AUTONICS PULSE METER, MP5W-49

AUTONICS PULSE METER, MP5W-49 Specification

Features
Easy setting, High visibility LED, Scalable relay/transistor output, Wide input pulse range

Components
Main Meter Unit, Mounting Bracket, Instruction Manual

Power Source
AC Powered

IP Rating
Front panel: IP65

Display Type
7-segment LED

Operating Temperature
-10C to 50C

Power Supply
100-240 VAC 50/60Hz

Input
Pulse Signal (Contact or NPN Input)

Resolution
1 pulse

Usage
Industrial Pulse Counting and Rate Indication

Output
Relay Output, Transistor Output

Response Time
Display refresh time: Approx. 500ms

Interface
Panel Mount, Terminal Block

Sensors Specification
Accepts Contact or NPN Sensor Pulse Input

Product Type
Pulse Meter

Application
Automation Machines, Production Line Monitoring, etc.

Rated Voltage
100-240 VAC

Supply Voltage
100-240 VAC

Size
48mm x 96mm

Dimension (L*W*H)
96 x 48 x 115mm

Function
Pulse Measurement and Display

Color
Black

Weight
Approx. 300g

Capacity
Counting capacity up to 999999

Current Rating
Relay: 5A at 250VAC

Thickness
Panel thickness up to 10mm compatible

Frequency
50/60 Hz

Storage Temperature
-20C to 60C

Operating Humidity
35 to 85% RH

Count Range
0 to 999999

Counting Speed
30 cps (Contact), 5kHz (Open Collector/NPN)

Mounting Type
Panel Mount

Model
MP5W-49

Front Panel Material
Polycarbonate

Relay Output Rating
250VAC/3A

Humidity (Storage)
35 to 85% RH

Back Housing Material
ABS

SSR Drive Output Rating
30VDC/100mA max

Display Color
Red LED

External Control Inputs
Reset, Hold, Batch, Key Protect

About AUTONICS PULSE METER, MP5W-49

Discover the distinguished AUTONICS PULSE METER, MP5W-49crafted for those who demand pristine accuracy and prodigious performance in industrial automation. This advanced unit features a brilliant Red LED 7-segment display, supporting a substantial count range up to 999999. Designed to handle both relay and transistor outputs with scalable options, its panel mount design ensures seamless integration. For a limited time, find this dependable solution with easy setup and robust IP65 protection. Add to Cart now to upgrade your production line monitoring with renowned Autonics quality.

Advanced Industrial Pulse Counting and Monitoring

The AUTONICS PULSE METER, MP5W-49 is engineered for detailed pulse measurement and display in automation machines and production lines. With high visibility LED, fast response time, and a sturdy polycarbonate front panel, it excels in monitoring with precision. Its robust construction and compatibility with multiple sensor types make it ideal for factory environments where pristine accuracy is essential. Supporting a broad range of inputs and outputs, this device ensures efficient workflow management and consistent performance in every industrial setting.

Efficient Distribution and Export Readiness

Stock ready for immediate dispatch, the AUTONICS PULSE METER, MP5W-49 is available for domestic markets and major export destinations. Our streamlined logistics network ensures that every order is shipped quickly and reliably. Sample policies are designed for flexibility, enabling suppliers, traders, and wholesalers easy access. Backed by thorough documentation and robust packaging, we support businesses in China and worldwide, from order placement to delivery, ensuring prompt fulfillment and customer satisfaction with every shipment.

FAQs of AUTONICS PULSE METER, MP5W-49:

Q: How is the AUTONICS PULSE METER, MP5W-49 used in an industrial setting?

A: This pulse meter is primarily used for accurate pulse counting and rate indication on automation machines and production line monitoring, ensuring efficiency and reliable measurement in diverse industrial applications.

Q: What are the main benefits of the MP5W-49s display and outputs?

A: The pristine 7-segment Red LED display offers high visibility even in bright factory conditions. It features scalable relay and transistor outputs, providing compatibility with various control systems for greater versatility.

Q: Where can the AUTONICS MP5W-49 be installed?

A: It is designed for panel mount applications, allowing seamless integration into control panels with up to 10mm thickness, commonly found in production lines and automation equipment.

Q: What pulse inputs does the meter accept?

A: The MP5W-49 accepts both contact and NPN sensor pulse input signals, making it suitable for a wide range of sensor types commonly used in industrial environments.

Q: How does the shipment and logistics process work for this product?

A: Stock is ready for quick shipment. Upon order, the product is securely packed and shipped through efficient logistics channels, ensuring timely delivery to both domestic and international locations.
