OMRON GUARD LOCK SAFETY DOOR SWICTH, D4SL-NSK10-LK

OMRON GUARD LOCK SAFETY DOOR SWICTH, D4SL-NSK10-LK Specification

Finish Type
Matte/Industrial

Circuit Type
Snap Action Contact

Response Time
Instantaneous (Mechanical Type)

Max. Current
10A (AC-15, 240V AC)

Temperature Range
-10C to +55C, No freezing

Rated Voltage
240V AC / 24V DC

Automation Grade
Industrial / Automation

Protection Level
IP67

Number of Module
Single

Mechanical Life
1,000,000 operations min.

Product Type
Guard Lock Safety Door Switch

Material
Plastic (Body), Metal (Contact)

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
100 m max.

Max. Voltage
240V AC

Operating Temperature
-10C to +55C

Stoke
35 mm (Standard for actuator)

Size
Approx. 69 x 40 x 129 mm (HxWxD)

Color
Black/Blue

Weight
approximately 350g

Mounting Type
Panel Mount / Screw Mount

Current Rating
10A max.

No Of Poles
2NC+1NO (Standard configuration)

QTY in Box
1

Series
D4SL

Model Number
D4SL-NSK10-LK

Standards Compliance
CE, UL, TUV

Actuator Type
Key operated (sold separately)

Release Type
Mechanical Lock/Manual Release

SKU / Bar Code
4548583230122

Door Switch Type
Safety Door Switch with Guard Lock

About OMRON GUARD LOCK SAFETY DOOR SWICTH, D4SL-NSK10-LK

Access a breathtaking standard of industrial safety with the OMRON GUARD LOCK SAFETY DOOR SWITCH, D4SL-NSK10-LK. Personalise your automation setup with peerless reliability and ineffable performance, ensuring unparalleled protection. This safety door switch boasts a mechanical lock/manual release, a robust combination of plastic and metal build, as well as an IP67 protection rating to resist harsh environments. Enjoy the reduced price and certified compliance (CE, UL, TUV) for peace of mind. Its key-operated actuator (sold separately), fast response, and long mechanical life guarantee steadfast operation in any automated environment.

Extra Features and Areas of Application

The OMRON D4SL-NSK10-LK Safety Door Switch stands out for its snap action contact mechanism, quick response, and mechanical lock/manual release system. Built for industrial and automation applications, its 1,000,000 operations mechanical life ensures exceptional durability. Protection level IP67 and compliance with CE, UL, and TUV standards make it suitable for environments that demand stringent safety measures and reliability. The standard configuration of 2NC+1NO contacts allows integration in various safety circuit designs.

Domestic Market, Sample Policy, and Shipping

OMRON GUARD LOCK SAFETY DOOR SWITCH, D4SL-NSK10-LK is available for supply across the main domestic market and can be shipped quickly from our designated FOB port. Shipped goods are securely packaged to ensure product safety in transit. Express shipping options are available for urgent project needs, and product samples may be offered based on wholesale policies. We provide reliable support and streamlined processes to guarantee your satisfaction from order placement through to final delivery.

FAQ's of OMRON GUARD LOCK SAFETY DOOR SWICTH, D4SL-NSK10-LK:

Q: How does the OMRON D4SL-NSK10-LK improve safety in automation settings?

A: With its mechanical lock and snap action contact, the D4SL-NSK10-LK provides reliable door monitoring and machine safety, helping prevent access to hazardous areas during operation.

Q: What kind of actuator does this safety door switch use?

A: The OMRON D4SL-NSK10-LK is designed for key-operated actuators, which are sold separately, enabling secure and controlled access.

Q: Where is the ideal area of application for this safety door switch?

A: Ideal for automation lines, industrial machinery, and any working environment with safety-guarded enclosures requiring a robust lock and quick response.

Q: What is the process for shipping and supplying this product domestically?

A: Orders are shipped from the designated FOB port, with express shipping options available for expedited delivery, ensuring timely supply to the domestic market.

Q: What are the benefits of its high IP67 protection rating?

A: The IP67 rating ensures the switch is dust-tight and can withstand strong water jets, making it suitable for harsh industrial environments.

Q: How can customers obtain a sample of the D4SL-NSK10-LK?

A: Sample policies vary depending on order quantity and wholesale agreements, so it's best to contact the supplier or exporter directly to request a sample.
