AUTONICS ROTARY ENCODER, ENC-1-1-N-24

AUTONICS ROTARY ENCODER, ENC-1-1-N-24 Specification

Voltage
12-24VDC Volt (v)

Rated Frequency
Not Specified

Sealed Type
Not Specified

Efficacy
Not Specified

Features
Compact size, high reliability, high-speed response

Power Rating
Not Specified

Noise Level
Not Specified

Ambient Temperature
-10°C to +70°C (Non-Freezing)

Bearing Type
Ball Bearing

Rated Voltage
12-24VDC

Pressure
Not Specified

Current Type
DC

Product Type
Rotary Encoder

Output Power
Not Specified

Protect Feature
Not Specified

Speed
Not Specified

Power
12-24VDC±5% Volt (v)

Color
Black and Silver

Dimension (L*W*H)
Diameter 38mm x Height 28mm (excluding shaft and cable)

Weight
Approx. 65g

Shaft Diameter
6 mm

Mounting Type
Panel Mount

Dielectric Strength
500VAC 50/60Hz for 1 minute

Insulation Resistance
Min. 100M (at 500VDC)

Shaft Loading
Radial 5N, Axial 2.5N

Output Type
NPN Open Collector

Max. Response Frequency
20 kHz

Connection Type
5-wire, Cable Length 2m

Output Phase
A, B Phase

Model
ENC-1-1-N-24

Resolution
100 pulses per revolution (P/R)

Max. Allowable Rotational Speed
5000 rpm

Housing Material
Aluminum

Output Voltage
High (Min. Vcc-0.7V); Low (Max. 0.5V)

Cable Specification
4mm, 5-core shielded cable, 2m

Consumption Current
Max. 40mA

About AUTONICS ROTARY ENCODER, ENC-1-1-N-24

Experience the new release of the AUTONICS ROTARY ENCODER, ENC-1-1-N-24a must-have for precise industrial automation. This towering piece of engineering delivers superlative performance with terrific accuracy, offering 100 pulses per revolution and reliable NPN Open Collector output. Fitted with a rugged aluminum housing, its 5-wire, 2m shielded cable ensures robust and stable connections. Designed for fast response with a 20 kHz maximum frequency and up to 5000 rpm speed, this compact encoder is perfect for demanding tasks. Utilise offer now for unmatched efficiency!

Versatility and Competitive Edge

The AUTONICS ROTARY ENCODER, ENC-1-1-N-24 is widely used by automation professionals and system integrators across diverse industries. Its competitive advantages include high-speed response, compact form, and outstanding reliability, making it ideal for robotics, packaging equipment, and CNC machinery. Applications are broad, ranging from position detection to speed monitoring. This trusted encoder empowers you to achieve precise control in complex operational setups, enhancing productivity and system performance.

Export Markets and Supply Details

Main export markets for the AUTONICS ROTARY ENCODER ENC-1-1-N-24 include Asia, Europe, and North America. Each unit is carefully packaged to prevent damage during transit. With a terrific sale price offered at one of the lowest price points in the market, customers can expect fast dispatched orders through reliable shipping partners. Supply ability remains robust, ensuring prompt fulfillment of both bulk and individual orders as per customer demands.

FAQs of AUTONICS ROTARY ENCODER, ENC-1-1-N-24:

Q: How is the AUTONICS ROTARY ENCODER, ENC-1-1-N-24 typically used?

A: This encoder is commonly used in applications requiring precise position or speed feedback, such as in robotics, CNC machines, and automated conveyor systems.

Q: What are the main benefits of choosing the ENC-1-1-N-24 model?

A: Its main benefits include compact size, high reliability, fast response rate up to 20 kHz, and solid performance in demanding industrial environments.

Q: Where can I install the ENC-1-1-N-24 rotary encoder?

A: You can install it using a panel mount setup, making it suitable for integration into various types of machinery or control panels.

Q: What is the process for connecting the encoder to my system?

A: Connection is straightforward with its 2m, 5-wire shielded cable. Wire according to the color-coded scheme in your devices manual to interface with your controller or PLC.
