MEANWELL POWER SUPPLY, LRS-350-12, OUTPUT 12V 29A

MEANWELL POWER SUPPLY, LRS-350-12, OUTPUT 12V 29A Specification

Cooling Method
Convection Cooling

Current Range
0-29A

Features
High Efficiency, Fanless Design, Low No Load Power Consumption, Compact Size, Universal AC Input

Output Current
29A

Output Type
Single Output

Rated Current
29A

Working Temperature
-30C to +70C

Phase
Single Phase

Power Factor
>0.95 (@230VAC)

Application
Industrial Automation, LED Lighting, Control Systems

Connector Type
Screw Terminal

Rated Power
348W

Noise Level
< 120mVp-p

Power Supply
Meanwell LRS-350-12

Operating Temperature
-30C to +70C

Product Type
Switching Power Supply

Output Power
348W

Output Frequency
47-63Hz

Input Voltage
AC 100-240V, 4.8A 50/60Hz

Voltage Protection
Over Voltage, Over Load, Short Circuit Protection

Efficiency
up to 89%

Material
Metal Enclosure

Line Regulation
0.5%

Storage Temperature
-40C to +85C

Weight
0.89kg

Isolation Voltage
I/P-O/P: 3.75KVAC

MTBF
> 334,700 hours

Enclosure Type
Low profile metal mesh case

Remote ON/OFF Control
No

Adjustable Output Voltage Range
10.2~13.8V

Power Good Signal
No

Output Voltage
12V DC

Cooling Fan
No (fanless)

Ripple & Noise
<120mVp-p

Input Current
4.8A/230VAC

Dimensions
215 x 115 x 30 mm (L x W x H)

Safety Standards
UL62368-1, TUV EN62368-1, EAC TP TC 004

MEANWELL POWER SUPPLY, LRS-350-12, OUTPUT 12V 29A About

Experience the resplendent performance of the MEANWELL LRS-350-12 Power Supply, designed for those demanding both opulent reliability and commanding efficiency. Offering an adjustable 12V DC output at 29A, this advanced solution effortlessly delivers up to 348W for your automation, LED lighting, and control systems. Personalise your operations with robust protections, universal AC input, and compact, fanless design. Secure your offer with advance purchase options from leading suppliers, traders, and wholesalers in China, ensuring your projects remain uninterrupted and reliable.

Versatile Applications & Key Features

The MEANWELL LRS-350-12 Power Supply is resplendent in industries ranging from industrial automation to high-end LED lighting and sophisticated control systems. Its opulent, low-profile metal mesh case ensures safe and efficient operation in both commercial and general environments. Features such as wide adjustable voltage, superb efficiency of up to 89%, and robust over-voltage, overload, and short-circuit protection make it a commanding choice for any demanding application.

Sample Availability & Streamlined Delivery

Proposal amounts can be customised with our stock ready for immediate dispatch, ensuring minimal downtime. Samples of the MEANWELL LRS-350-12 are available upon request, making it easy to evaluate before committing to a larger order. Delivery times are prompt, and payment terms remain flexible-your efficiency and satisfaction are prioritised. Orders are prepared and handed over quickly so you can maintain momentum on critical projects.

FAQ's of MEANWELL POWER SUPPLY, LRS-350-12, OUTPUT 12V 29A:

Q: How can I personalise the MEANWELL LRS-350-12 power supply to fit my project requirements?

A: The adjustable output voltage range of 10.2-13.8V allows for customisation according to application demands, making it suitable for various industrial and commercial uses.

Q: What commercial and general uses is this power supply suited for?

A: This model is ideal for industrial automation, LED lighting, control systems, and other applications requiring resilient, high-output power in a compact, fanless format.

Q: When will my order for the MEANWELL LRS-350-12 be handed over?

A: In-stock products are typically prepared and handed over for dispatch promptly after order confirmation and completion of payment formalities.

Q: Where does the MEANWELL LRS-350-12 stand out compared to conventional power supplies?

A: Its opulent, low profile, fanless design and commanding efficiency up to 89% make it superior in environments demanding both silence and performance.

Q: What is the process for requesting a sample or advance purchase?

A: Simply contact your supplier or wholesaler directly with your requirements. They will propose an amount, check available stock, and arrange timely sample dispatch or advance purchase as needed.

Q: How does the LRS-350-12 ensure safety during operation?

A: It complies with global safety standards such as UL62368-1, TUV EN62368-1, and features over-voltage, over-load, and short-circuit protections for secure, worry-free usage.
