AUTONICS,ROTARY ENCODER, E40H10-2028-3-T-24

AUTONICS,ROTARY ENCODER, E40H10-2028-3-T-24 Specification

Features
Incremental, Compact Size, Totem Pole Output, 2m Cable, High Reliability

Bearing Type
Ball Bearing

Rated Voltage
12-24VDC 5%

Ambient Temperature
-10C to +70C (Non-freezing)

Voltage
12-24VDC 5%

Power Rating
Not Specified

Current Type
DC

Noise Level
Not Specified

Sealed Type
Not Specified

Product Type
Rotary Encoder

Output Power
Not Specified

Protect Feature
IP50

Power
12-24VDC 5%

Color
Silver/Black

Dimension (L*W*H)
Diameter 40mm x Shaft Length (approx.)

Weight
Approx. 120g

Shaft Diameter
6mm

Mounting Type
Clamping or Servo Mount (Face Mount, Standard)

IP Rating
IP50

Allowable Shaft Load
Radial 30N, Axial 20N

Output
Totem Pole (NPN/PNP Open Collector, 3-phase A, B, Z)

Resolution
2000 pulses per revolution (PPR)

Connector
Cable Type (2 meters, radial)

Model
E40H10-2028-3-T-24

Max Response Frequency
200kHz

Country of Make
Korea

Max Shaft Speed
5000rpm

Moment of Inertia
Max. 6x107 kgm2

Insulation Resistance
50M at 500VDC

Shaft Type
Solid Shaft

Material
Case - Aluminum, Shaft - Stainless Steel

Dielectric Strength
750VAC 60Hz for 1 minute

Application
General Industrial Automation, Position Detection, Motion Feedback

About AUTONICS,ROTARY ENCODER, E40H10-2028-3-T-24

Introducing the elite AUTONICS ROTARY ENCODER E40H10-2028-3-T-24, renowned for its rare combination of excellent performance and durability. Decorated with a robust aluminum case and famed stainless steel solid shaft, this incremental rotary encoder delivers an outstanding resolution of 2000 PPR. Its compact, high-reliability design with a 2-meter cable and Totem Pole output makes it ideal for exploring advanced industrial automation, position detection, and motion feedback. Engineered for excellence, it meets demanding operational standards, supporting up to 5000rpm and ensuring long-lasting performance in rigorous environments. Proudly crafted in Korea for professionals who seek exceptional quality.

Versatile Applications and Distinct Advantages

AUTONICS E40H10-2028-3-T-24 excels across multiple surfaces in general industrial automation. Easily mounted on machinery via clamping or servo mounts, it ensures precise position detection and motion feedback. The main advantage lies in its compact size, high pulse resolution, and rare versatility, which streamline critical automation tasks. Explore enhanced operational accuracy and reliable signal output in various setups, making it a favored choice for engineers demanding dependable performance and adaptability.

Superior Packaging and Swift Supply Ability

Each E40H10-2028-3-T-24 rotary encoder is securely packaged for safe international export. With stock ready for immediate dispatch, rapid order fulfillment is guaranteed for bulk purchase demands. The sale price is optimized for the export market, catering to suppliers, traders, and wholesalers worldwide. Payment terms are designed to be flexible, supporting fast transactions and ensuring that buyers receive their premium encoders promptly, helping you accelerate project timelines and maintain seamless industrial operations.

FAQs of AUTONICS,ROTARY ENCODER, E40H10-2028-3-T-24:

Q: How is the AUTONICS E40H10-2028-3-T-24 rotary encoder mounted?

A: This encoder can be installed using clamping or servo (face) mounts, offering a standard fit for diverse machinery and ensuring secure, stable operation.

Q: What are the main benefits of using this rotary encoder in industrial applications?

A: Its high resolution (2000 PPR), compact form, and reliable signal output make it an excellent choice for precise position detection and motion feedback in demanding automation environments.

Q: When is this encoder most suitable for deployment?

A: It is ideal for use in environments where accurate, high-speed position or motion monitoring is essentialsuch as automated production lines and robotics.

Q: Where does the AUTONICS E40H10-2028-3-T-24 originate from?

A: This famed rotary encoder is manufactured in Korea, ensuring it meets stringent international quality and durability standards.

Q: What application methods are recommended for optimal use?

A: For best performance, securely mount the encoder using the provided cable and ensure electrical connections follow totem pole NPN/PNP open collector wiring guidelines. Regular checks will help maintain excellent operation.
