OMRON E3FA-TP21

OMRON E3FA-TP21 Specification

Mounting Type
Panel or Bracket Mount

Features
Reliable detection, Compact size, Easy installation

Sensitivity
Adjustable (via potentiometer)

Wireless
No

Cable Length
2 m (integral cable)

Response Time
1 ms

IP Rating
IP67

Interface
2-wire or 3-wire DC

Power Consumption
20 mA

Operating Temperature
-25C to +55C

Application
Industrial automation, Packaging, Material handling

Measurement Range
0 to 20 m (Through-beam)

Signal Type
Digital

Sensor Type
Photoelectric (Through-beam)

Product Type
Photoelectric Sensor

Material
Plastic (Housing)

Input
10 to 30 VDC

Output
PNP Transistor NO/NC

Function
Through-Beam (Projector side)

Usage
Object detection, Positioning

Accuracy
High repeatability ( 2 mm)

Voltage
10 to 30 VDC

Weight
Approx. 50 g

EMC
Conforms to EN standards

Light Source
Red LED (660 nm)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Protection Circuits
Reverse polarity, Output short-circuit, Mutual interference prevention

Output Current
Max. 100 mA

Ambient Light Immunity
Sunlight: 5,000 lux, Incandescent lamp: 3,000 lux

Enclosure Material
PC/ABS blend

Connection Method
Pre-wired cable (2 m)

Shock Resistance
500 m/s^2, 3 times each in 6 directions

Indicator
Operation indicator (LED)

About OMRON E3FA-TP21

Get the matchless OMRON E3FA-TP21 Photoelectric Sensor at a reduced price, featuring enviable reliability and favorable reviews in industrial automation. With a robust red LED light source (660 nm), this invincible sensor boasts high repeatability (2 mm) and an extensive operating range (0-20 m). Its rugged PC/ABS blend enclosure and IP67 rating guarantee longevity. The E3FA-TP21 is engineered for quick installation, reliable object detection, and top-tier positioning accuracy. Benefit from mutual interference prevention, compact size, and efficient power consumption (20 mA). Ideal for packaging, material handling, and process automation, this sensor is favored by leading suppliers, traders, and wholesalers in China.

Versatile Application Surfaces and Methods

The OMRON E3FA-TP21 excels on diverse surfaces, from conveyor belts to complex assembly lines. Application is straightforward: panel or bracket mounting ensures quick setup, while the adjustable sensitivity caters to varying requirements. Aside from object detection, it's perfect for accurate positioning in packaging and seamless monitoring in automated sorting. Other applications span material handling and quality inspection, making it a reliable option for tough industrial environments that demand both flexibility and precision.

Domestic Market Reach, Certifications, and Samples

OMRON E3FA-TP21 is popular throughout China's main domestic markets, vouched for by essential EN standard certifications. Express shipping is available for efficient delivery, with professional packaging ensuring product integrity. Samples can be requested, sometimes with an additional charge. This combination of certified quality, broad market application, and customer-oriented sampling service makes it an attractive choice for suppliers and wholesalers seeking prompt and dependable solutions.

FAQ's of OMRON E3FA-TP21:

Q: How is the OMRON E3FA-TP21 installed in industrial applications?

A: The OMRON E3FA-TP21 can be easily installed using either panel or bracket mounting. Its compact design and pre-wired 2-meter cable streamline the process for swift integration into production lines.

Q: What makes the E3FA-TP21 suitable for harsh environments?

A: With an IP67 rating, vibration and shock resistance, and a durable PC/ABS enclosure, the E3FA-TP21 is built to operate reliably in demanding industrial settings including exposure to dust, moisture, and mechanical stress.

Q: When should the sensitivity adjustment via potentiometer be used?

A: The adjustable sensitivity potentiometer should be used when detection conditions vary, such as when objects of different sizes or reflectivities must be detected, or when optimizing performance for specific distances within the 0-20 m range.

Q: Where is the OMRON E3FA-TP21 commonly applied?

A: It is widely used in industrial automation for object detection, packaging lines, material handling systems, quality control, and other positions requiring accurate and reliable photoelectric sensing.

Q: What certifications ensure the reliability of this sensor?

A: The OMRON E3FA-TP21 conforms to EMC and EN standards, verifying that it meets rigorous safety and electromagnetic compatibility requirements essential for industrial automation environments.

Q: How can I request a sample of the E3FA-TP21?

A: Samples are available upon request-please check with your supplier or wholesaler, as charges may apply and express shipping options can be arranged depending on packaging and location.
