OMRON CONNECTOR CABLE, XS2F-M12PVC3A10MPLED

OMRON CONNECTOR CABLE, XS2F-M12PVC3A10MPLED Specification

Operating Temperature
-25C to +80C

Rated Temperature
-25C to +80C

Install Type
Panel mount or field wiring

Weight
Approx. 350g (10m cable)

Cable Type
Pre-wired, assembly type

Usage & Applications
Connects sensors and actuators to control systems

Conductor Type
Stranded

Dielectiric Strength
1500V AC / 1 min

Insulation
PVC

Number of Conductor
3

Core Number
3

Features
Pre-wired connector with M12 LED indication, waterproof, oil-resistant, robust construction for industrial use

Diameter
Approx. 6mm (cable)

Locking Type
Screw locking, M12

Conductor Shape
Round

Core Material
Copper

Product Type
Connector Cable

Length
10 Meters

Voltage
250V AC/DC (Max)

Insulation Material
PVC

Application
Industrial automation, sensor connection, machinery interfacing

Conductor Material
Copper

Jacket Material
PVC

Storage Temperature
-25C to +80C

Connector Color
Metallic with Transparent LED window

Shield Material
Unshielded

Jacket Color
Black

Dimension (L*W*H)
Cable Length: 10m, Connector Diameter: ~12mm

Color
Black cable, metallic connector

Material
PVC and Metal

Size
M12 connector

Indicator
LED indication for connection status

Contact Plating
Gold-plated contacts

Bending Radius
10 x cable outer diameter (recommended)

Standards Compliance
IEC standard compliant

Connector Type
M12, 3-pin, male

Mounting Method
Direct plug-in with threaded locking

Ingress Protection
IP67 (dust-tight, waterproof)

Connector Gender
Male

Rated Current
4A max

OMRON CONNECTOR CABLE, XS2F-M12PVC3A10MPLED About

Access the latest in industrial connectivity with the OMRON CONNECTOR CABLE, XS2F-M12PVC3A10MPLED. This spectacular, top-ranking M12, 3-pin, male connector features lustrous gold-plated contacts and a transparent LED window for instant connection status. Designed for robust performance, it meets IEC standards, offers IP67 waterproofing, and withstands harsh environments. The new pre-wired 10-meter cable includes oil-resistant PVC insulation, ensuring durability for demanding automation, sensor, and machinery interfacing. Benefit from its reliable screw-locking design and premium quality, making it ideal for advanced industrial installations.

Extensive Applications for Industrial Automation

The OMRON CONNECTOR CABLE, XS2F-M12PVC3A10MPLED is widely used in industrial automation for connecting sensors, actuators, and machinery to control systems. Its robust construction and waterproof design make it perfect for both interior panel mounting and field wiring on factory floors. This connector cable excels on varied application surfaces, including automated assembly lines, machinery interfaces, and sensor networks, consistently delivering reliable performance in demanding environments.

Sample Policy, Certifications, and Delivery Timelines

OMRON provides premium quality with every delivery-samples are available with a nominal charge credited on bulk orders. Each cable complies with stringent IEC standards for safety and performance. Orders are typically delivered within a short, specified timeframe to ensure your projects proceed without delay. Rest assured that all cables are thoroughly tested and certified to meet industrial grade requirements, making every shipment as dependable as your application demands.

FAQ's of OMRON CONNECTOR CABLE, XS2F-M12PVC3A10MPLED:

Q: How does the LED indicator on the OMRON CONNECTOR CABLE function during usage?

A: The integrated LED provides clear, immediate visual feedback on connection status, illuminating when the connector is correctly mated and power is supplied.

Q: What are the primary benefits of using this pre-wired M12 cable in industrial applications?

A: Its robust design, waterproof and oil-resistant PVC insulation, and easy screw-locking mechanism deliver durability and reliability, reducing maintenance and installation time for industrial automation and sensor connections.

Q: Where can the OMRON XS2F-M12PVC3A10MPLED connector cable be installed?

A: This cable is suitable for installation in industrial environments, including factory floors, machinery panels, sensor arrays, and outdoor applications-where high ingress protection and oil resistance are vital.

Q: What is the process for panel or field mounting this cable?

A: Direct plug-in with threaded screw locking enables easy, secure installation on panels or field locations, requiring minimal tools and ensuring a tight, stable connection.

Q: When should I consider requesting a sample, and is there a charge?

A: Sample requests can be made ahead of bulk purchasing decisions; a nominal charge is applied, which is typically credited if a subsequent premium order is placed.

Q: How does the product comply with industry standards and certifications?

A: Each cable is IEC standard compliant, ensuring safety, durability, and high performance, meeting the rigorous criteria essential for industrial environments.
