AUTONICS,ROTARY ENCODER, E50S8-2500-3-T-1

AUTONICS,ROTARY ENCODER, E50S8-2500-3-T-1 Specification

Bearing Type
Ball Bearing

Ambient Temperature
-10°C to +70°C

Rated Voltage
5-24VDC

Power Rating
Not Specified

Noise Level
Not Specified

Voltage
5-24VDC ±5%

Sealed Type
IP50 (Standard)

Current Type
DC

Product Type
Rotary Encoder

Protect Feature
Reverse Polarity Protection

Power
5-24VDC ±5%

Color
Black / Silver

Dimension (L*W*H)
50mm Dia x 38mm Length (Body), Shaft Length 35mm

Weight
Approx. 280g

Shaft Diameter
8mm

Mounting Type
Shaft Mounting

Model
E50S8-2500-3-T-1

Applicable Wire Size
AWG24-AWG20

Encoder Type
Incremental Rotary Encoder

Maximum Allowable Revolution Speed
5000rpm

Insulation Resistance
Over 50M (at 500VDC)

Dielectric Strength
500VAC 50/60 Hz for 1 minute

Shock Resistance
500m/s2 (Approx. 50G)

Starting Torque
5mNm or less

Resolution
2500 Pulses per Revolution (PPR)

Vibration Resistance
10 to 55Hz, 1.5mm double amplitude

Shaft Type
Solid Shaft

Maximum Response Frequency
300kHz

Output Type
NPN Open Collector (3-phase: A, B, Z)

About AUTONICS,ROTARY ENCODER, E50S8-2500-3-T-1

Discover the rare and outstanding AUTONICS ROTARY ENCODER E50S8-2500-3-T-1, a marvel in industrial automation renowned for its precision. A true find in reserved stock, this incremental rotary encoder delivers an impressive 2500 pulses per revolution with a robust NPN Open Collector output (A, B, Z phases). Housed in a sealed IP50-rated body, its reliable solid shaft and advanced ball bearings offer stability at speeds up to 5000rpm. Backed by reverse polarity protection and remarkable vibration/shock resistance, this sought-after encoder is perfect for demanding automation environments.

Special Features and Suitable Applications

Featuring high-resolution 2500 PPR output, the AUTONICS E50S8-2500-3-T-1 offers marvelous response speed and accuracy. Its reserved solid shaft and 50mm diameter design suit factory automation, robotics, CNC machinery, and conveyor systems. Its outstanding shock and vibration resistance make it ideal for industrial surfaces subjected to demanding conditions, ensuring reliable performance. This renowned encoder is suitable for systems requiring precise speed, direction, and positioning control.

Export Markets and Supply Capabilities

With a strong presence in Korea North, the AUTONICS ROTARY ENCODER E50S8-2500-3-T-1 is regularly dispatched to major industrial markets worldwide. Sample availability ensures evaluation before larger orders, while steady supply ability guarantees timely goods transport. Buyers can inquire about the asking price, with dependable logistics supporting prompt delivery and safe handling of reserved inventory. Its reputable exporter network adds assurance for global traders and wholesalers.

FAQs of AUTONICS,ROTARY ENCODER, E50S8-2500-3-T-1:

Q: How does the AUTONICS E50S8-2500-3-T-1 ensure accuracy in positioning applications?

A: This encoder boasts a high resolution of 2500 pulses per revolution, enabling precise speed and position detection essential for automation systems and equipment calibration.

Q: What makes the E50S8-2500-3-T-1 suitable for harsh industrial environments?

A: The encoder offers outstanding shock and vibration resistance, along with IP50 sealing and a robust solid shaft design, making it well-suited for demanding industrial applications.

Q: Where can the AUTONICS rotary encoder be installed?

A: It is ideal for use in CNC machinery, robotics, conveyor systems, and general factory automation settings requiring accurate rotary motion feedback.

Q: What is the process for ordering samples or bulk quantities?

A: Interested buyers may request samples to test performance before committing to bulk purchases, with orders handled through trusted supplier and wholesaler networks ensuring prompt dispatching and safe transport.

Q: What benefits does reverse polarity protection offer?

A: Reverse polarity protection prevents circuit damage from incorrect wiring, safeguarding the encoder and increasing long-term reliability in industrial installations.
