standard models?

A: Its solenoid lock with key release, double-break slow action contacts, robust polyamide enclosure, IP67 protection, and compliance with IEC/EN60947-5-1 standards distinguish it as a superior choice for automated safety.

Q: Where can the OMRON GUARD LOCK SAFETY DOOR SWITCH be installed?

A: This switch can be mounted in any direction on automated machinery or safety doors, thanks to its flexible mounting orientation and multiple actuator entry points.

Q: What is the process for ordering and sampling this product from China?

A: Ordering is seamless via suppliers, traders, or wholesalers, dispatching from the China FOB Port. Sample policy is available for evaluation before committing to bulk outlay.

Q: What types of environments is this safety door switch designed for?

A: It is engineered to operate in industrial settings requiring high protection from dust, moisture, vibration, and shock, maintaining rated performance within ambient humidity and temperature ranges.
