OMRON CAPACITIVE PROXIMITY SWITCH,E2K-C25ME1

OMRON CAPACITIVE PROXIMITY SWITCH,E2K-C25ME1 Specification

Protection Level
IP66

Rated Voltage
220 VAC

Response Time
20 ms max.

Mechanical Life
30,000,000 operations min.

Circuit Type
Normally Open (NO), 2-wire

Max. Current
200 mA AC

Automation Grade
Automatic

Finish Type
Molded

Number of Module
Single

Temperature Range
-25C to +70C

Product Type
Capacitive Proximity Switch

Material
Plastic, ABS

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
50 m max.

Max. Voltage
220 VAC

Operating Temperature
-25C to +70C (with no icing or condensation)

Stoke
Non-contact (N/A)

Size
25 mm diameter, M30

Color
Gray

Weight
Approx. 130 g

Mounting Type
Panel Mount, Screw Mount

Current Rating
200 mA

No Of Poles
2-wire AC

Cable Length
2 m (standard)

Power Consumption
2.2 VA max.

Control Output
Non-contact, AC Switch Output

Indicator
Operation indicator (Red LED)

Frequency
50/60 Hz

Output Type
SCR (Silicon Controlled Rectifier)

Sensing Distance
25 mm 10%

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Shock Resistance
500 m/s2, 3 times each in XYZ directions

Operating Humidity
35% to 95% RH

Standards Compliance
CE Marked, RoHS compliant

About OMRON CAPACITIVE PROXIMITY SWITCH,E2K-C25ME1

The OMRON CAPACITIVE PROXIMITY SWITCH, E2K-C25ME1, is a highly recommended and popular solution for precise detection tasks. Renowned for its superb reliability and peerless performance, this switch operates with a noble efficiency, offering non-contact AC switch output with SCR technology. Its cost-effective design meets strict CE and RoHS compliance standards, featuring an impressive sensing distance of 25 mm 10%. With robust vibration and shock resistance, an operation indicator, and weatherproof IP66 housing, this E2K-C25ME1 model is ideal for demanding automation industries seeking a durable and efficient solution.

Extensive Commercial Applications

OMRON's E2K-C25ME1 capacitive proximity switch is engineered for diverse commercial uses, excelling in automation, packaging, and assembly operations. Highly suitable for factories, workshops, and production units, its non-contact detection makes it indispensable in food processing, material handling, and conveyor systems. The device's exceptional environmental tolerance and resilience allow it to outperform in industries requiring durable and accurate sensors for harsh or variable operating conditions, guaranteeing continued productivity and reduced downtime.

Export Markets & Packaging Solutions

Serving a global clientele, the E2K-C25ME1 is chiefly supplied to key export markets in Asia, Europe, and North America. With sample units offered for evaluative proposals, clients can review cost and compatibility before full expenditure. Products are meticulously packaged to protect during domestic and international transport, ensuring that the integrity remains intact upon arrival. The supplier, trader, and wholesaler networks based in China offer competitive proposal amounts for bulk and recurrent procurement.

FAQ's of OMRON CAPACITIVE PROXIMITY SWITCH,E2K-C25ME1:

Q: How does the OMRON E2K-C25ME1 proximity switch operate?

A: The E2K-C25ME1 uses SCR (Silicon Controlled Rectifier) technology to deliver a reliable, non-contact AC switch output, making it effective for detecting solid and liquid objects within a 25 mm range.

Q: What are the main benefits of using the E2K-C25ME1 in industrial automation?

A: This model stands out for its durability, rapid 20 ms response time, superb environmental tolerance, and IP66 protection rating, ensuring safe and consistent operation in challenging industrial settings.

Q: Where can the OMRON E2K-C25ME1 be installed?

A: It is suitable for panel and screw mount installations, making it versatile for use in a wide range of commercial and industrial machinery, conveyor systems, and automated equipment.

Q: What application areas is this proximity switch recommended for?

A: The E2K-C25ME1 excels in food processing, packaging lines, assembly operations, and other industries requiring non-contact object detection and high reliability under diverse environmental conditions.

Q: Is it possible to request a sample before making a bulk purchase of the E2K-C25ME1?

A: Yes, samples are available for proposal assessment, allowing clients to evaluate the product's suitability and performance before committing to significant expenditure.

Q: How is the OMRON E2K-C25ME1 packaged and delivered to clients?

A: The proximity switch is securely packaged to preserve quality during both domestic and international shipping, ensuring safe arrival regardless of the destination.
