E2EY-X8C1,Omron Aluminium -Detecting Non-Ferrous Proximity Sensor

E2EY-X8C1,Omron Aluminium -Detecting Non-Ferrous Proximity Sensor Specification

Response Time
1 ms

IP Rating
IP67

Cable Length
2 meters (standard) PVC insulated

Mounting Type
Flush/embedded mounting

Sensor Type
Inductive Proximity

Sensitivity
Optimized for non-ferrous metals (Aluminium)

Operating Temperature
-25C to +70C (No icing or condensation)

Power Consumption
15 mA (no load)

Features
Aluminium-detecting, Non-ferrous metal sensitivity, Short-circuit and reverse polarity protection

Wireless
No

Interface
Cable output, 3-wire DC

Signal Type
Digital (ON/OFF switching)

Application
Detection of aluminium and non-ferrous metals in conveyors, machines, and assembly lines

Measurement Range
8 mm (Standard sensing distance for aluminium)

Product Type
Proximity Sensor

Material
Metal

Input
12 to 24 VDC

Output
NPN NO (Normally Open)

Function
Sensing

Usage
Commercial

Accuracy
High Repeatability (10% of sensing distance)

Resolution
Discrete, not analog

Voltage
1224 V DC (operating voltage range: 1030 V DC)

Weight
Approx. 110 g (including cable)

Warranty
Yes

Status Indicator
LED operation indicator

Case Material
ABS plastic

Sensing Object
Non-ferrous metals (maximum sensitivity for aluminium)

Approvals/Certification
CE Marked

Protection Circuitry
Surge suppressor, load short-circuit protection, reverse polarity protection

Ambient Humidity
35% to 95% RH

Model Number
E2EY-X8C1

Control Output Current
Max 200 mA

Connector Type
Pre-wired (cable attached)

Hysteresis
20% of sensing distance

Shock Resistance
500 m/s (approx. 50G) 3 times each in X, Y, Z direction

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude for 2 hrs in X, Y, Z direction

Repeat Accuracy
Within 0.05 mm

E2EY-X8C1,Omron Aluminium -Detecting Non-Ferrous Proximity Sensor Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
5-10 Days

Main Domestic Market
All India

About E2EY-X8C1,Omron Aluminium -Detecting Non-Ferrous Proximity Sensor

Spotlight your industrial operations with the resplendent E2EY-X8C1 Omron Aluminium-Detecting Non-Ferrous Proximity Sensor. Engineered for unbeatable performance, it ensures lustrous accuracy with a repeatability of within 0.05 mm and optimized sensitivity for aluminium. Designed to withstand challenging environments, its IP67-rated ABS case, reverse polarity, and surge protection circuits amplify longevity and safety. Benefit from a special discount and personalise your automation with this cutting-edge sensor. Ideal for commercial usage, the E2EY-X8C1 guarantees reliable detection in conveyors, machines, and assembly lines.

Competitive Edge and Applications of E2EY-X8C1

The E2EY-X8C1's competitive advantages include high repeat accuracy, non-ferrous metal optimized sensitivity, and robust ABS construction. Effortlessly deployed in conveyors, industrial machinery, and assembly lines, it excels in aluminium detection with a sensing range of 8 mm. Easy flush or embedded mounting enhances directional use flexibility. Its LED status indicator and digital ON/OFF output ensure reliable media interaction across demanding commercial applications, maximizing productivity and detection reliability.

Supply, Payment, and Packaging for E2EY-X8C1

The E2EY-X8C1 sensor is readily available for immediate supply to meet bulk and ongoing industrial demands. Goods transport is arranged using efficient transport services, ensuring safe and timely delivery across India. Flexible payment terms accommodate diverse business needs. Each unit is securely packaged to protect against physical damage during transit, with clear labeling and documentation included for secure goods handling from supplier to end-user destination.

FAQ's of E2EY-X8C1,Omron Aluminium -Detecting Non-Ferrous Proximity Sensor:

Q: How does the E2EY-X8C1 sensor detect non-ferrous metals like aluminium?

A: The E2EY-X8C1 uses inductive proximity technology with optimized sensitivity specifically for non-ferrous metals such as aluminium, ensuring precise detection within a standard range of 8 mm.

Q: What benefits does the E2EY-X8C1 offer for commercial automation?

A: This sensor delivers high repeat accuracy, robust surge and polarity protection, and seamless integration into commercial settings, making it ideal for reliable, maintenance-friendly automation of conveyors, machines, and assembly lines.

Q: Where is the E2EY-X8C1 typically installed?

A: The sensor is installed in industrial environments like conveyor systems, manufacturing machines, and automated assembly lines where precise non-ferrous metal detection is critical for operational efficiency.

Q: When is the optimal time to use the E2EY-X8C1 sensor?

A: It is best to use this sensor when reliable and accurate detection of aluminium or other non-ferrous metals is required, especially in high-vibration or harsh conditions due to its robust mechanical and protective features.

Q: What is the process for connecting the E2EY-X8C1 sensor to a control system?

A: The sensor features a 2-meter pre-wired cable with a 3-wire DC configuration for straightforward interface and connection to PLCs, controllers, or monitoring systems, facilitating easy setup and maintenance.
