AUTONICS ROTARY ENCODER,EP50S8-1024-2F-P-24

AUTONICS ROTARY ENCODER,EP50S8-1024-2F-P-24 Specification

Conductor Type
Flexible

Rated Temperature
-10C to +70C

Usage & Applications
Used in CNC machines, industrial robots, conveyor systems

Locking Type
Shaft with flat

Number of Conductor
8 wires

Install Type
Flange mount

Conductor Shape
Stranded

Core Number
8

Weight
Approx. 300g

Diameter
50mm

Core Material
Copper

Features
Incremental rotary encoder, compact size, easy installation, high precision, long service life

Dielectiric Strength
AC 500V 60Hz for 1 minute

Insulation
Insulation resistance 100M (DC 500V)

Cable Type
Shielded cable

Operating Temperature
-10C to +70C

Product Type
Rotary Encoder

Length
Standard cable length: 2 meters

Voltage
5-24VDC 5%

Insulation Material
Polyvinyl Chloride (PVC)

Application
Industrial automation, position/speed control, servo systems, motor feedback

Conductor Material
Copper

Jacket Material
PVC

Storage Temperature
-25C to +85C

Connector Color
Black

Shield Material
Aluminum foil

Jacket Color
Black

Dimension (L*W*H)
50mm x 48.5mm (Diameter x Length)

Material
Metal body, plastic rear cover

Color
Black/Silver

Size
50mm Shaft

Resolution
1024 pulses/rev

Model Number
EP50S8-1024-2F-P-24

Rotation Direction
Bi-directional

Pulse Per Revolution (PPR)
1024 P/R

Output Type
NPN Open Collector

Cable Exit Direction
Radial

Protection Structure
IP50

Max. Revolution
6000 rpm

Starting Torque
Max. 70gfcm (at room temperature)

Allowable Load
Radial 50N, Thrust 30N

Reference Standard
IEC standard compliant

Shaft Diameter
8mm

Mounting Hole Diameter
5.5mm

Response Frequency
Max. 300kHz

About AUTONICS ROTARY ENCODER,EP50S8-1024-2F-P-24

Discover the AUTONICS ROTARY ENCODER, EP50S8-1024-2F-P-24-now offered at a reduced and affordable outlay. Decorated with a flawless metal body and resplendent black/silver finish, this compact rotary encoder promises impeccable performance in demanding automation environments. Pick yours to enjoy high precision, 1024 pulses per revolution, and reliable NPN open collector output. With an IP50 protection structure, shaft locking, easy flange mount, and efficient PVC-shielded cable, it's a standout solution for position and speed control in CNC machines, robotics, and motor feedback applications.

Versatile Performance for Industrial Applications

The AUTONICS ROTARY ENCODER, EP50S8-1024-2F-P-24 excels in various settings such as CNC machines, industrial robots, conveyor systems, and servo applications. Crafted with a sturdy metal body, black PVC-jacketed shielded cable, and stranded copper conductors, this encoder ensures robust signal integrity and long-lasting durability. Features like bi-directional rotation, compact size, and easy installation make it a top choice for industrial automation and precise control systems.

Efficient Export, Packaging, and Supply

AUTONICS ROTARY ENCODER, EP50S8-1024-2F-P-24 is shipped promptly from reputable FOB ports in Korea South, reaching main export markets including Asia, Europe, and the Middle East. Each unit is meticulously packaged to guarantee product integrity during shipment. With substantial supply ability, wholesale clients and traders benefit from affordable pricing and consistent availability, ensuring smooth procurement and reliable, uninterrupted operations for industrial projects.

FAQ's of AUTONICS ROTARY ENCODER,EP50S8-1024-2F-P-24:

Q: How does the AUTONICS EP50S8-1024-2F-P-24 rotary encoder improve automation systems?

A: Its high-resolution 1024 PPR output, bi-directional rotation, and robust construction provide accurate position and speed feedback, enhancing the efficiency and control of CNC machines, conveyers, and industrial robots.

Q: What materials are used in the construction of this rotary encoder?

A: The encoder features a metal body for durability, a plastic rear cover, flexible stranded copper conductors, and a PVC jacket, ensuring long service life and excellent insulation.

Q: When is it suitable to use this encoder in industrial settings?

A: This encoder is ideal for applications requiring precise feedback and control, such as motor positioning, servo systems, and environments needing reliable electronics within an operating temperature of -10C to +70C.

Q: Where can the AUTONICS rotary encoder be installed?

A: It can be easily mounted on compatible machinery using its flange mount and is suitable for industrial settings where position or speed feedback is required, such as automated production lines.

Q: What is the process for ordering and receiving the product?

A: Orders are shipped promptly from Korea South FOB ports with secure packaging. The supplier ensures quick and reliable delivery to main export markets, and wholesalers benefit from steady supply and competitive pricing.

Q: How is the product protected during transport?

A: Each rotary encoder is packaged with care to safeguard it against damage, ensuring flawless delivery and maintaining its resplendent appearance and performance upon arrival.
