OMRON ELECTRIC SWITCH,V-156-1A5-T

OMRON ELECTRIC SWITCH,V-156-1A5-T Specification

Temperature Range
-25C to +80C

Max. Current
15A

Protection Level
IP40

Number of Module
Single

Response Time
< 5 ms

Circuit Type
SPST-NO (Single Pole Single Throw - Normally Open)

Finish Type
Standard

Mechanical Life
1,000,000 operations min.

Automation Grade
Manual

Rated Voltage
250V AC, 125V AC

Product Type
Micro Limit Switch

Material
Phenolic resin (case), Silver alloy (contacts)

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
15 m max. (initial value)

Max. Voltage
250V AC

Operating Temperature
-25C to +80C (no icing or condensation)

Stoke
0.5 mm (pretravel)

Size
27.8mm x 10.3mm x 15.9mm (L x W x H)

Color
Black

Weight
About 7.2g

Mounting Type
Panel Mount / Screw Mount

Current Rating
15A at 250VAC

No Of Poles
1

Standards Compliance
RoHS, cULus recognized

Manufacturer Part Number
V-156-1A5-T

Application
Home appliances, vending machines, industrial controls

Electrical Life
50,000 cycles min.

Terminal Type
Quick-connect

Contact Form
NO (Normally Open)

Actuator Type
Short Hinge Lever

Dielectric Strength
1,000V AC for 1 min between terminals of same polarity

About OMRON ELECTRIC SWITCH,V-156-1A5-T

The OMRON ELECTRIC SWITCH, V-156-1A5-T is a blue-ribbon, cost-effective choice for applications demanding reliability and noteworthy performance. Featuring a resplendent design with a short hinge lever actuator, this switch boasts favorable reviews and excellent durability with a minimum electrical life of 50,000 cycles and a mechanical life exceeding 1,000,000 operations. Its silver alloy contacts and robust phenolic resin case ensure optimal conductivity and safety, rated at 15A and 250V AC. Compliance with RoHS and cULus standards makes it a preferred solution for home appliances, vending machines, and industrial controls. This offer is ending soon.

Applications and Usage for OMRON V-156-1A5-T

The OMRON ELECTRIC SWITCH, V-156-1A5-T is specifically designed for integration within home appliances, vending machines, and diverse industrial controls. With panel or screw mounting, this switch supports manual automation for reliable, long-lasting operation. Usage directions are straightforward: install with the quick-connect terminals, and leverage the 0.5 mm pretravel for precision actuation. Its robust build and wide operating temperature range ensure dependable performance, even in challenging conditions.

Delivery & Export Information for OMRON V-156-1A5-T

Once ordered, the OMRON ELECTRIC SWITCH, V-156-1A5-T is processed promptly, ensuring it is handed over to logistics partners without unnecessary delay. Sample units are available for evaluation purposes, catering to clients who value hands-on assessment prior to bulk purchase. Delivered efficiently across global export markets with a special focus on Asia, North America, and Europe, the switch's order processing is streamlined to exceed customer expectations.

FAQ's of OMRON ELECTRIC SWITCH,V-156-1A5-T:

Q: How can the OMRON V-156-1A5-T switch be installed?

A: The V-156-1A5-T can be installed via quick-connect terminals using either panel mount or screw mount methods for secure and reliable placement in your selected application.

Q: What are the key benefits of using the OMRON V-156-1A5-T?

A: This switch offers exceptional durability, noteworthy performance in harsh environments, RoHS and cULus compliance, and a high current rating, making it ideal for demanding applications in home appliances and industrial controls.

Q: When can I expect delivery after placing my order?

A: After order processing, the product is typically handed over to logistics for quick delivery, with timeframes varying by region and export destination.

Q: Where is the OMRON V-156-1A5-T primarily used?

A: It is commonly used in home appliances, vending machines, and industrial controls where dependable switching is required.

Q: What is the process for obtaining a sample of the OMRON V-156-1A5-T?

A: You may request a sample unit during the order process. Our team will coordinate to ensure it is delivered efficiently for evaluation.

Q: How does the switch maintain safety and longevity?

A: Constructed with a phenolic resin case and silver alloy contacts, and tested to rigorous electrical and insulation standards, the switch ensures safe, long-lasting operation.
