OMRON DIGITAL COUNTER,H7CX-A4SD-N

OMRON DIGITAL COUNTER,H7CX-A4SD-N Specification

Accuracy
0.1% (Display value)

Connection
Screw terminals

Function
Digital Counter

Size
48 x 48 mm (DIN 1/16 size)

Mounting Method
Panel mounting

Protection Structure
IP66 (front panel only)

Display Type
7-segment, 2-line LCD display with color change capability

Reset Method
Manual reset, External reset, Power reset

Count Speed
30 Hz / 1 kHz / 5 kHz (selectable)

Weight
Approx. 110 g

Power Supply Voltage
24 to 240 VAC/DC

Environmental Resistance
Operating temperature: -10C to +55C, Humidity: 25 to 85% RH

Counting Input
PNP/NPN universal

Contact Output
4-digit preset / Double preset, SPDT relay

About OMRON DIGITAL COUNTER,H7CX-A4SD-N

Experience elite precision with the acclaimed OMRON DIGITAL COUNTER, H7CX-A4SD-N. This renowned counter features a first-rate 7-segment, 2-line LCD display with color change capability, ensuring clear, adaptable readings. Suitable for various environments, its universal input accepts both PNP and NPN signals and operates on 24 to 240 VAC/DC. Triumphant in durability, this device offers a robust IP66-rated front panel and supports double preset contact outputs. With selectable count speeds up to 5 kHz and versatile reset options, the H7CX-A4SD-N is the preferred choice for advanced automation needs.

Distinct Features & Competitive Advantages

The OMRON H7CX-A4SD-N showcases advanced user-centric features, including manual, external, and power reset options for ultimate versatility. Its compact DIN 1/16 size and screw terminal connection facilitate swift integration into control panels. With a high 0.1% accuracy, robust IP66 front panel protection, and wide operating temperature tolerance, it stands out as a first-rate solution for manufacturing, packaging, and process control. Its acclaimed reputation makes it a trusted choice among engineers worldwide.

Supply Ability, Sample Policy, and Shipping Terms

Our supply chain is designed for swift fulfillment, ensuring shipped goods arrive reliably via selected freight partners. We offer sample availability for the OMRON H7CX-A4SD-N to qualifying customers for evaluation purposes; please inquire about the asking price and sample policy. Bulk orders benefit from timely dispatch, and all goods are securely packed for global distribution. Contact us for more information on bulk pricing, supply capabilities, and to request sample shipments at the best competitive rates.

FAQ's of OMRON DIGITAL COUNTER,H7CX-A4SD-N:

Q: How does the OMRON H7CX-A4SD-N benefit industrial automation processes?

A: The H7CX-A4SD-N enhances productivity by offering rapid, precise digital counting with selectable speed options and adaptable display settings, making process monitoring and control more efficient.

Q: What competitive advantages does the H7CX-A4SD-N offer over standard digital counters?

A: This model features a robust IP66-rated front panel, exceptional environmental resistance, and dual preset outputs. It also offers a color-change LCD and universal input compatibility, providing flexibility and reliability unmatched by standard counters.

Q: Where can the OMRON H7CX-A4SD-N be effectively utilized?

A: Ideal for use in manufacturing automation, packaging lines, process industries, and machinery requiring precise counting and preset control, the device's resilience and accuracy suit demanding industrial applications.

Q: What is the process for obtaining a sample of the OMRON H7CX-A4SD-N?

A: To request a sample, customers can contact our sales team for sample policy details, asking price, and shipment arrangements. Samples are provided to qualified buyers for evaluation purposes.

Q: How does the product's environmental resistance enhance usage?

A: With an operating temperature range from -10C to +55C, 25-85% humidity tolerance, and IP66 protection on the front panel, the counter consistently delivers reliable performance in challenging environments.
