DELTA LASER SENSOR, EX-L211-P

DELTA LASER SENSOR, EX-L211-P Specification

Features
Compact, lightweight, fast response

Interface
2-wire / 3-wire connection

IP Rating
IP67

Mounting Type
Panel, Surface Mount

Spectral Range
Visible Red Laser (650nm)

Wireless
No

Operating Temperature
-10C to +55C

Sensor Type
Laser Through-beam sensor

Response Time
0.5 ms

Application
Positioning, Counting, Presence Detection

Signal Type
Digital

Measurement Range
0.5 m (through-beam type)

Housing Material
Plastic

Cable Length
2 meters

Ingress Protection
IP67

Sensitivity
Adjustable

Mounting Thread
M2.6

Power Consumption
Max. 20 mA

Product Type
Laser Sensor

Material
ABS Plastic

Input
12-24V DC

Output
NPN Open Collector

Function
Object Detection

Usage
Automation, Industrial applications

Accuracy
High precision, up to 0.5mm

Resolution
Fine (for small object detection)

Voltage
12 - 24 VDC

Weight
Approx. 20 g (including cable)

Hysteresis
Minimal for high switching accuracy

Operating Humidity
35-85% RH (no condensation)

Cable Material
PVC insulation

Light Source
Class 1 Red Semiconductor Laser

Short-circuit Protection
Yes

Reverse Polarity Protection
Built-in

Repeatability
High (0.1mm)

Package Contents
Sensor, instruction manual

Ambient Light Immunity
Yes, resistant to ambient light interference

DELTA LASER SENSOR, EX-L211-P About

Discover the superb, top-ranking DELTA LASER SENSOR EX-L211-P-engineered for optimum accuracy and automation needs. This scarce sensor is available with competitive pricing and limited stock. Featuring a Class 1 red semiconductor laser, this high-precision device boasts minimal hysteresis for superior switching accuracy and reliable object detection. Built with robust IP67 ingress protection and advanced features like high ambient light immunity, reverse polarity, and short-circuit protection, the EX-L211-P ensures flawless operation. Compact and lightweight, it's ideal for demanding industrial applications, delivering unbeatable efficiency and consistent results every time.

DELTA LASER SENSOR, EX-L211-P: Advantages & Features

This top-ranking sensor excels in automation, offering fine resolution for small object detection and minimal hysteresis for high switching accuracy. It's designed for various industrial tasks, including positioning, counting, and presence detection. The compact and lightweight housing, paired with adjustable sensitivity and fast 0.5 ms response time, make it an optimum choice for modern requirements. Its robust ambient light immunity and IP67 rating assure uninterrupted use in challenging environments, backed by built-in polarity and short-circuit protections.

Sample Policy and Packaging for DELTA LASER SENSOR, EX-L211-P

Sample availability is provided for clients requiring preliminary evaluation before bulk orders. Shipment and delivery processes are streamlined for both domestic and international markets to ensure prompt arrival. Each sensor is packaged with care, accompanied by a detailed instruction manual, and protected for secure transport. Packaging is designed to minimize any transit-related damage, catering to the highest standards whether shipping within the domestic market or abroad, ensuring every sample and order arrives in superb condition.

FAQ's of DELTA LASER SENSOR, EX-L211-P:

Q: How does the DELTA LASER SENSOR, EX-L211-P maintain high measurement accuracy in industrial settings?

A: The sensor achieves high measurement accuracy with minimal hysteresis, fine resolution (up to 0.5mm), and immunity to ambient light, ensuring precise detection and repeatable results, even in complex environments.

Q: What features make the EX-L211-P suitable for industrial automation applications?

A: The EX-L211-P offers fast response times (0.5 ms), adjustable sensitivity, IP67 ingress protection, lightweight housing, and robust protections, making it ideal for automation tasks like positioning, counting, and presence detection.

Q: Where is the DELTA LASER SENSOR, EX-L211-P commonly used?

A: This laser sensor finds frequent use in industrial automation systems, manufacturing processes, and applications requiring accurate object detection, presence monitoring, and fine position control.

Q: When should I consider requesting a sample of the EX-L211-P?

A: Request a sample when you need to evaluate sensor performance in your application or want to verify compatibility with your existing setup before proceeding with a bulk purchase.

Q: What safeguards are included to ensure safe and reliable sensor operation?

A: The EX-L211-P integrates built-in reverse polarity and short-circuit protection, durable ABS housing, and PVC-insulated cables to promote reliability in various industrial environments.

Q: How is the EX-L211-P shipped and what does the package include?

A: Each shipment is securely packaged and contains the laser sensor and an instruction manual, ensuring safe delivery and ease of installation upon arrival.
