AUTONICS ROTARY ENOCDER 12-24VDC, E40S6-1000-3-T-24

AUTONICS ROTARY ENOCDER 12-24VDC, E40S6-1000-3-T-24 Specification

Voltage
12-24V DC 5%

Features
Incremental rotary encoder, Solid shaft, Compact size, Wide voltage range

Bearing Type
Ball bearing

Ambient Temperature
-10C to 70C (non-freezing, non-condensing)

Standard
CE, RoHS

Current Type
DC

Rated Voltage
12-24V DC

Product Type
Rotary Encoder

Protect Feature
Reverse polarity protection, Surge protection

Phase
3-phase (for output signal) [A, B, Z]

Speed
Max. 6000 rpm

Color
Black/Metallic

Dimension (L*W*H)
40 mm (outer diameter), Total length 37 mm (excluding shaft)

Weight
Approx. 200g

Shaft Diameter
6 mm

Mounting Type
Clamp Mount

IP Rating
IP50

Output Mode
Incremental

Output Signal
NPN Open Collector (A, B, Z phase) - 3 Channels

Model
E40S6-1000-3-T-24

Material (Shaft)
Stainless Steel

Cable Length
2 meters

Vibration Resistance
10 to 55 Hz, amplitude 1.5 mm, X, Y, Z each 2 hours

Pulse per Revolution (PPR)
1000

Insulation Resistance
Over 100M (at 500V DC)

Maximum Response Frequency
100 kHz

Cable Connection
Radial

Material (Body)
Aluminum

About AUTONICS ROTARY ENOCDER 12-24VDC, E40S6-1000-3-T-24

Redeem the best price for the ravishing AUTONICS ROTARY ENCODER 12-24VDC, model E40S6-1000-3-T-24. Renowned for extraordinary reliability and robust construction, this incremental rotary encoder boasts a remarked output signal of NPN open collector (A, B, Z phase) across 3 channels. With an impressive Pulse per Revolution of 1000 and a wide 12-24V DC operating range, it's crafted from quality aluminum and stainless steel. Benefit from advanced protection features, compact design, and a maximum speed of 6000 rpm. Take advantage of this remarkable device offered by a reputed supplier from China.

Applications & Features: Your Reliable Automation Solution

The AUTONICS E40S6-1000-3-T-24 rotary encoder is ideal for automation, robotics, CNC systems, and industrial machinery. Its compact size permits versatile installation, while the solid shaft enhances precision and endurance. Use this encoder for real-time monitoring, speed control, or position detection. Directional output is supported with A, B, and Z-phase signals. Key features include a wide voltage range, high vibration resistance, and reliable protection circuitry, making this encoder perfect for demanding environments.

Packaging, Export Destinations & Sampling Convenience

Each AUTONICS encoder is securely packaged to ensure protection during order processing. Designed for global markets, the main export destinations include Asia, Europe, and the Middle East, offering companies the lowest price with optimized expenditure. Samples are available for evaluation upon request, assisting customers before large-scale orders. Experience hassle-free transactions and efficient delivery as a part of our comprehensive export and after-sales support system, tailored for international clients.

FAQ's of AUTONICS ROTARY ENOCDER 12-24VDC, E40S6-1000-3-T-24:

Q: How can the AUTONICS E40S6-1000-3-T-24 rotary encoder be used in industrial applications?

A: The encoder is suitable for use in automation, robotics, and CNC machines, providing precise feedback on position, speed, and direction in challenging industrial environments.

Q: What are the main benefits of choosing the E40S6-1000-3-T-24 encoder?

A: It offers high accuracy with 1000 pulses per revolution, robust construction, excellent protection features, and compatibility with a wide voltage range, guaranteeing dependable performance.

Q: Where can this rotary encoder be installed?

A: Thanks to its compact and solid design, it can be installed in various setups, including tight machinery spaces and equipment that demands high-speed response and accurate measurement.

Q: What is the process for ordering and sample availability?

A: To order or request samples, contact the supplier directly. Samples are available for initial evaluation so you can assess suitability before full-scale procurement.

Q: How does the encoder handle reverse polarity and electrical surges?

A: The device comes equipped with reverse polarity and surge protection features, ensuring safe and uninterrupted operation even in fluctuating electrical conditions.
