OMRON DIGITAL TEMPERATURE CONTROLLER, E5EC-RR2ASM-800

OMRON DIGITAL TEMPERATURE CONTROLLER, E5EC-RR2ASM-800 Specification

Type
Digital Temperature Controller

Theory
PID Control with Auto-tuning

Exterior Material
Plastic Housing (Flame-retardant)

External Size
48 mm x 96 mm x 60 mm (H x W x D) Millimeter (mm)

Heating System
External (Load Controlled by Relay Output)

Cooling System
External (Load Controlled by Relay Output)

Controller System
Microprocessor based with Digital Display

Temperature Range
-200C to 2300C (sensor dependent) Celsius (oC)

Operating Temperature
-10°C to 55°C

Mounting Method
Panel Mount

Communication
RS-485 (Modbus/ASCII, optional)

Sampling Period
50 ms

Input Type
Thermocouple, RTD, Analog

Setting Method
Digital Keypad

IP Rating
Front Panel: IP66, Rear: IP20

Auxiliary Output
1 (optional)

Alarm Output
2 (SPST-NO, 3A at 250 VAC/30 VDC)

Control Method
ON/OFF, 2-PID, PID (with auto-tuning)

Power Supply Voltage
100 to 240 VAC 50/60Hz

Output Type
Relay (2 outputs), Voltage output (for SSR drive)

Display
White LCD display with 4-digit 7-segment main display and 4-digit sub display

Model Number
E5EC-RR2ASM-800

Weight
Approx. 150g

About OMRON DIGITAL TEMPERATURE CONTROLLER, E5EC-RR2ASM-800

Experience sizzling performance with the OMRON DIGITAL TEMPERATURE CONTROLLER, E5EC-RR2ASM-800a supreme, must-have solution for precision control. Featuring a polished white LCD display with dual 4-digit segments, this controller excels with an unprecedented input versatility (Thermocouple, RTD, Analog) and multiple output options. Its microprocessor-based system ensures reliable PID control with effortless auto-tuning. Personalise your settings using the digital keypad for optimal results. Compact yet robust with flame-retardant housing and IP66 front panel protection, it guarantees stellar performance from -200C to 2300C. Unleash quality control with every application.

Versatile Applications and Specific Uses

The OMRON E5EC-RR2ASM-800 is engineered for supreme versatility, making it suitable for various industrial and laboratory applications, including process heating, cooling, and precise temperature management in ovens, plastics, and packaging. Its flame-retardant exterior and robust panel mounting allow tailored use across diverse surfaces such as machinery panels, control cabinets, and testing platforms. This polished controller adapts seamlessly for must-have solutions in temperature-sensitive environments requiring unwavering accuracy and reliability.

Domestic Market Reach and Secure Distribution

OMRONs E5EC-RR2ASM-800 serves the main domestic markets across India and Southeast Asia, promising secure shipping and prompt delivery. With impressive supply ability, customers can place their purchase orders confidently, knowing their investment will be valued with proper handling and documentation. The FOB port in China facilitates streamlined international logistics, ensuring timely arrivals and safe packaging. Rely on stable valuation and prompt fulfillment for a hassle-free procurement experience.

FAQs of OMRON DIGITAL TEMPERATURE CONTROLLER, E5EC-RR2ASM-800:

Q: How can I personalise settings on the E5EC-RR2ASM-800 controller?

A: You can easily personalise settings using the digital keypad, allowing you to fine-tune temperature ranges and control parameters, making it ideal for specific process requirements.

Q: What types of inputs are supported by the OMRON E5EC-RR2ASM-800?

A: This controller supports thermocouple, RTD, and analog inputs, giving you flexibility to adapt to a range of sensors and environments.

Q: Where can the E5EC-RR2ASM-800 be installed?

A: Designed for panel mounting, it fits securely into control cabinets, machinery panels, and test platforms, offering flexibility across multiple setups.

Q: What are the benefits of the IP66 rating on the front panel?

A: The IP66 rating ensures dust-tight and water-resistant protection on the front panel, safeguarding the device against challenging industrial conditions.

Q: How does the auto-tuning PID control improve process reliability?

A: Auto-tuning PID control automatically adjusts controller settings in response to process changes, enhancing stability and maintaining precise temperature control with minimal intervention.

Q: What is the capacity of the relay outputs in this controller?

A: The OMRON E5EC-RR2ASM-800 features two relay outputs, each capable of handling up to 5A at 250 VAC or 30 VDC, to support various external heating and cooling systems effectively.
