AUTONICS ROTARY ENCODER, E50S8-360-3-T-1

AUTONICS ROTARY ENCODER, E50S8-360-3-T-1 Specification

Torque
Not Specified

Power Rating
Not Specified

Ambient Temperature
Not Specified

Sealed Type
Not Specified

Bearing Type
Not Specified

Voltage
5-24VDC ±5%

Starting Type
Not Specified

Features
Compact Size, High Reliability

Current Type
Not Specified

Poles Number
Not Specified

Noise Level
Not Specified

Rated Voltage
5-24VDC ±5%

Product Type
Rotary Encoder

Protect Feature
Not Specified

Power
5-24VDC ±5%

Color
Not Specified

Dimension (L*W*H)
Not Specified

Weight
Not Specified

Shaft Diameter
8 mm

Mounting Type
Not Specified

IP Rating
IP50

Shaft Length
20 mm

Resolution
360 PPR (Pulses Per Revolution)

Maximum Response Frequency
300 kHz

Material
Aluminum Alloy Housing

Humidity Range
35% to 85% RH (Non-condensing)

Operating Temperature Range
-10C to +70C

Application
Position Detection, Automation Equipment, CNC Machines

Insulation Resistance
Minimum 100 M (at 500V DC)

Body Diameter
50 mm

Connection Type
Cable Type

Cable Length
2 meters

Encoder Model
E50S8-360-3-T-1

Output Signal
5V to 24V DC

Shock Resistance
50 G

Storage Temperature Range
-25C to +85C

Vibration Resistance
10 to 55 Hz, Double amplitude 1.5 mm

Output Phase
A, B, Z

Maximum Rotational Speed
6000 rpm

Output Type
NPN Open Collector

AUTONICS ROTARY ENCODER, E50S8-360-3-T-1 About

Discover gorgeous savings with the AUTONICS ROTARY ENCODER E50S8-360-3-T-1, crafted for unmatchable accuracy and blue-ribbon performance in industrial automation. Boasting a robust aluminum alloy housing and compact 50 mm body, this incremental rotary encoder delivers 360 PPR at a fabulous best price. Its NPN open collector output, 2-meter cable, and 300 kHz max response frequency guarantee versatile, dependable use. Enjoy affordable quality for CNC machines and position detection, backed by high vibration and shock resistance, making it the top affordable solution for your automation needs in Vietnam.

Optimized Application, Guaranteed Precision

The AUTONICS ROTARY ENCODER E50S8-360-3-T-1 excels in position detection for automation equipment and CNC machines, making it ideal for diverse industrial uses. Its incremental type design, supporting output phases A, B, Z, provides accurate pulse feedback for real-time position tracking. Designed for cable-type connections and reliable mounting, this device ensures seamless integration into production setups, enhancing efficiency in velocity and direction monitoring. Its compact design suits installations with confined spaces, emphasizing reliability and durability.

Sample Policy, Logistics & Flexible Payment Terms

We offer attractive list price discounts and competitive offers for bulk orders of AUTONICS ROTARY ENCODER E50S8-360-3-T-1. Samples can be provided under our supportive policy to ensure customer satisfaction before full commitment. All shipments are handled efficiently from Vietnams main FOB ports, enabling timely and secure logistics. With flexible payment terms tailored to your business needs, we ensure your procurement process remains smooth, affordable, and customer-oriented.

FAQs of AUTONICS ROTARY ENCODER, E50S8-360-3-T-1:

Q: How does the AUTONICS ROTARY ENCODER E50S8-360-3-T-1 benefit automation applications?

A: Its high resolution (360 PPR), robust construction, and quick response frequency of up to 300 kHz significantly enhance position tracking and operational reliability in automation equipment.

Q: What is the primary use type and recommended application method for this encoder?

A: This device is an incremental rotary encoder, best utilized for position and direction feedback in CNC machinery and automated industrial systems using A, B, and Z output phases and a secure cable connection.

Q: When should I consider choosing this model over others?

A: Select this model when you require compact size, affordable investment, high reliability, and strong resistance to vibration and shock in environments with temperatures ranging from -10C to +70C.

Q: Where can I procure the AUTONICS ROTARY ENCODER E50S8-360-3-T-1 in Vietnam?

A: This rotary encoder is available through leading suppliers, traders, and wholesalers specializing in industrial automation products across Vietnam.

Q: What is the process for requesting a product sample or placing an order?

A: Contact your preferred supplier or our sales team to discuss the sample policy and current offers. Confirm payment terms, and shipments will be arranged via Vietnams main FOB ports.
