OMRON CABLE CONNECTOR,XS2F-M12PVC3A5MPLED

OMRON CABLE CONNECTOR,XS2F-M12PVC3A5MPLED Specification

Conductor Type
Flexible

Locking Type
Screw/Nut lock â M12 connector standard

Insulation
PVC insulation

Number of Conductor
3

Core Number
3-core

Weight
Approx. 200g

Rated Temperature
-25°C to +70°C

Usage & Applications
For use with industrial sensors, actuators, and fieldbus devices

Install Type
Panel mountable, plug and play

Operating Temperature
-25°C to +70°C

Features
With LED indicator for operation status, flexible, pre-wired, oil-resistant, and water-resistant design, rugged PVC outer jacket

Core Material
Copper

Conductor Shape
Stranded

Diameter
Approx. 4.5 mm (Cable Outer Diameter)

Dielectiric Strength
1000V AC, 1 min

Cable Type
M12 pre-wired cable assembly

Product Type
Cable Connector

Length
5 meters

Voltage
250V AC/DC (maximum)

Insulation Material
PVC

Application
Other

Conductor Material
Copper

Jacket Material
PVC

Storage Temperature
-25°C to +70°C

Connector Color
Metallic with black insulation

Shield Material
Unshielded

Jacket Color
Black

Color
Black (Cable), Metallic (Connector)

Material
PVC (Cable), Copper (Conductor), Metal/Plastic (Connector)

Size
M12, 5 meters long

Standards Compliance
RoHS compliant

Voltage Rating
250V AC/DC

Ingress Protection
IP67 rated for dust and water resistance

Contact Resistance
≤ 5 mΩ

Connector Gender
Male

Connector Type
M12 male connector, straight (with LED)

Current Rating
4A (Max)

Insulation Resistance
>100 MΩ at 500V DC

Cable Structure
3-wire, pre-assembled

Pin Configuration
3-pin

Product Series
XS2F-M12PVC3A5MPLED

Mounting
Direct cable connection – ready to install

About OMRON CABLE CONNECTOR,XS2F-M12PVC3A5MPLED

Redeem the champion of connectivity with the OMRON CABLE CONNECTOR, XS2F-M12PVC3A5MPLED at the best price-order today! This majestic M12 male connector features a 3-pin straight design with a powerful LED indicator, ensuring unmatchable status monitoring. Boasting an IP67 rating for outstanding dust and water resistance, it thrives in harsh industrial environments. With a flexible 5-meter, pre-wired, oil-resistant PVC jacket and robust copper conductors, this connector delivers reliable 250V AC/DC performance up to 4A. RoHS compliant and ready for direct installation, it's the ultimate solution for industrial automation, sensor, and actuator applications.

Versatile Applications and Material Excellence

The OMRON XS2F-M12PVC3A5MPLED excels in various industrial environments, connecting sensors, actuators, and M12 interface devices seamlessly. Its flexible, stranded copper core and rugged PVC insulation offer outstanding material reliability. Engineered for plug-and-play use, this connector thrives in automation systems, machinery panels, and demanding fieldbus applications, providing durable, high-performance connectivity every time.

Packaging, Delivery, and Supply Details

Order completion is swift and efficient with OMRON's streamlined process. Each XS2F-M12PVC3A5MPLED cable connector is securely packaged to ensure safe transit. We support high supply ability to meet bulk and timely requirements. Freight is managed from a major FOB port in China, and express shipping solutions are available, ensuring your order reaches you quickly and reliably, with minimal lead time.

FAQ's of OMRON CABLE CONNECTOR,XS2F-M12PVC3A5MPLED:

Q: How do I install the OMRON XS2F-M12PVC3A5MPLED cable connector?

A: Installation is straightforward-directly connect the pre-wired, flexible cable using the industry-standard M12 screw/nut lock interface. The plug-and-play design enables panel mounting quickly without requiring custom wiring.

Q: What type of usage is this cable connector best suited for?

A: The XS2F-M12PVC3A5MPLED is ideal for industrial automation environments, particularly for connecting sensors and actuators to control panels or fieldbus devices where flexibility, ruggedness, and operational status indication are needed.

Q: When should I choose a connector with an LED indicator?

A: Select a cable connector with an LED indicator like this one when you need real-time visual confirmation of operation status, which aids in diagnostics and system monitoring during use.

Q: Where is the product shipped from and what are the logistics options?

A: Products are shipped from China, typically from a prominent FOB port. Express shipping and standard freight methods are available to ensure timely and secure delivery according to your needs.

Q: What material advantages does this connector offer?

A: The connector features a durable PVC jacket, flexible stranded copper conductors, and robust metallic locking hardware, combining oil resistance, water resistance, and mechanical strength for extended service life.

Q: How does the IP67 rating benefit my industrial applications?

A: IP67 ingress protection means the connector resists dust and temporary water immersion, making it reliable in demanding industrial settings with exposure to contaminants or moisture.
