MEANWELL POWERS SUPPLY, LRS-600-24 INPUT 100-240V 12A OUTPUT 24V 25A

MEANWELL POWERS SUPPLY, LRS-600-24 INPUT 100-240V 12A OUTPUT 24V 25A Specification

Output Current
25A

Connector Type
Screw Terminal

Rated Power
600W

Current Range
0~25A

Cooling Method
Built-in DC fan

Rated Current
25A

Power Supply
AC-DC

Phase
Single Phase

Operating Temperature
-30~+70C

Application
LED Lighting, Industrial Automation, CNC, 3D Printers, Security Systems

Features
Universal AC input, Compact size, High reliability, Built-in DC fan

Power Factor
> 0.94

Noise Level
<65mVp-p

Output Type
Single

Working Temperature
-30~+70C (with derating)

Product Type
Switching Power Supply

Output Power
600W

Output Frequency
47-63Hz

Input Voltage
100-240V AC

Voltage Protection
Over Voltage, Over Load, Over Temperature, Short Circuit Protection

Efficiency
Up to 89%

Material
Metal (Aluminum Case)

Line Regulation
0.5%

Storage Temperature
-40~+85C

Weight
1.68kg

MTBF
> 200,000 hours

Remote Sense
Yes (for voltage compensation)

Humidity
20~90% RH non-condensing

Output Voltage
24V DC

Input Frequency
47-63Hz

Dimensions (LxWxH)
215 x 115 x 50mm

Setup, Rise, Hold-up Time
1200ms, 80ms, 16ms at full load

Protection Type
Auto Recovery

Isolation Voltage
I/P-O/P: 3.75kVAC

Ripple & Noise (max)
150mVp-p

Adjustable Output Voltage Range
21.6~28.8V

Safety Standards
UL, TUV, EAC recognized

About MEANWELL POWERS SUPPLY, LRS-600-24 INPUT 100-240V 12A OUTPUT 24V 25A

Get your hands on the top-tier MEANWELL Power Supply, model LRS-600-24, highly recommended for a diverse range of industrial applications. Procure this renowned power supply featuring an astounding 600W output and 25A current with a universal 100-240V AC input. Its robust aluminum case ensures durability while remote sense technology provides voltage compensation and stable output. Equipped with over-voltage, overload, over-temperature, and short circuit protection, this power supply offers up to 89% efficiency, making it the ideal choice for LED lighting, CNC machinery, 3D printers, and more.

Astounding Features and Versatile Applications

The MEANWELL LRS-600-24 is infused with advanced features for astute users-automatic recovery protections, a compact profile, and a robust aluminum build. Its adjustable voltage range (21.6~28.8V) and 600W output make it highly suitable for dynamic usages in LED lighting, security systems, industrial automation, CNC machines, and 3D printers. Employ this single-phase, high-reliability unit with confidence in demanding environments, thanks to its wide operating and storage temperature range and efficient built-in cooling system.

Market Value, Delivery, and Supply Dynamics

This MEANWELL power supply establishes strong market value as a reliable, long-life solution available from a leading supplier and wholesaler in China. Experience prompt delivery and consistent supply ability, ensuring you procure your units at the lowest price through our efficient logistics network. FOB Port options further streamline your buying process, making the acquisition of this industry-moving product both accessible and economical for your business needs.

FAQ's of MEANWELL POWERS SUPPLY, LRS-600-24 INPUT 100-240V 12A OUTPUT 24V 25A:

Q: How does the remote sense feature benefit voltage compensation in the LRS-600-24?

A: The remote sense feature allows the power supply to automatically adjust for voltage drops along the output wires, ensuring precise voltage delivery directly at the load, which is critical for sensitive industrial equipment.

Q: What applications are best suited for the MEANWELL LRS-600-24?

A: It is highly recommended for LED lighting systems, CNC machinery, industrial automation, 3D printers, and security systems due to its reliable output, advanced protections, and robust construction.

Q: What protection features are included for safe operation?

A: The LRS-600-24 incorporates multiple safety features such as over-voltage, over-load, over-temperature, and short-circuit protection with an auto-recovery design, ensuring consistent and safe performance.

Q: Where can I procure this power supply, and what is the typical delivery timeframe?

A: This renowned power supply can be sourced from trusted suppliers and wholesalers in China. Delivery is prompt and efficient, contingent on your location and order quantity.

Q: What is the process for adjusting the output voltage?

A: The output voltage can be easily adjusted within 21.6 to 28.8V using the built-in voltage adjustment feature on the unit. Refer to the product manual for specific adjustment instructions.

Q: When is the LRS-600-24 most beneficial to use?

A: It delivers top performance when highly stable and efficient power is required over a wide load range in both harsh and controlled industrial environments.
