METAL FACE PROXIMITY SENSOR HTC 6-36VDC,HTC12-3004PAT-Q,12MM,PNP NO,SD-4MM,FLUSH PLUG TYPE

METAL FACE PROXIMITY SENSOR HTC 6-36VDC,HTC12-3004PAT-Q,12MM,PNP NO,SD-4MM,FLUSH PLUG TYPE Specification

Application
Industrial Automation, Process Control, Conveyor Systems

Measurement Range
Sensing Distance 4mm

Signal Type
Digital

Operating Temperature
-20C to +70C Celsius (oC)

Wireless
No

IP Rating
IP67

Sensitivity
Configured for Metal Target

Cable Length
2 Meter (m)

Sensor Type
Inductive Proximity Sensor

Interface
3-wire

Features
Short Circuit & Overload Protection, LED Indicator

Product Type
Metal Face Proximity Sensor

Material
Metal (Sensing Face)

Input
6-36 VDC

Output
PNP, Normally Open (NO)

Function
Proximity Detection

Usage
Object/Metal Detection

Resolution
Precise Switching

Voltage
6-36 VDC Volt (v)

Weight
150g Grams (g)

Frequency
Switching Frequency Up To 500Hz

Ambient Humidity
35% to 85% RH

Protection Features
Reverse Polarity and Surge Protection

Mounting Thread Size
M12

Shock Resistance
50G (500 m/s2)

Model Number
HTC12-3004PAT-Q

Sensing Face Diameter
12mm

Housing Material
Nickel Plated Brass

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Connection Type
Pre-wired Cable

METAL FACE PROXIMITY SENSOR HTC 6-36VDC,HTC12-3004PAT-Q,12MM,PNP NO,SD-4MM,FLUSH PLUG TYPE Trade Information

Minimum Order Quantity
30 Number

Supply Ability
1000 Per Month

Delivery Time
7 Days

About METAL FACE PROXIMITY SENSOR HTC 6-36VDC,HTC12-3004PAT-Q,12MM,PNP NO,SD-4MM,FLUSH PLUG TYPE

Discover the new release, METAL FACE PROXIMITY SENSOR HTC12-3004PAT-Qhighlighted for its meritorious engineering and robust performance. This superb sensor features a 12mm sensing face, a pre-wired 2-meter cable, and a nickel-plated brass housing, ensuring astounding reliability for object and metal detection. Equipped with advanced protection features like reverse polarity, surge, and short circuit safeguards, it supports 636VDC input and operates at high frequency (up to 500Hz) with PNP, NO output. Find impeccable precision and durability ideal for industrial automation, process control, and conveyor systems with an IP67 rating and high vibration and shock resistance.

Commercial Applications & Key Competitive Advantages

The METAL FACE PROXIMITY SENSOR HTC12-3004PAT-Q excels in diverse commercial settings, including industrial automation, process control, and conveyor systems. Its versatility makes it suitable for manufacturers seeking reliable, rapid object or metal detection. Highlighted competitive advantages include its IP67 protection, high-frequency switching, superb shock/vibration resistance, and flush mounting. The sensors precise switching and meritorious build quality ensure dependable operation even under challenging conditions, setting it apart in the competitive landscape.

Payment Terms, Export Markets & Delivery Time

We offer flexible payment terms and attractive wholesale rates tailored for global clients. The METAL FACE PROXIMITY SENSOR HTC12-3004PAT-Q is primarily exported to Asian, European, and American markets. Our efficient dispatching and reliable transport services ensure prompt delivery, typically within 7-14 business days after order confirmation. Each unit is carefully packed to guarantee safe transit, and support is available for all export and shipping-related inquiries throughout the process.

FAQs of METAL FACE PROXIMITY SENSOR HTC 6-36VDC,HTC12-3004PAT-Q,12MM,PNP NO,SD-4MM,FLUSH PLUG TYPE:

Q: How does the METAL FACE PROXIMITY SENSOR HTC12-3004PAT-Q improve industrial automation processes?

A: This sensor streamlines industrial automation by providing high-accuracy, rapid metal/object detection with precise switching and minimal response time, reducing manual monitoring and improving system reliability.

Q: What are the main usage areas for this proximity sensor?

A: The HTC12-3004PAT-Q is primarily used in industrial automation, process control, conveyor systems, and other environments where dependable and accurate metal detection is crucial.

Q: Where can this sensor be installed in an industrial setup?

A: Its flush, plug-type mounting and compact 12mm sensing face make it ideal for installation in tight spaces on equipment frames, conveyor lines, or control panels within harsh industrial environments.

Q: What benefits do the IP67 rating and overload protection provide?

A: The IP67 rating ensures outstanding resistance to water and dust ingress, while overload protection safeguards the sensor against electrical surges, ensuring prolonged lifespan and dependable operation.

Q: How is the delivery process handled for international orders?

A: We manage international dispatching through established transport services, ensuring timely shipment and secure packaging. Most orders are delivered within 7-14 business days, depending on the destination.
