AUTONICS, TEMPERATURE CONTROLLER, TCN4S-24R

AUTONICS, TEMPERATURE CONTROLLER, TCN4S-24R Specification

Type
Digital Temperature Controller

Theory
Proportional-Integral-Derivative (PID) Control

Capacity
1 Control Output, 1 Alarm Output

Exterior Material
Polycarbonate/ABS (Flame-resistant plastic case)

Interior Material
PCB and Electronic Components

Internal Size
48 x 48 mm (DIN 48-square size)

External Size
Panel Cutout: 45 x 45 mm

Heating System
External Heater Control via Relay

Cooling System
External Cooling Control via Relay

Controller System
Microprocessor-based Digital Controller

Temperature Range
-10C to 50C (Operating Ambient Temp)

Protection Structure
IP66 (front panel), IP20 (terminal)

Control Output
Relay (SPDT, 250VAC 5A resistive load)

Display
7-segment LED dual display (4 digits)

Dimensions
48 x 48 x 100 mm (W x H x D)

Mounting Method
Panel Mount

Control Method
ON/OFF, P, PI, PD, PID; Auto-tuning / Self-tuning

Safety Standards
CE, UL

Power Supply
100-240VAC 50/60Hz, 24VAC/DC (model dependent)

Input Type
Thermocouple (K, J, L, T, E, R, S, B, N, C), RTD (Pt100, JPt100)

Weight
Approx. 250g

Accuracy
0.5% F.S. 1 digit

Setting Method
Front Keypad Digital Setting

Sampling Cycle
100 ms

Alarm Output
Relay (SPST, 250VAC 3A resistive load)

AUTONICS, TEMPERATURE CONTROLLER, TCN4S-24R About

Access a masterful level of temperature control with the AUTONICS TCN4S-24R Temperature Controller. Unlock precision and reliability in your process with its gilt-edged PID control technology, supporting both thermocouple and RTD inputs for venerable accuracy. Personalise your setup via the intuitive front keypad and dual 7-segment LED displays. With a robust polycarbonate/ABS case, IP66 facade, and internationally recognised certifications, this microprocessor-based controller delivers dependable relay outputs, making it the perfect automation solution for demanding industrial, laboratory, and commercial environments.

Enhanced Versatility and Application Benefits

The AUTONICS TCN4S-24R Temperature Controller is suitable for industrial process control, laboratory automation, or commercial heating and cooling applications. Simply install the unit onto your panel, connect your selected sensors, and personalise temperature settings using the front keypad. Users benefit from advanced auto-tuning, reliable relay outputs, and a gilt-edged accuracy of 0.5%. Its robust construction and compact design allow for easy integration and operation in various demanding environments.

Market Reach, Flexible Payment, and Robust Supply

AUTONICS TCN4S-24R is supplied to extensive export markets including Asia, Europe, and the Middle East. With punctual goods transport, reliable supply ability, and secure payment terms like T/T or LC, this product ensures smooth commercial transactions. Distributors and traders rely on AUTONICS for continuous stock availability, efficient order processing, and immaculately packed goods, charging forward to meet client requirements worldwide with dependable delivery networks and high-volume fulfillment.

FAQ's of AUTONICS, TEMPERATURE CONTROLLER, TCN4S-24R:

Q: How do I set up the AUTONICS TCN4S-24R Temperature Controller?

A: Install the unit by panel mounting, connect the appropriate input sensors (thermocouple or RTD), wire the control and alarm outputs, and personalise the temperature settings using the front keypad and digital interface.

Q: What types of inputs are compatible with the TCN4S-24R model?

A: This model accepts thermocouple types K, J, L, T, E, R, S, B, N, C and RTD types Pt100 and JPt100, allowing for a wide range of temperature monitoring applications.

Q: When is the auto-tuning or self-tuning function beneficial?

A: Auto-tuning is advantageous during initial setup or when changing load conditions, ensuring the controller automatically finds optimal PID parameters for masterful process stability and reduced manual adjustments.

Q: Where can I use the AUTONICS TCN4S-24R controller?

A: This controller is ideal for industrial machinery, laboratory equipment, commercial HVAC systems, and any process requiring precise temperature regulation in a panel-mounted configuration.

Q: What are the advantages of using a microprocessor-based digital controller?

A: Microprocessor control allows for precise, gilt-edged accuracy, programmable functions, advanced control algorithms (PID, ON/OFF), and adaptability to complex monitoring scenarios, ensuring reliable and efficient operation.
