AUTONICS PROXIMITY SENSOR, PS50-30DP

AUTONICS PROXIMITY SENSOR, PS50-30DP Specification

Signal Type
DC, 3-wire

Sensor Type
PS50-30DP

Power Consumption
15 mA

Application
Position Sensing, Counting, Automation Machinery, Conveyors

Operating Temperature
-25C to +70C

Wireless
No

Measurement Range
Sensing Distance 30 mm

Features
Short-circuit protection, Surge protection, Durable construction, LED status indicator

Sensitivity
Adjustable

Interface
Cable

Mounting Type
Flush/Embeddable

Response Time
2 ms

Cable Length
2 meters

IP Rating
IP67

Product Type
Proximity Sensor

Material
Nickel Plated Brass

Input
3-Wire DC

Output
PNP Normally Open

Function
Detection of metallic objects without contact

Usage
Industrial Automation, Object Detection

Accuracy
High accuracy, repeatability 0.05 mm

Voltage
12-24V DC

Weight
Approximately 470g

Vibration Resistance
1.5 mm at 10-55 Hz amplitude

Storage Temperature
-30C to +80C

Frequency
140 Hz

Housing Size
M50

Case Diameter
50 mm

Environmental Resistance
Humidity 35% to 95% RH

Insulation Resistance
50 M (at 500VDC megger)

Protection Circuits
Surge, Overload, Reverse Polarity

LED Indicator
Red (operation LED)

Storage Humidity
35% to 95% RH

Withstand Voltage
1500VAC, 50/60Hz for 1 minute (between charging part and case)

Switching Hysteresis
10% of sensing distance

Material (Sensing face)
ABS Resin

Control Output
DC 200 mA Max.

Shock Resistance
500 m/s2

Connector Type
Pre-wired

Detectable Object
Ferrous Metals

About AUTONICS PROXIMITY SENSOR, PS50-30DP

Find the ultimate solution for industrial automation with the AUTONICS PROXIMITY SENSOR, PS50-30DP. Spotlight this potent sensor, boasting a noble nickel-plated brass housing and a detectable range for ferrous metals up to 30 mm. Experience high accuracy (0.05 mm repeatability), versatile mounting, and durable ABS resin sensing face. With advanced protection circuits, steadfast insulation resistance, and reliable DC output, its red LED indicator ensures operational clarity. Purchase this sensor for precise position sensing, counting, and automation machinery, elevating productivity with robust performance.

Material Strength, Application Versatility, and Ultimate Usage

Crafted with a nickel-plated brass case and ABS resin sensing face, the PS50-30DP proximity sensor withstands harsh industrial environments. Its IP67 rating makes it suitable for diverse automation applications such as position sensing, conveyors, and counting in factories, warehouses, or assembly lines. The pre-wired design ensures quick installation, while the high repeatability and adjustable sensitivity guarantee accurate detection of metallic objects without physical contact.

Supply Capacity, Packaging, and Delivery Process

AUTONICS PROXIMITY SENSOR, PS50-30DP holds significant market value owing to its quality and dependability. Upon receiving a purchase order, our team ensures secure packaging for safe transit. The sensors are dispatched swiftly, typically within a prompt delivery time after order confirmation. Suppliers, traders, and wholesalers can rely on consistent availability for bulk requirements, optimizing procurement and supporting uninterrupted automation operations.

FAQs of AUTONICS PROXIMITY SENSOR, PS50-30DP:

Q: How does the AUTONICS PROXIMITY SENSOR, PS50-30DP enhance industrial automation?

A: The sensor offers precise detection of ferrous metals, high repeatability, and reliable performance in various environments, enabling efficient position sensing, counting, and machinery automation.

Q: What application areas are ideal for installing the PS50-30DP sensor?

A: This sensor is perfect for use in factories, warehouses, conveyor systems, position detection, and machinery automation where non-contact metal detection is required.

Q: When should the sensor be replaced or maintained?

A: Regular inspections are recommended; replace the sensor if noticeable inaccuracies or physical damage occur to maintain optimal operation and safety.

Q: Where can I purchase the AUTONICS PROXIMITY SENSOR, PS50-30DP?

A: You can acquire the sensor directly from authorized suppliers, traders, or wholesalers specializing in industrial automation components, particularly in Korea North.

Q: What is the process for dispatching the sensor after a purchase order?

A: Once a purchase order is received, the sensor is securely packaged and dispatched for delivery, typically within the stated timeline, ensuring safe and prompt arrival.

Q: What benefits does the sensors protection circuitry offer?

A: Its integrated surge, short-circuit, overload, and reverse polarity protection ensures longevity, operational safety, and minimizes downtime in challenging industrial environments.
