OMRON ELECTRONIC LIMIT SWITCH,SS-GL2

OMRON ELECTRONIC LIMIT SWITCH,SS-GL2 Specification

Temperature Range
-25C to +80C

Mechanical Life
10,000,000 operations min.

Protection Level
IP40

Automation Grade
Automatic

Response Time
15 ms max.

Number of Module
1

Rated Voltage
250 VAC/125 VDC

Finish Type
Glossy

Circuit Type
SPDT

Max. Current
5A

Product Type
Electronic Limit Switch

Material
Polymer; Metal Components

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
30 m max. (initial)

Max. Voltage
250 VAC

Operating Temperature
-25C to +80C (with no icing)

Stoke
10 mm

Size
50 mm 19.8 mm 13.5 mm

Color
Black and Silver

Weight
Approx. 11 g

Mounting Type
Panel Mount/Chassis Mount

Current Rating
5A

No Of Poles
Single Pole

Contact Material
Silver alloy

Compliance Standards
RoHS, IEC Standards

Housing Material
High-strength Polyester

Electrical Life
500,000 operations min.

Terminal Type
Solder terminal

Model Number
SS-GL2

Switching Frequency
120 operations/min (mechanically); 30 operations/min (electrically)

Shock Resistance
Malfunction: 300 m/s2 min. (approx. 30G)

Actuator Type
Lever (Hinge Lever)

Vibration Resistance
Malfunction: 10~55 Hz, 1.5 mm double amplitude

Dielectric Strength
1000 VAC, 50/60 Hz for 1 minute

About OMRON ELECTRONIC LIMIT SWITCH,SS-GL2

Experience ineffable precision with the OMRON ELECTRONIC LIMIT SWITCH, SS-GL2-a first-rate masterpiece engineered for reliable automation. Spotlighted for its advanced hinge lever actuator and robust construction, this device boasts a mechanical life of 10 million operations and adheres to IEC and RoHS compliance. With competitive pricing and attractive discounts, the SS-GL2 excels in protection, resilience, and safety. Enjoy superior performance with its IP40 rating, high-strength polyester housing, and silver alloy contacts-all created to ensure your automation systems run seamlessly and efficiently.

Exceptional Automation Solution: Superior Advantages

The OMRON SS-GL2 Electronic Limit Switch stands out for its automatic SPDT circuit design and lever (hinge lever) actuator type, ideally suited for industrial machinery and automation applications. Its primary competitive advantages include impressive mechanical life of over 10 million operations, rapid response time, and an IP40 protection level. This masterpiece thrives in automatic environments requiring reliability, accuracy, and endurance, making it the ultimate choice for demanding usage scenarios.

Global Distribution: Markets & Logistics

Dominating both domestic and key export markets, the OMRON SS-GL2 is available for prompt delivery via our main FOB port in China. Stock is ready for quick packing & dispatch to meet urgent purchase orders globally. We cater to suppliers, traders, and wholesalers across various regions, ensuring timely supply for automation projects worldwide. With efficient logistics and reliable export processes, your orders reach their destination securely and on schedule.

FAQ's of OMRON ELECTRONIC LIMIT SWITCH,SS-GL2:

Q: How is the OMRON SS-GL2 limit switch typically used in automation systems?

A: The OMRON SS-GL2 limit switch is primarily used to detect position or movement in automated equipment, ensuring precise control and safety of machinery in industrial automation applications.

Q: What competitive advantages does the SS-GL2 model offer?

A: This model offers high durability, with a mechanical life of at least 10,000,000 operations, a fast response time, and compliance with strict industry standards such as RoHS and IEC, ensuring longevity and safety.

Q: Where can the SS-GL2 limit switch be purchased and shipped?

A: The SS-GL2 is available for purchase through suppliers, traders, and wholesalers, with stock ready for dispatch from China to domestic and international markets, ensuring broad availability.

Q: What is the process for ordering and dispatch of the SS-GL2 limit switch?

A: After placing a purchase order, the product is promptly packed and dispatched from our main FOB port in China, ensuring fast and secure delivery to your location.

Q: What are the primary benefits of using the SS-GL2 limit switch in automation?

A: Benefits include an extended operational lifespan, high safety standards, robust vibration and shock resistance, and consistent performance for both panel mount and chassis mount applications.
